FIAT 125P 1967-1991 Service Repair Manual

FIAT 125P 1967-1991 Service Repair Manual

$16.99
$16.99
Em promoção Esgotado
Envio calculado na finalização da compra.
Vehicle data plateRef 198307
Brand
Fiat
Vehicle
Cars
Models covered
125P
Years
1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Fiat
Model:
125P
Year:
1967-1991
Codes
Chassis Code:
125P (Polish version of Fiat 125)
👋 Introduction
Market Position
Target Audience:
Car owners with basic mechanical skills and independent auto service professionals.
Competitive Analysis
Value Proposition:
Provides the same specifications and procedures as authorized dealer service departments, enabling informed discussions with technicians and empowering DIY repairs.
Key Features
Accessibility:
Instant download upon payment, eliminating shipping costs and waiting times.
Usability:
Printable pages allow for clean working copies, preserving the original digital file.
📋 Manual Details
Coverage Areas
Engines Covered:
1.3L and 1.5L
Production Years Covered:
1967-1991
Page Count
Estimated Page Count:
Extensive (detailed coverage implies significant page count, specific number not provided)
Manual Type
Type:
Service and Repair Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine Service:
Engine service and overhauling, induction, emission control, fuel system
Drivetrain:
Transmission, differentials
Chassis And Body:
Chassis, body, steering and suspension, brakes, ABS
Electrical:
Wiring diagrams, control system
Fuel System:
Fuel tank, fuel pump, fuel lines, carburetor maintenance and adjustment.
Emission Control:
Information on emission control systems pertinent to the era, including PCV systems.
Procedures Included
Diagnostic Procedures:
Troubleshooting and diagnostics, diagnosing engine fault symptoms, testing suspected parts
Repair Procedures:
Engine overhauling, transmission repair, chassis repair, bodywork repair, brake system repair, suspension adjustments, steering system service
Maintenance Procedures:
Routine maintenance, fluid checks and changes, component servicing
Wiring Diagram Analysis:
Detailed wiring diagrams with specific terminal pin connections and expected readings for tracing and verification.
Mechanic Interaction:
Guidance for owners to understand repairs, communicate effectively with mechanics, and verify work performed.
Technical Depth
Depth:
Comprehensive, including specifications, torque settings, and detailed procedures suitable for owners with basic mechanical skills and independent professionals.
Engine Management:
Understanding and analysis of different engine management systems of the period.
Component Testing:
Techniques for testing suspected parts, including specific diagnostic methods.
📊 Manual Specifications
File Format
Readability:
Viewable on PC, Mac, and various devices including phones and ebook readers.
Printability:
Print individual pages as needed.
Searchability:
PDF format allows for text searching, improving efficiency in finding information.
Binding Type
Type:
Digital (PDF format)
Paper Type
Type:
N/A (Digital)
⚙️ Engine Specifications
Primary Engine
Displacement:
1.3 Liters (1295 cc) and 1.5 Liters (1481 cc)
Engine Type
Configuration:
Inline-four cylinder, OHV (Overhead Valve)
Performance
Horsepower Range:
Approximately 60-75 HP (depending on variant and tuning)
Torque Range:
Approximately 90-110 Nm (depending on variant)
Fuel System
Carburetion:
Single or Twin Weber carburetors (specific models vary)
Cooling System
Type:
Water-cooled
Ignition System
Type:
Distributor-based ignition system
Block Material
Material:
Cast iron
Head Material
Material:
Aluminum alloy
🔧 Transmission
Standard
Type:
4-speed manual transmission
Optional
Type:
5-speed manual transmission (on some later models)
Features
Drive Layout:
Rear-wheel drive
Fluid Type
Recommendation:
Refer to manual for specific GL-4 rated gear oil (e.g., SAE 75W-90 or 80W-90)
Clutch Type
Type:
Single dry plate, diaphragm spring
📐 Dimensions
Exterior
Body Styles:
4-door sedan, 5-door station wagon (Kombi)
Length:
Approx. 4250 mm (sedan)
Width:
Approx. 1620 mm (sedan)
Height:
Approx. 1440 mm (sedan)
Weights
Curb Weight:
Approx. 1100-1250 kg (depending on body style and engine)
Gross Vehicle Weight:
Refer to manual for specific ratings
Wheelbase
Length:
Approx. 2740 mm
Wheels And Tires
Wheel Bolt Pattern:
4x150mm
Tire Sizes:
Commonly 165/80 R13 or similar (refer to manual for exact specifications)
🛡️ Safety Features
Ratings
Crash Safety:
Designed to mid-1960s to early 1990s safety standards. Refer to manual for specific structural details.
Active Features
Brakes:
Front disc brakes, rear drum brakes. ABS not standard on most models.
Passive Features
Seatbelts:
Provision for seatbelts, likely lap belts in front and rear on earlier models, 3-point on later models.
💡 Technology Features
Infotainment
Audio System:
Factory fitted analog radio (AM/FM) on most models. Aftermarket upgrades common.
Driver Assistance
Features:
Limited; ABS was not standard and very rare. Focus is on mechanical systems.
Connectivity
Features:
N/A (pre-digital era).
🔧 Maintenance
Service Intervals
Oil Change:
Typically every 5,000 - 7,500 km or 6 months (refer to manual for specific recommendation).
Tune Up:
Spark plugs, points, condenser, and timing adjustments recommended annually or every 10,000-15,000 km.
Fluid Specifications
Engine Oil:
Refer to manual; typically SAE 20W-50 or 10W-40 for gasoline engines (API SG or similar).
Coolant:
Ethylene glycol based coolant, typically 50/50 mix with distilled water.
Brake Fluid:
DOT 3 or DOT 4 brake fluid (refer to manual for specific type and replacement interval).
Coolant Capacity:
Approx. 7-8 liters (refer to manual for exact capacity)
Known Issues
Common Problems:
Rust and corrosion, ignition system reliability, carburetor tuning, exhaust system wear, clutch wear, steering and suspension component wear.
Electrical System:
Older wiring harnesses can degrade; manual provides wiring diagrams for diagnosis.
Common Fixes
Troubleshooting Advice:
Manual provides guidance on diagnosing common symptoms like no-starts, hesitations, and stalling, along with practical quick solutions.
📚 Vehicle History
Brand Heritage
Manufacturer:
Fiat (Italy) / FSO (Poland)
Model Evolution
Basis:
Based on the Fiat 125 platform, but significantly adapted and produced under license by FSO (Fabryka Samochodów Osobowych) in Poland.
Significance:
The FSO 125p was a cornerstone of Polish automotive industry for decades, representing a robust and practical vehicle.
Production
Production Period:
1967-1991
Manufacturing Location:
Warsaw, Poland
