Mitsubushi FTO 1997-2001 Workshop Service Repair Manual

Mitsubushi FTO 1997-2001 Workshop Service Repair Manual

$16.99
$16.99
İndirim Tükendi
Kargo, ödeme sayfasında hesaplanır.
Vehicle data plateRef 398351
Brand
Mitsubushi
Vehicle
Cars
Models covered
FTO, Mitsubishi
Years
1997, 1998, 1999, 2000, 2001
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
FTO
Generation:
DE2A/DE3A
Production Years:
1994-2000
Manual Coverage Years:
1997-2001
Codes
Chassis Code:
DE2A (2WD), DE3A (4WD/GR)
👋 Introduction
Market Position
Segment:
Compact sports coupe
Target Audience:
Enthusiasts, DIY mechanics, professional technicians working on Mitsubishi FTO models
Competitive Analysis
Competitors:
Toyota Celica, Honda Prelude, Nissan 200SX (S14), Mazda MX-6
Key Features
Unique Selling Points:
MIVEC V6 engine, unique styling, available Active Aerodynamics (Aero Series)
📋 Manual Details
Coverage Areas
Manual Type:
Workshop Service Repair Manual
Language:
English
Format:
Digital (likely PDF)
Included Engines:
2.0L 6A12 DOHC 24v V6 MIVEC
Included Transmissions:
5-Speed Manual (F5M42), 5-Speed Automatic (F5A42)
📖 Manual Coverage
Systems Covered
Powertrain:
Engine, Engine Lubrication, Fuel System, Engine Cooling, Intake and Exhaust, Engine Electrical, Engine and Emission Control, Clutch, Manual Transmission, Automatic Transmission, Power Plant Mount
Chassis:
Front Axle, Rear Axle, Wheel and Tire, Front Suspension, Rear Suspension, Service Brakes, Parking Brakes, Steering
Body And Comfort:
Body, Exterior and Interior, HVAC
Procedures Included
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs) interpretation, symptom-based diagnosis
Repair:
Component removal and installation, rebuilding procedures, adjustments, component testing
Specifications:
Torque values, clearances, fluid capacities, electrical diagrams, component dimensions
Technical Depth
Depth:
Comprehensive, covering from basic checks and maintenance to in-depth component repair and overhaul
📊 Manual Specifications
File Format
Digital Format:
Likely PDF, often searchable and printable
Print Quality
Quality:
High resolution for clear diagrams and text
Binding Type
Physical Binding:
N/A (digital format)
Paper Type
Physical Paper:
N/A (digital format)
⚙️ Engine Specifications
Primary Engine
Engine Code:
6A12
Configuration:
60-degree V6
Displacement:
1998 cc (2.0 Liters)
Valvetrain:
DOHC (Double Overhead Camshaft), 24 Valves
Aspiration:
Naturally Aspirated
Bore X Stroke:
78.4 mm x 69.0 mm
Compression Ratio:
10.0:1 (typical)
Power Output Ps:
200 PS @ 7000 rpm (approx. for MIVEC variants)
Torque Output Nm:
191 Nm @ 6000 rpm (approx. for MIVEC variants)
Performance
Mivec System:
Mitsubishi Innovative MIVEC (engine timing control system) for improved power and efficiency across the rev range.
Fuel System
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (95 RON recommended)
🔧 Transmission
Standard
Manual Transmission:
F5M42 (5-speed manual)
Optional
Automatic Transmission:
F5A42 (5-speed INVECS-II automatic with Sportronic shifter)
Features
Sportronic Shifter:
Allows manual gear selection in automatic mode.
Invecs-Ii:
Intelligent & Innovative Vehicle Electronic Control System, adapting shift patterns to driving style.
📐 Dimensions
Exterior
Length:
Approx. 4310 mm
Width:
Approx. 1740 mm
Height:
Approx. 1300 mm
Wheelbase:
Approx. 2500 mm
Weights
Curb Weight Kg:
Approx. 1300-1450 kg (depending on trim and drivetrain)
🛡️ Safety Features
Ratings
NHTSA Rating:
N/A (Vehicle predates widespread standardized testing by NHTSA)
Active Features
ABS:
Available on higher trims (e.g., GSR, RS-X)
Traction Control:
Available on some models (e.g., ECI-Multi/TCL)
Passive Features
Airbags:
Driver and passenger airbags available on later models/trims
Seatbelts:
3-point inertia reel seatbelts with pre-tensioners available on some models.
💡 Technology Features
Infotainment
Audio System:
Original systems typically featured AM/FM radio with cassette player and CD player options, often with basic speaker configurations.
Driver Assistance
Cruise Control:
Available on higher trim levels.
Connectivity
Connectivity Options:
Limited by era; no modern Bluetooth or USB integration in original factory setup.
🔧 Maintenance
Service Intervals
Oil Change:
Every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6-12 months, whichever comes first.
Air Filter Replacement:
Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on driving conditions.
Spark Plug Replacement:
Refer to manual, typically 30,000 - 60,000 miles (48,000 - 96,000 km) depending on plug type (e.g., iridium).
Fluid Specifications
Engine Oil:
API SG/SH/SJ, ACEA A2/A3, SAE 10W-30 or 10W-40 (check manual for exact viscosity and capacity, typically around 4.5 liters).
Coolant:
Mitsubishi Super Long Life Coolant (SLLC) or equivalent ethylene glycol based coolant with deionized water (50/50 mix), capacity ~7.5 liters.
Transmission Fluid Manual:
API GL-4, SAE 75W-90 or 75W-80 gear oil. Capacity ~2.1 liters for F5M42.
Transmission Fluid Automatic:
Mitsubishi DiaQueen ATF SP-II M or equivalent. Capacity ~7.3 liters (total fill, check manual for specific drain/refill amounts).
Brake Fluid:
DOT 3 or DOT 4.
Known Issues
Suspension Wear:
Front suspension components (bushings, ball joints) can wear over time, leading to knocking noises and poor handling.
Rusting:
Common in older vehicles, especially wheel arches, sills, and around windows.
Mivec Cam Phaser:
MIVEC system can sometimes develop issues, affecting performance and smooth running, often related to oil pressure or solenoids.
Automatic Transmission:
INVECS-II can sometimes be hesitant or fail to select gears correctly if not properly maintained; fluid changes are critical.
Air Conditioning:
HVAC systems can develop leaks or compressor issues common to many vehicles of this era.
Timing Belt:
Critical component; must be replaced at recommended intervals (typically 60,000 miles / 100,000 km) to prevent catastrophic engine damage.
📚 Vehicle History
Brand Heritage
Motorsport Connection:
Developed by Mitsubishi's performance division, with motorsport heritage influencing its design and engineering.
Model Evolution
Facelifts:
Received minor updates and cosmetic changes during its production run, including revised bumpers and interior trim.
Production
Manufacturing Location:
Japan
Key Markets:
Primarily Japan, with limited export to other markets (e.g., UK, Australia).
🏆 Awards & Recognition
Recognitions
Jdm Icon:
Recognized as a significant JDM (Japanese Domestic Market) sports coupe of its era, appreciated for its styling and performance.
Ratings
Customer Satisfaction:
Generally positive for performance and styling, but variable based on maintenance history and age.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
