Mitsubishi Carisma 1996 1997 1998 1999 -2003 Service Repair Manual

Mitsubishi Carisma 1996 1997 1998 1999 -2003 Service Repair Manual

$16.99
$16.99
Em promoção Esgotado
Envio calculado na finalização da compra.
Vehicle data plateRef 367344
Brand
Mitsubishi
Vehicle
Cars
Models covered
Carisma
Years
1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Carisma
Model Years Covered:
1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Chassis Codes:
DA1A, DA2A, DA5A, DA6A
Codes
Platform:
Mitsubishi Space Star/Carisma platform (shared with Volvo S40/V40)
👋 Introduction
Market Position
Segment:
Compact family car
Target Audience:
Families, commuters seeking practicality and reliability
Competitive Analysis
Key Competitors:
Ford Focus, Volkswagen Golf, Vauxhall/Opel Astra, Peugeot 306, Renault Mégane
Key Features
Design Philosophy:
European design influence (collaboration with Netherlands Design Centre), emphasis on comfort and practicality.
Platform Sharing:
Shared platform with Volvo S40/V40, indicating robust engineering and safety focus.
📋 Manual Details
Coverage Areas
Manual Type:
Official Factory Service Repair Shop Manual
Language:
English
Format:
Digital PDF Download
Page Count
Estimated Page Count:
Varies by specific engine/transmission, but typically over 1000 pages for a comprehensive factory manual
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Disassembly, assembly, inspection, repair of all engine components (pistons, rings, bearings, crankshaft, camshaft, valves, timing system)
Engine Management:
Fuel injection systems, ignition systems, emissions control systems, sensors, actuators, ECU diagnostics
Transmission Manual:
Clutch, gearbox disassembly, assembly, repair, shift mechanism
Transmission Automatic:
Automatic transmission disassembly, assembly, repair, hydraulic control, torque converter
Suspension:
Front and rear suspension components, struts, shocks, bushings, alignment specifications
Steering:
Power steering system, steering rack, tie rods, steering column
Brakes:
Hydraulic system, ABS (if equipped), brake pads, rotors, calipers, lines, bleeding procedures
Electrical System:
Wiring diagrams, component locations, fuse/relay box diagrams, starter, alternator, battery, lighting, accessories
Body And Chassis:
Body panel removal/installation, interior trim, glass, doors, bumpers, chassis structural information
Heating Ventilation And Air Conditioning:
HVAC system components, refrigerant, diagnosis, repair
Procedures Included
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection
Troubleshooting:
Diagnostic procedures for common issues, fault codes, symptom-based troubleshooting
Engine Rebuild:
Detailed steps for major engine overhaul and component replacement
Transmission Overhaul:
Comprehensive procedures for rebuilding both manual and automatic transmissions
Brake System Repair:
Component replacement, bleeding, ABS diagnostics
Electrical Component Replacement:
Diagnosing and replacing electrical parts like sensors, actuators, and modules
Bodywork And Collision Repair:
Information on body panel alignment and repair
Suspension And Steering Repair:
Replacement of ball joints, tie rods, shocks, struts
Technical Depth
Depth Of Information:
Comprehensive: Covers everything from basic maintenance to complete rebuilds and advanced diagnostics.
Oem Specifications:
Includes torque specifications, fuel pressure charts, electrical data, compression ranges, tolerances, OEM part number references, paint codes.
Diagrams And Illustrations:
Features exploded diagrams, charts, and photographs to aid in disassembly and reassembly.
