2008 Polaris Sportsman 500 EFI/X2/Touring/500 H O Workshop

2008 Polaris Sportsman 500 EFI/X2/Touring/500 H O Workshop

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 38766
Brand
Polaris
Vehicle
Powersports
Models covered
Indy Models, Snowmobiles, Sportsman 500 EFI, Sportsman 500 H O, Sportsman 500 Touring, Sportsman 500 X2
Years
2008
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Polaris
Model:
Sportsman 500
Year:
2008
Sub Models Covered:
EFI, X2, Touring, 500 HO
Codes
Oem Manual Code Likely:
PM-2008SP500
👋 Introduction
Market Position
Vehicle Type:
All-Terrain Vehicle (ATV)
Target Audience:
Owners, mechanics, and enthusiasts seeking in-depth repair and maintenance knowledge for the 2008 Polaris Sportsman 500 models.
Competitive Analysis
Manual Value Proposition:
Provides authoritative, detailed instructions to empower users to perform their own maintenance and repairs, saving time and money compared to dealership service.
Key Features
Manual Benefits:
Enables proactive maintenance, efficient troubleshooting, and confident execution of repairs, leading to extended vehicle lifespan and optimal performance.
📋 Manual Details
Coverage Areas
Major Sections:
General Information, Maintenance, Engine, Fuel System, Body/Suspension, Clutch, Transmission, Final Drive, Brakes, Electrical, International Models
Page Count
Estimated Page Count:
400+
Manual Type
Type:
Workshop Repair Service Manual
Language
Language:
English
Format
Digital Format:
PDF
Compatibility
Operating Systems:
All Versions of Windows & Mac
Requirements
Software Requirements:
Adobe PDF Reader
📖 Manual Coverage
Systems Covered
Engine Systems:
Engine overhaul, cylinder head, piston, crankshaft, camshaft, valve train, cooling system, lubrication system
Fuel System:
Fuel injection system (EFI), fuel pump, fuel injectors, throttle body, fuel tank, fuel lines
Drivetrain:
Clutch (primary and secondary), transmission, final drive, driveshafts, differential, AWD system (if applicable)
Suspension And Steering:
Front and rear suspension components, shock absorbers, A-arms, steering system, tie rods, wheel bearings
Brakes:
Brake system overhaul, hydraulic lines, calipers, master cylinder, brake pads, rotors, bleeding procedures
Electrical System:
Ignition system, battery, charging system (stator, regulator/rectifier), lighting, starter motor, wiring diagrams, sensors, ECU
Body And Frame:
Body panels, plastic components, seat assembly, rack systems, chassis components, frame inspection
Procedures Included
Maintenance Procedures:
Scheduled maintenance, oil changes, filter replacements, lubrication, valve adjustments, belt inspection/replacement
Diagnostic Procedures:
Troubleshooting guides, fault code interpretation, common problem diagnosis, electrical diagnostics
Repair Procedures:
Step-by-step repair instructions for all major systems, component removal and installation, torque specifications
Overhaul Procedures:
Complete engine rebuild, transmission overhaul, differential rebuild
Technical Depth
Depth Of Information:
Comprehensive, covering from basic maintenance to complete engine and transmission rebuilds, including detailed electrical schematics and diagnostic procedures.
📊 Manual Specifications
File Format
File Type:
PDF
Print Quality
Print Readability:
High resolution for clear text and diagrams, suitable for printing.
