Mitsubishi Mirage 2012-2016 Workshop Repair Service Manual

Mitsubishi Mirage 2012-2016 Workshop Repair Service Manual

$17.99
$17.99
Em promoção Esgotado
Envio calculado na finalização da compra.
Vehicle data plateRef 479550
Brand
Mitsubishi
Vehicle
Cars
Models covered
Mirage
Years
2012, 2013, 2014, 2015, 2016
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Mirage
Model Years Covered:
2012, 2013, 2014, 2015, 2016
Generation
Generation Identifier:
A00 series (Global/Sixth Generation)
Codes
Chassis Codes:
A00A, A03A
👋 Introduction
Market Position
Vehicle Segment:
Subcompact Hatchback/Sedan
Target Audience:
Budget-conscious consumers, first-time car buyers, urban commuters
Competitive Analysis
Key Competitors:
Honda Fit, Toyota Yaris, Nissan Versa, Ford Fiesta, Chevrolet Sonic
Key Features
Vehicle Selling Points:
Fuel efficiency, affordability, compact size, maneuverability, practicality
Manual Value Proposition:
Empowers owners to perform maintenance and repairs, saving significant costs compared to professional labor
📋 Manual Details
Coverage Areas
Regions Covered:
Global
Model Variants Covered:
All Models, All Engines, All Trim Levels, All Transmission Types
Page Count
Estimated Page Count:
Hundreds (specific count not provided but described as extensive)
Manual Type
Manual Type:
Workshop Repair Service Manual
Language
Language:
English
Format
File Format:
PDF
Delivery Method:
Instant Download
📖 Manual Coverage
Systems Covered
Engine Service Repair:
Comprehensive engine diagnostics, repair, overhaul, and maintenance
Transmission Service Repair:
Detailed procedures for both manual and automatic transmission systems
Brake System:
Service and repair for ABS, hydraulic systems, calipers, rotors, pads, and parking brake
Electrical System:
Complete diagnosis, repair, and troubleshooting of all electrical components and circuits
Wiring Diagrams:
Detailed, comprehensive wiring schematics for all vehicle systems
Suspension:
Repair and replacement of struts, shocks, springs, control arms, and alignment procedures
Steering:
Service for power steering systems, steering columns, and linkages
Cooling System:
Maintenance and repair of radiator, coolant, water pump, and thermostat
Fuel Injection Fuel System:
Diagnosis and repair of fuel pump, injectors, fuel lines, and fuel tank
Emission System:
Troubleshooting and repair of emissions control components and systems
Heater Air Conditioning:
Service and repair for HVAC system, refrigerant, compressor, and climate control
Engine Control System:
Diagnosis and repair of ECU, sensors, actuators, and engine management
Chassis Body:
Body repair, frame alignment, and chassis component service
Restraint System:
Service for airbags, seatbelts, and related safety components
Interior:
Trim removal, component replacement, and interior systems service
Differential Drive:
Service and repair of drivetrain components including differentials
Axle:
Service and repair of front and rear axles and CV joints
General Maintenance:
Regular maintenance procedures and schedules
Periodic Lubrication:
Lubrication points and specifications
Procedures Included
Troubleshooting:
Extensive troubleshooting guides for common and uncommon issues
Repair Procedures:
Detailed step-by-step repair instructions with numbered steps
Disassembly Assembly:
Component disassembly and reassembly instructions
Cleaning Reinstalling:
Procedures for cleaning and reinstalling parts
Diagnostic Procedures:
Comprehensive diagnostic procedures for various systems
Technical Depth
Depth Of Information:
Professional-level technical information used by local service/repair shops
Detail Level:
Detailed substeps, notes, cautions, and warnings for critical information
Illustration Quality:
Detailed illustrations, drawings, photos, and enlarged inset views
📊 Manual Specifications
File Format
PDF Quality:
High quality, zoomable and searchable (implied by PDF format and capabilities)
Print Quality
Printability:
Full Printable
Binding Type
Binding:
N/A (Digital PDF download)
Paper Type
Paper Type:
N/A (Digital PDF download)
Requirements