📊 Manual Specifications
File Format
File Type:
PDF
Searchability:
Typically searchable PDF text
Print Quality
Printable:
Yes
Print Format:
Printable page-by-page for taking to service locations or for reference
Binding Type
Binding:
Digital Download (no physical binding)
Paper Type
Paper Type:
Not Applicable (Digital)
⚙️ Engine Specifications
Primary Engine
Engine Codes:
4G92 (1.6L), 4G93 (1.8L SOHC/DOHC), 4G63 (2.0L DOHC), 6A12 (2.5L V6)
1.6L (4G92) Specs:
Approx. 90-100 hp, 1.6-liter inline-4, SOHC
1.8L (4G93) Specs:
Approx. 113-125 hp (SOHC), 140 hp (DOHC GDI), 1.8-liter inline-4
2.0L (4G63) Specs:
Approx. 130-150 hp, 2.0-liter inline-4, DOHC
2.5L V6 (6A12) Specs:
Approx. 160-170 hp, 2.5-liter V6, SOHC
Performance
Fuel Delivery:
Multi-point Fuel Injection (MPI), Gasoline Direct Injection (GDI) on some 1.8L models
Fuel Type:
Unleaded gasoline
Fuel System
Fuel Pressure:
Specific values provided in manual (e.g., ~3 bar for MPI systems)
🔧 Transmission
Standard
Gearbox Options:
5-speed manual, 4-speed automatic
Optional
Transmission Type:
4-speed INVECS-II automatic transmission
Features
Manual Transmission Fluid:
API GL-3 or GL-4, SAE 75W-90 or 80W-90 (specific part numbers in manual)
Automatic Transmission Fluid:
DIA Queen ATF-SP II M or equivalent (specific part numbers in manual)
📐 Dimensions
Exterior
Length:
Approximately 4510 mm (177.6 in) for sedan, 4350 mm (171.3 in) for hatchback
Width:
Approximately 1730 mm (68.1 in)
Height:
Approximately 1405-1430 mm (55.3-56.3 in)
Weights
Curb Weight:
Approximately 1100-1350 kg (2425-2976 lbs) depending on engine and equipment
Gross Vehicle Weight Rating:
Specific values vary by model and are detailed in the manual
🛡️ Safety Features
Ratings
Euro Ncap Rating:
Achieved 3 stars in 1997 Euro NCAP testing (for the sedan variant).
Active Features
ABS:
Available as an option on many models.
Passive Features
Airbags:
Driver and passenger airbags available, side airbags optional on some later models.
Seatbelts:
Pre-tensioning front seatbelts
💡 Technology Features
Infotainment
Audio System:
Factory fitted radio/cassette or CD player, often with speakers in front and rear doors.
Climate Control:
Manual or automatic climate control available on higher trims.
Driver Assistance
Cruise Control:
Available on some models and trims.
Connectivity
Parking Sensors:
Not a standard feature, but aftermarket options were common.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 10,000 miles or 12 months, or as per manufacturer recommendations in the manual.
Timing Belt Replacement:
Crucial for non-interference engines. Interval typically around 60,000-90,000 miles or 5-7 years. Specifics for each engine variant are in the manual.
Fluid Specifications
Engine Oil Type:
API SJ or higher, viscosity typically 10W-40 or 5W-30 (refer to manual for specific engine and climate recommendations).
Coolant:
Ethylene glycol based coolant with corrosion inhibitors, typically a 50/50 mix with distilled water.
Brake Fluid:
DOT 3 or DOT 4 (refer to manual for exact specification).
Known Issues
Common Problems:
Early models could experience some electrical gremlins, exhaust manifold cracks on some 1.8L models, and wear on suspension bushings. Clutch wear on manual transmissions.
Engine Specific Notes:
4G93 GDI engines may require specific maintenance due to direct injection technology.
📚 Vehicle History
Brand Heritage
Mitsubishi History:
Mitsubishi Motors Corporation, a Japanese multinational automotive manufacturer with a long history of innovation and diverse vehicle production.
Model Evolution
Carisma Development:
Developed in collaboration with Volvo, sharing the platform with the Volvo S40/V40. Designed with a focus on European market tastes and standards.
Production
Production Period:
1995-2005 (Globally), with this manual covering 1996-2003.
Manufacturing Locations:
Primarily produced in Born, Netherlands (NedCar factory), and also in Japan.
🏆 Awards & Recognition
Recognitions
Industry Awards:
While not receiving specific major 'awards' in the traditional sense, the Carisma was generally well-regarded for its practicality, comfort, and value for money in its segment.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