Binding Type
Binding:
Not Applicable (Digital PDF)
Paper Type
Paper Quality:
Not Applicable (Digital PDF)
⚙️ Engine Specifications
Primary Engine
Engine Type:
4-stroke, Liquid-Cooled, SOHC, 2-Valve
Displacement:
499cc
Bore X Stroke:
92mm x 75mm
Cooling System:
Liquid-Cooled with Fan
Performance
Horsepower Estimate:
Approx. 32-34 HP (Varies by specific sub-model and tuning)
Torque Estimate:
Approx. 30-32 lb-ft (Varies by specific sub-model and tuning)
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline
Ignition
Ignition System:
Electronic Ignition with Digital CDI
Lubrication
Oil Type Recommended:
SAE 10W-40 Synthetic Motorcycle Oil (API SG or higher)
Oil Capacity W Filter:
Approx. 2.1 quarts (2.0 liters)
🔧 Transmission
Standard
Transmission Type:
Automatic PVT (Polaris Variable Transmission) with Engine Braking
Features
Gear Selection:
High (H), Low (L), Neutral (N), Reverse (R), Park (P)
Drive System:
On-Demand All-Wheel Drive (AWD)
Final Drive
Gear Reduction:
Shaft Drive to Front and Rear
Fluid Type
Transmission Fluid:
Polaris PVT Fluid or equivalent SAE 20W-50 API GL-5 Gearcase Lube
📐 Dimensions
Exterior
Length:
Approx. 81 inches (205.7 cm) (Varies slightly by sub-model)
Width:
Approx. 46 inches (116.8 cm)
Height:
Approx. 48 inches (121.9 cm) (Varies by sub-model)
Weights
Dry Weight:
Approx. 675 lbs (306 kg) (Varies by sub-model)
Ground Clearance:
Approx. 11.25 inches (28.6 cm)
Towing Capacity:
1500 lbs (680 kg)
Rack Capacity Front:
100 lbs (45 kg)
Rack Capacity Rear:
200 lbs (90 kg) (Or more on X2/Touring models)
Fuel Capacity:
4.0 gallons (15.1 L)
🛡️ Safety Features
Ratings
Safety Certification:
ATV Safety Institute (ASI) Recommended Practices
Active Features
Braking System:
Hydraulic Disc Brakes (Front and Rear)
Engine Braking:
Standard on PVT transmission for controlled descents
Passive Features
Handlebars:
Handlebar with integrated handguards for protection
Operator Protection:
Recommended use of helmet, eye protection, gloves, and sturdy footwear
💡 Technology Features
Infotainment
Infotainment Features:
Basic LCD display for speed, RPM, odometer, trip meter, fuel level, and engine warning indicators.
Driver Assistance
Throttle Control:
Electronic Fuel Injection (EFI) for precise throttle response and smoother power delivery.
Connectivity
Diagnostic Ports:
On-board diagnostic system with connectors for service tools/computers (covered in the manual).
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or 12 months, whichever comes first.
Air Filter Cleaning:
Inspect every 25 hours, clean as needed. Replace if damaged.
Spark Plug Replacement:
Every 200 hours or 24 months.
Clutch Belt Inspection:
Inspect every 100 hours for wear, cracks, or damage. Replace as needed.
Transmission Fluid Change:
Every 200 hours or 24 months.
Fluid Specifications
Engine Oil Specification:
SAE 10W-40 Synthetic Motorcycle Oil (API SG or higher)
Cooling System Coolant:
Polaris Premium Antifreeze/Coolant or equivalent (50/50 mix of ethylene glycol and distilled water).
Brake Fluid Type:
DOT 4 Hydraulic Brake Fluid
Gearcase Lubricant:
Polaris PVT Fluid or SAE 20W-50 API GL-5 Gearcase Lube
Known Issues
Common Wear Items:
Drive belt, tie rod ends, wheel bearings, brake pads, shock absorber bushings.
Potential Efi Issues:
Throttle body cleaning, fuel injector clogging, TPS sensor calibration.
Cooling System Maintenance:
Regular coolant flushes and ensuring proper fan operation are critical to prevent overheating.
📚 Vehicle History
Brand Heritage
Manufacturer:
Polaris Industries Inc.
Brand Focus:
Specialty vehicles, including snowmobiles, ATVs, and utility vehicles.
Model Evolution
Sportsman Lineage:
The Sportsman line has been a cornerstone of Polaris' ATV offerings, known for its versatility, comfort, and capable performance since its introduction.
2008 Updates:
The 2008 model year saw continued refinement of the Sportsman 500 platform, including improvements in EFI systems for better throttle response and reliability across its various configurations (EFI, X2, Touring).
Production
Manufacturing Location:
Likely manufactured in the USA by Polaris Industries.
🏆 Awards & Recognition
Recognitions
Atv Segment Popularity:
The Polaris Sportsman 500 has historically been one of the best-selling and most popular utility ATVs in its class, recognized for its reliability and all-around performance.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
