HOLDEN CALAIS VF Series 2013-2015 Workshop Service Manual

HOLDEN CALAIS VF Series 2013-2015 Workshop Service Manual

$17.99
$17.99
İndirim Tükendi
Kargo, ödeme sayfasında hesaplanır.
Vehicle data plateRef 86201
Brand
Holden
Vehicle
Material Handling
Models covered
CALAIS VF Series, Industrial Equipment & Tools, Transmissions Gearboxes, Tremec, Vehicle Parts & Accessories
Years
2013, 2014, 2015
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Holden
Model:
Calais
Generation:
VF Series
Model Years:
2013, 2014, 2015
Codes
Platform Code:
VF
👋 Introduction
Market Position
Vehicle Segment:
Full-size luxury sedan
Competitive Analysis
Competitors:
Ford Falcon, Toyota Camry (higher trims), Mitsubishi Magna (previous generations). The Calais represented the pinnacle of Holden's large sedan offerings, often competing with imported luxury brands in terms of features and comfort, while maintaining Australian engineering.
Key Features
Vehicle Strengths:
Spacious interior, powerful engine options, comfortable ride, premium appointments, strong performance from V8 variants, rear-wheel-drive platform.
Manual Value Proposition
Benefit To Owner:
Enables informed DIY maintenance and repairs, reduces reliance on costly dealership services, provides detailed technical knowledge for efficient troubleshooting and repair.
📋 Manual Details
Coverage Areas
Engine Variants:
3.0L V6 SIDI (LFW), 3.6L V6 LP Gas (LWR), 3.6L V6 SIDI (LFX), 6.0L V8 GEN-IV L77, 6.2L V8 Supercharged LSA, 6.2L V8 LS3
Transmission Variants:
6-Speed Automatic (6L45, 6L50, 6L80, 6L90), 6-Speed Manual (AISIN AY6, TREMEC TR6060)
Page Count
Total Pages:
> 11000
Manual Type
Type:
Workshop Service and Repair Manual
Language
Primary Language:
English
Format
Digital Format:
PDF Download
📖 Manual Coverage
Systems Covered
Powertrain:
Engine mechanical systems, fuel systems, ignition systems, cooling systems, lubrication, exhaust systems, engine management (SIDI, VVT), supercharger systems (LSA), automatic transmissions (6L45, 6L50, 6L80, 6L90), manual transmissions (AY6, TR6060), clutch systems.
Chassis:
Brake systems (ABS, hydraulic, disc, parking), steering systems (power steering, column), suspension systems (front, rear, electronic control), wheel and tire systems, wheel alignment.
Electrical And Electronics:
Engine starting and charging systems, lighting, wipers and washers, vehicle access, horns, mirrors, data communications, power outlets, infotainment, navigation, displays and gauges, secondary customer controls, theft deterrent, immobilizer, object detection, pedestrian protection, remote functions, supplementary inflatable restraints (airbags), seat and seat belts.
Body And Trim:
Body hardware, exterior trim, interior trim, instrument panel, console trim, floor coverings, headlinings, bolted exterior panels, bumper systems, collision repair, frame and underbody, paint and coatings, plastic panels, windows, sunroof.
Procedures Included
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, lubrication, inspections.
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), diagnostic procedures, wiring diagrams for troubleshooting.
Repair:
Detailed step-by-step repair instructions for all major systems, component removal and installation, adjustments, rebuild procedures.
Technical Depth
Depth:
Comprehensive coverage suitable for both DIY enthusiasts and professional mechanics, including detailed specifications, diagrams, and torque values.