Software Requirements:
Adobe PDF Reader, WinZip
Operating System Compatibility:
All Versions of Windows & Mac
⚙️ Engine Specifications
Primary Engine
Engine Type:
Inline 3-cylinder, naturally aspirated
Engine Displacement:
1.0 L (999 cc)
Engine Code:
3A90 (MIVEC)
Performance
Horsepower Output:
Approx. 74-78 hp @ 6000 rpm (market dependent)
Torque Output:
Approx. 60-65 lb-ft (81-88 Nm) @ 4000 rpm (market dependent)
Fuel System
Fuel Delivery:
Multi-point Fuel Injection (MPI) or Port Injection
Fuel Type:
Unleaded gasoline
Emission Controls:
MIVEC (Mitsubishi Innovative Valve timing Electronic Control system)
🔧 Transmission
Standard
Standard Transmission:
5-speed manual transmission
Optional
Optional Transmission:
Continuously Variable Transmission (CVT) (market dependent, often designated with 'INVECS-III')
Features
Transmission Features:
Designed for fuel efficiency
📐 Dimensions
Exterior
Length:
Approx. 3710-3770 mm (146.1-148.4 inches)
Width:
Approx. 1665 mm (65.6 inches)
Height:
Approx. 1490-1515 mm (58.7-59.6 inches)
Wheelbase:
Approx. 2450 mm (96.5 inches)
Weights
Curb Weight:
Approx. 830-940 kg (1829-2072 lbs) (model and trim dependent)
🛡️ Safety Features
Ratings
Safety Certifications:
Varies by market and testing agency (e.g., NHTSA, Euro NCAP, IIHS). Manual covers restraint system repairs.
Active Features
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Traction Control (TCL), Electronic Stability Control (ESC) (market and trim dependent)
Passive Features
Passive Safety Features:
Front airbags, side airbags, curtain airbags, seatbelt pretensioners, ISOFIX child seat anchors
💡 Technology Features
Infotainment
Infotainment Features:
Basic infotainment systems, often including AM/FM radio, CD player, and optional USB/auxiliary inputs. Higher trims may offer Bluetooth and basic touchscreen displays.
Driver Assistance
Driver Assistance Features:
Limited driver assistance features on base models; higher trims may offer parking sensors or rearview cameras (market dependent).
Connectivity
Connectivity Options:
Bluetooth for hands-free calling and audio streaming (on equipped models), USB and auxiliary audio inputs.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6-12 months, depending on driving conditions. Specifics detailed in manual.
Air Filter Replacement:
Generally every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection. Specifics detailed in manual.
Spark Plug Replacement:
Typically around 60,000 - 100,000 miles (96,000 - 160,000 km) for iridium-type plugs. Specifics detailed in manual.
Fluid Specifications
Engine Oil Type:
Likely SAE 0W-20 synthetic oil (refer to manual for precise specification and capacity)
Transmission Fluid Type Manual:
API GL-4 SAE 75W-85 or similar (refer to manual for precise specification and capacity)
Transmission Fluid Type Cvt:
Specific CVT Fluid (e.g., J1 or equivalent - refer to manual for precise specification and capacity)
Coolant Type:
Durable Coolant (long-life, typically pink or red ethylene glycol based - refer to manual for precise specification and capacity)
Known Issues
Common Wear Items:
Brake pads/rotors, tires, suspension components (due to vehicle's lightweight nature and typical usage), battery
Potential Electrical Issues:
Some reports of minor electrical glitches, which this manual's detailed wiring diagrams will address.
📚 Vehicle History
Brand Heritage
Mitsubishi Heritage:
Mitsubishi Motors Corporation (MMC) is a Japanese multinational automotive manufacturer with a long history of producing reliable and innovative vehicles.
Model Evolution
Mirage Lineage:
The Mirage nameplate has been used by Mitsubishi for various models since the 1970s. This 2012-2016 model represents the global reintroduction and sixth generation of the Mirage, focusing on efficiency and affordability.
Production
Production Location:
Primarily manufactured in Thailand at the Mitsubishi Motors (Thailand) Co., Ltd. plant.
🏆 Awards & Recognition
Recognitions
Fuel Economy Awards:
Often recognized for its segment-leading fuel efficiency in various automotive publications and by EPA ratings.
