Ssangyong

SsangYong Actyon Sport Complete Workshop Service Repair Manual 2006 2007 2008 2009 2010 2011

SsangYong Actyon Sport Complete Workshop Service Repair Manual 2006 2007 2008 2009 2010 2011

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 453446
Brand
Ssangyong
Vehicle
Truck
Models covered
Actyon, Actyon Sport
Years
2006, 2007, 2008, 2009, 2010, 2011
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
SsangYong
Model:
Actyon Sport
Generation:
First Generation
Production Years Covered:
2006, 2007, 2008, 2009, 2010, 2011
Codes
Platform Code:
Q200 (based on Actyon SUV platform)
👋 Introduction
Market Position
Segment:
Compact Pickup Truck / Utility Vehicle
Target Audience:
Individuals and businesses requiring robust utility and off-road capability, often positioned as a more affordable alternative in its segment.
Competitive Analysis
Competitors:
Key competitors in the compact pickup segment included models like the Mitsubishi L200 (Triton), Isuzu D-Max, Toyota Hilux, Ford Ranger (depending on market availability and generation).
Key Features
Design:
Distinctive styling, often characterized by SUV-like front-end design and a separate pickup bed, offering a blend of passenger comfort and cargo utility.
Capability:
Known for its rugged build and often featuring selectable 4WD systems, providing good off-road and towing capabilities for its class.
📋 Manual Details
Coverage Areas
Coverage:
All repair and service procedures A-Z, All Models/Engines/Trim/Transmissions Types
Page Count
Page Count:
Not Specified (typically extensive for a complete workshop manual)
Manual Type
Type:
Complete Workshop Service Repair Manual
Language
Language:
English (implied by product description and target market)
Format
Format:
Downloadable Digital Format (PDF or similar, compatible with PC, MAC, tablets, smartphones)
📖 Manual Coverage
Systems Covered
Engine:
Engine overhaul, diagnostics, repair, maintenance, cooling system, fuel system, lubrication system, ignition system, emission control systems.
Transmission:
Manual and Automatic transmission repair, diagnostics, clutch, gearbox components, torque converter, transmission control module (TCM).
Drivetrain:
Front-wheel drive (FWD), Rear-wheel drive (RWD), Four-wheel drive (4WD/AWD) system repair, differential, driveshafts, axles, transfer case.
Suspension:
Front and rear suspension components, shock absorbers, springs, control arms, bushings, wheel alignment procedures.
Steering:
Power steering system repair, steering rack, steering column, hydraulic pump, steering linkage.
Brakes:
Brake system diagnostics, repair, ABS (Anti-lock Braking System), brake pads, rotors, calipers, brake lines, parking brake.
Electrical System:
Wiring diagrams, starter, alternator, battery, lighting system, power windows, central locking, fuses, relays, body control module (BCM).
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) system diagnosis and repair, refrigerant, compressor, evaporator, heater core.
Body And Chassis:
Body panel repair, doors, hood, tailgate, interior trim, frame diagnosis and repair, underbody protection.
Procedures Included
Maintenance:
Routine maintenance (oil changes, filter replacements, fluid checks), scheduled maintenance intervals, lubrication.
Diagnostics:
Troubleshooting guides, fault code interpretation, diagnostic procedures for all major systems.
Repair:
Step-by-step repair instructions for all vehicle components, component removal and installation.
Rebuilding:
Engine rebuilding procedures, transmission overhaul, component rebuilding specifications.
Technical Specifications:
Torque specifications, clearances, fluid capacities, electrical values, diagnostic parameters.
Technical Depth
Depth:
Comprehensive, covering basic to advanced repair and diagnostic procedures, suitable for professional technicians and experienced DIY enthusiasts.
📊 Manual Specifications
File Format
File Type:
PDF (Portable Document Format) or similar, optimized for digital viewing and printing.
Print Quality
Printability:
High-quality, allowing individual pages or chapters to be printed for workshop use.
Binding Type
Binding:
N/A (Digital format, binding is user's choice upon printing)
Paper Type
Paper Quality:
N/A (Digital format, paper type is user's choice upon printing)
⚙️ Engine Specifications
Primary Engine
Engine Family:
SsangYong D-Series (e.g., D20DT, D27DT, D27Y)
Displacement Petrol:
2.3L (e.g., G23D inline-4, Mercedes-Benz M111 based)
Displacement Diesel:
2.0L, 2.7L Turbocharged (e.g., XDi common rail diesel)
Performance Petrol
Horsepower 2.3L:
Approx. 150 PS (110 kW) @ 5500 rpm (Varies by specific variant)
Torque 2.3L:
Approx. 215 Nm (159 lb-ft) @ 4000 rpm (Varies by specific variant)
Performance Diesel
Horsepower 2.0L Diesel:
Approx. 145 PS (107 kW) @ 4000 rpm (e.g., D20DT)