📊 Manual Specifications
File Format
File Type:
PDF
File Size Mb:
795
Required Software:
Adobe Acrobat Reader, WinZip/WinRAR for extraction
Print Quality
Printability:
Printable individual pages as needed
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Quality:
N/A (Digital Download)
⚙️ Engine Specifications
Primary Engine
Default Engine:
3.0L V6 SIDI DOHC VVT (LFW)
Performance
3.0L V6 Lfw Horsepower:
235 PS (173 kW)
3.0L V6 Lfw Torque:
290 Nm (214 lb-ft)
3.6L V6 Lfx Horsepower:
274 PS (201 kW)
3.6L V6 Lfx Torque:
350 Nm (258 lb-ft)
6.0L V8 L77 Horsepower:
367 PS (270 kW)
6.0L V8 L77 Torque:
530 Nm (391 lb-ft)
6.2L V8 Ls3 Horsepower:
417 PS (307 kW)
6.2L V8 Ls3 Torque:
570 Nm (420 lb-ft)
6.2L V8 Lsa Horsepower:
582 PS (430 kW)
6.2L V8 Lsa Torque:
740 Nm (546 lb-ft)
Fuel System
Injection Type:
Sequential Fuel Injection (SFI) / Gasoline Direct Injection (GDI for SIDI variants)
Fuel Type:
Unleaded Petrol (Premium Unleaded recommended for performance variants), LPG (for LWR engine)
Engine Management
Vvt:
Variable Valve Timing (VVT) on all engines
Sidi:
Spark Ignition Direct Injection (SIDI) on 3.0L and 3.6L LFX engines
🔧 Transmission
Standard
Standard Transmission:
6-Speed Automatic (6L45/6L50 typically with V6, 6L80/6L90 with V8)
Optional
Optional Transmission:
6-Speed Manual Transmission (AISIN AY6 / TREMEC TR6060)
Features
Automatic Features:
Active Select (Driver Shift Control), adaptive shifting logic.
Manual Features:
Performance-oriented gear ratios, robust construction.
📐 Dimensions
Exterior
Length Mm:
Approx. 4985 mm
Width Mm:
Approx. 1898 mm
Height Mm:
Approx. 1471 mm
Wheelbase Mm:
Approx. 2939 mm
Weights
Kerb Weight Kg Range:
Approx. 1750 - 1900 kg (depending on engine and options)
🛡️ Safety Features
Ratings
Ancap Rating:
5-Star ANCAP Safety Rating (for VF Series)
Active Features
Driver Assistance:
Electronic Stability Control (ESC), Traction Control System (TCS), Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Brake Assist (BA).
Passive Features
Airbags:
Driver and front passenger airbags, front side airbags, curtain airbags (side impact protection).
Structure:
High-strength steel body structure, crumple zones.
💡 Technology Features
Infotainment
Infotainment System:
Holden MyLink infotainment system with touch screen, Bluetooth connectivity, Pandora/Stitcher integration (depending on model year and options).
Premium Audio Option:
Available premium audio systems (e.g., BOSE).
Driver Assistance
Advanced Features:
Reverse camera, parking sensors, Blind Spot Alert, Lane Departure Warning, Forward Collision Alert (availability varies by trim and options).
Connectivity
Connectivity Options:
USB ports, auxiliary input, Bluetooth hands-free calling and audio streaming.
🔧 Maintenance
Service Intervals
Oil Change Interval Km:
Typically 15,000 km or 12 months, whichever comes first (may vary based on driving conditions).
Major Service Points:
Spark plug replacement (e.g., 120,000 km), transmission fluid change (e.g., 100,000 km, consult manual), coolant flush (e.g., 160,000 km).
Fluid Specifications
Engine Oil Spec:
GM dexos1 GEN2 SAE 5W-30 (or equivalent meeting GM specification).
Transmission Fluid Auto:
GM DEXRON-VI (or equivalent meeting GM specification).
Coolant Type:
GM Super Coolant (Orange) or equivalent OAT (Organic Acid Technology) coolant.
Known Issues
Common Wear Items:
Ignition coils and spark plugs (especially on V6 engines), water pump seals, HVAC blend door actuators, power steering pump leaks (less common on electric power steering variants if applicable), front suspension bushings.
Electronic Quirks:
Infotainment system glitches, sensor failures (e.g., ABS sensors, camshaft/crankshaft position sensors).
📚 Vehicle History
Brand Heritage
Holden Legacy:
Holden, an Australian icon, has a long history of producing large, capable sedans for the Australian market, dating back to models like the Kingswood and Statesman.
Model Evolution
Vf Calais Positioning:
The VF Calais represented the flagship luxury variant of the Holden Commodore (which underpinned the Calais), building on the VE platform with significant updates to technology, refinement, and safety. It aimed to provide a premium Australian-made driving experience.
Production
Manufacturing Location:
Australia (Elizabeth, South Australia)
Production End Impact:
The VF Series marked one of the final generations of locally manufactured Holden vehicles before the closure of Australian manufacturing plants.
🏆 Awards & Recognition
Recognitions
Vehicle Acclaim:
While specific awards for the VF Calais can be numerous, the Holden Commodore platform itself consistently received praise from automotive journalists and consumer groups for its blend of performance, comfort, and value within its segment.
Ratings
Consumer Reviews:
Generally positive for its comfort and performance, particularly the V8 variants. Criticisms sometimes focused on fuel economy for V8 models or the premium feel compared to some European competitors.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
