Mitsubishi FTO Complete Workshop Service Repair Manual 1994 1995 1996 1997 1998

Mitsubishi FTO Complete Workshop Service Repair Manual 1994 1995 1996 1997 1998

$16.99
$16.99
İndirim Tükendi
Kargo, ödeme sayfasında hesaplanır.
Vehicle data plateRef 452705
Brand
Mitsubishi
Vehicle
Cars
Models covered
FTO
Years
1994, 1995, 1996, 1997, 1998
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
FTO
Model Code:
DE Series
Generation
Generation Name:
First Generation
Generation Years:
1994-2000
Codes
Chassis Codes:
DE2A, DE3A
👋 Introduction
Market Position
Segment:
Compact Sports Coupe
Target Audience:
Enthusiasts seeking performance and distinctive styling, owners performing DIY maintenance and repairs
Competitive Analysis
Competitors:
Toyota Celica GT-Four, Honda Prelude, Nissan Silvia S13/S14, Mazda MX-6
Key Features
Unique Selling Points:
Distinctive 'cab-forward' design, V6 engine options, INVECS-II transmission with G-SENSOREngine and transmission technology, lightweight chassis
Manual Value Proposition
Diy Savings:
Enables owners to perform extensive repairs and maintenance, saving significant labor costs
Information Access:
Provides access to factory-level repair data and procedures
📋 Manual Details
Coverage Areas
Years Covered:
1994, 1995, 1996, 1997, 1998
Models Covered:
All FTO models, engines, trims, and transmission types
Page Count
Page Count Estimate:
Comprehensive (exact number not provided, but stated to cover all procedures A-Z)
Manual Type
Manual Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
Digital Downloadable (PDF)
File Format
File Type:
PDF
Searchability:
Searchable text content (typical for well-produced PDFs)
Print Quality
Print Capability:
Printable page by page or entire manual
Binding Type
Binding Type:
N/A (Digital)
Paper Type
Paper Type:
N/A (Digital)
📖 Manual Coverage
Systems Covered
Engine:
Engine mechanical, cooling system, lubrication system, fuel system, ignition system, emissions control
Transmission:
Manual transmission, INVECS-II Automatic transmission (including Sports Mode/Tiptronic functionality)
Drivetrain:
Driveshafts, differentials, axles
Suspension:
Front suspension (MacPherson strut), Rear suspension (Multi-link), steering system, wheel alignment
Brakes:
Front and rear brake systems (disc brakes), ABS (Anti-lock Braking System)
Electrical:
Battery, charging system, starting system, lighting, instrumentation, power windows, mirrors, central locking, SRS airbag system
Body:
Body panels, doors, hood, trunk, interior trim, glass, body sealing
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) system
Fuel And Emissions:
Fuel tank, fuel pump, fuel injectors, EVAP system, catalytic converter
Procedures Included
Routine Maintenance:
Oil and filter changes, fluid checks and replacements, spark plug replacement, air filter replacement, brake pad replacement
Troubleshooting:
Diagnostic procedures for common faults, wiring diagrams, electrical component testing
Major Repairs:
Engine overhaul, transmission overhaul, suspension component replacement, brake system overhauls, electrical system repairs
Component Rebuilds:
Detailed instructions for rebuilding major components like engines, transmissions, and alternators
Diagnostics:
Step-by-step diagnostic guides for identifying and resolving issues
Technical Depth
Depth:
Comprehensive from basic maintenance to in-depth engine and transmission rebuilds, including electrical diagnostics and troubleshooting
Diagnostics Level:
Advanced, including detailed wiring diagrams and component testing procedures
Rebuild Scope:
Full engine and transmission rebuild procedures with specifications
⚙️ Engine Specifications
Primary Engine
Engine Code 1:
6A12
Engine Type 1:
2.0L V6 SOHC MIVEC
Displacement 1:
1998 cc
Power 1:
168 bhp (125 kW) @ 7000 rpm (non-MIVEC), 200 bhp (147 kW) @ 7500 rpm (MIVEC)
Torque 1:
130 lb-ft (176 Nm) (non-MIVEC), 145 lb-ft (197 Nm) (MIVEC)
Secondary Engine
Engine Code 2:
6A13
Engine Type 2:
2.5L V6 SOHC
Displacement 2:
2498 cc
Power 2:
170 PS (125 kW; 168 hp)
Torque 2:
220 Nm (162 lb-ft)
Performance
Engine Configuration:
90-degree V6
Valvetrain:
SOHC 24-valve (MIVEC on some 2.0L variants)
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline
Cooling System
Cooling Type:
Water-cooled
🔧 Transmission
Standard
Transmission Type Standard:
5-speed Manual
Optional
Transmission Type Optional:
4-speed INVECS-II Automatic (with Sportronic/Tiptronic sequential shifting)
Features
Transmission Features:
Electronically controlled transmission, adaptive shift patterns (INVECS-II), limited-slip differential (LSD) available on certain sport trims
📐 Dimensions
Exterior
Length:
4310 mm (169.7 in)
Width:
1720 mm (67.7 in)
Height:
1290 mm (50.8 in)
Wheelbase:
2500 mm (98.4 in)
Weights
Curb Weight Approx:
1310 kg (2888 lb) for 2.0L models, 1340 kg (2954 lb) for 2.5L models
🛡️ Safety Features
Ratings
Safety Ratings:
N/A (Industry standards of the time, likely no specific crash test ratings available comparable to modern standards)
Active Features
Active Safety:
ABS (Anti-lock Braking System), Limited-slip Differential (LSD) on select models
Passive Features
Passive Safety:
SRS Airbag system (driver's side standard, passenger optional on some models), crumple zones, reinforced passenger cell
💡 Technology Features
Infotainment
Infotainment System:
Factory fitted AM/FM stereo radio with cassette player and CD player (optional), basic climate controls.
Driver Assistance
Driver Assistance Features:
ABS (Anti-lock Braking System), INVECS-II Sportronic transmission with G-SENSOR for adaptive shifting.
Connectivity
Connectivity Features:
Basic power accessories (windows, mirrors), central locking.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 7,500 miles (12,000 km) or 6 months, whichever comes first (typical recommendation)
Transmission Fluid Interval:
Every 30,000 miles (48,000 km) or 24 months (typical recommendation for automatic)
Spark Plug Replacement:
Refer to manual for specific intervals based on engine and plug type (e.g., 60,000-100,000 miles for iridium plugs)
Fluid Specifications
Engine Oil Type:
API SG/SH or ACEA A2/A3, Viscosity: 5W-30 or 10W-30 (refer to manual for exact specification)
Coolant Type:
Mitsubishi Super Long Life Coolant (or equivalent ethylene glycol-based antifreeze/coolant with corrosion inhibitors)
Transmission Fluid Automatic:
DIA Queen ATF-SP III (or equivalent Dexron III/Mercon compatible fluid)
Transmission Fluid Manual:
API GL-4, SAE 75W-90 or 75W-85 gear oil
Brake Fluid:
DOT 3 or DOT 4 brake fluid
Known Issues
Engine Mounts:
Degradation of engine mounts over time, leading to increased vibration and noise
Suspension Components:
Wear in bushings, ball joints, and tie rod ends due to age and mileage
Fuel Pump:
Occasional failure of the fuel pump, especially on higher mileage vehicles
Mivec Actuator:
Potential issues with the MIVEC actuator or solenoid on 2.0L MIVEC engines, affecting performance
Rust:
Susceptibility to rust, particularly around wheel arches, sills, and the underside, common in certain climates
📚 Vehicle History
Brand Heritage
Brand Focus:
Mitsubishi Motors has a long history in motorsport and performance vehicle development, including rally cars.
Model Evolution
Model Introduction:
The Mitsubishi FTO (Fresh Touring Original) was launched in late 1994 in Japan as a sports coupe, positioned above the Lancer.
Design Inspiration:
The design was influenced by Mitsubishi's FTO concept cars and aimed to compete in the personal luxury/sport coupe segment.
Facelifts:
Received a significant facelift in 1997, featuring revised front and rear bumpers, side skirts, and updated interior trim.
Production
Production Period:
1994-2000
Production Location:
Japan
Motorsport
Motorsport Heritage:
The FTO was notably successful in Japanese Grand Touring Championship (JGTC) and other racing series, demonstrating its performance capabilities.
🏆 Awards & Recognition
Recognitions
Automotive Journalism Awards:
Voted Japanese Car of the Year for 1994-1995.
Motorsport Awards:
Multiple victories and championships in JGTC racing.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.

Tüm ayrıntıları görüntüle
  • Instant download Link on the order page and in your inbox within a minute.
  • Secure checkout Encrypted Shopify payments — card, PayPal, Apple Pay, Google Pay.
  • Print-ready PDF Searchable text; print only the pages you take to the bench.
  • Coverage check Not sure it fits? Send the model and VIN before you buy.