Torque 2.0L Diesel:
Approx. 310 Nm (229 lb-ft) @ 1800-2700 rpm (e.g., D20DT)
Horsepower 2.7L Diesel:
Approx. 165 PS (121 kW) @ 4000 rpm (e.g., D27DT)
Torque 2.7L Diesel:
Approx. 340 Nm (251 lb-ft) @ 1800-3000 rpm (e.g., D27DT)
Fuel System
Petrol Injection:
Multi-point Fuel Injection (MPI)
Diesel Injection:
Common Rail Direct Injection (CRDi)
Engine Codes
Common Engine Codes:
G23D (Petrol), D20DT, D27DT, D27Y (Diesel)
🔧 Transmission
Standard
Transmission Type Standard:
5-speed Manual Transmission
Optional
Transmission Type Optional:
5-speed T-Tronic Automatic Transmission (Mercedes-Benz sourced or licensed)
Features
Drivetrain Options:
Selectable 4WD (Part-time 4WD) with low-range transfer case, RWD
📐 Dimensions
Exterior
Length:
Approx. 4965 mm (195.5 in)
Width:
Approx. 1865 mm (73.4 in)
Height:
Approx. 1775 mm (69.9 in)
Wheelbase:
Approx. 3025 mm (119.1 in)
Cargo
Bed Length:
Approx. 1300 mm (51.2 in)
Weights
Curb Weight:
Approx. 1800 - 2000 kg (3968 - 4409 lbs) depending on configuration
Towing Capacity:
Typically rated up to 2500 kg (5511 lbs) braked trailer weight (market dependent)
🛡️ Safety Features
Ratings
Crash Test Rating:
Euro NCAP (for related Actyon SUV) achieved 4-star rating. Specific Actyon Sport ratings may vary by market and testing body.
Active Features
ABS:
Standard (Anti-lock Braking System)
Ebd:
Standard (Electronic Brakeforce Distribution)
Esp:
Optional/Available on higher trims (Electronic Stability Program)
Passive Features
Airbags:
Driver and Passenger Airbags (standard), Side Airbags (optional/market dependent)
Seatbelts:
3-point front and rear seatbelts with pretensioners
💡 Technology Features
Infotainment
Audio System:
Basic AM/FM radio with CD player, MP3 compatibility, and speaker systems. Higher trims might feature more advanced head units and auxiliary inputs.
Display:
Basic digital or analog displays for climate control and audio information. Navigation systems were rare in this era.
Driver Assistance
Parking Sensors:
Optional or available on higher trim levels.
Cruise Control:
Available on higher trim levels and often standard on automatic transmission models.
Connectivity
Usb Aux:
Auxiliary input jacks for audio devices were becoming more common, USB ports were less common on base models of this period.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 5,000 - 10,000 km (3,000 - 6,000 miles) or 6-12 months, depending on driving conditions and engine type (refer to manual for exact specification).
Air Filter Replacement:
Every 20,000 - 40,000 km (12,000 - 24,000 miles) or annually (refer to manual).
Fuel Filter Replacement:
Diesel: Every 40,000 - 60,000 km (24,000 - 36,000 miles); Petrol: Every 60,000 - 80,000 km (36,000 - 48,000 miles) (refer to manual).
Fluid Specifications
Engine Oil Petrol:
API SG/SH/SJ/SL/SM, SAE 10W-30 or 10W-40 (check manual for precise viscosity and API rating, e.g., ACEA A3/B4 may be recommended for certain engines).
Engine Oil Diesel:
API CF/CG-4/CH-4/CI-4, SAE 5W-30 or 10W-30 (check manual for precise viscosity and API rating, e.g., ACEA B4 or E7 may be recommended).
Transmission Fluid Manual:
API GL-4 SAE 75W-90 or 80W-90 gear oil.
Transmission Fluid Automatic:
Dexron III or equivalent ATF (Automatic Transmission Fluid) - consult manual for exact specification and capacity.
Coolant:
Ethylene glycol-based coolant with long-life inhibitors, typically a 50/50 mix with distilled water. Consult manual for specific type (e.g., OAT, HOAT).
Known Issues
Diesel Particulate Filter:
Potential DPF regeneration issues or clogging, especially with short-trip urban driving for diesel models.
Suspension Wear:
Possible wear in bushings and ball joints over time due to load and off-road use.
Electrical Gremlins:
Some owners report minor electrical issues, often related to switches or sensors, which this manual would help diagnose.
Turbocharger:
Early turbocharger issues or leaks can occur if maintenance is neglected, particularly on diesel variants.
📚 Vehicle History
Brand Heritage
Manufacturer Origin:
South Korea
Brand Focus:
SsangYong has historically focused on SUVs, MPVs, and pickups, often utilizing Mercedes-Benz technology under license in earlier models.
Model Evolution
Introduction Year:
2006
Design Philosophy:
Based on the SsangYong Actyon SUV platform, the Actyon Sport was designed to offer a more utilitarian and rugged alternative with a dual-cab utility body.
Production
Manufacturing Plant:
Pyeongtaek, South Korea
🏆 Awards & Recognition
Recognitions
Awards:
No widely publicized major automotive awards for the SsangYong Actyon Sport are readily available; however, its value proposition and utility often contributed to positive customer reviews in its specific market segments.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
