PIPER CHEROKEE Service Manual PA-28-140 150 160 180 235 200

PIPER CHEROKEE Service Manual PA-28-140 150 160 180 235 200

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 33726
Brand
Piper
Vehicle
Tractors
Models covered
2 150, Agriculture, PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-200, PA-28-235, White
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Piper
Model:
Cherokee PA-28
Generation:
PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, PA-28R-200
📋 Manual Details
General
Manual Type:
Service Manual
Language:
English
Page Count:
916
Format:
PDF
Features
Searchable:
True
Bookmarked:
True
Indexed:
True
Illustrations:
True
Diagrams:
True
Photos:
True
Compatible Os:
Windows, Mac
Product Id
Part Number:
753-586
🔧 Maintenance
Scope
Service Instructions Scope:
Ground handling, servicing, and inspections
Maintenance Instructions Scope:
Troubleshooting, removal/installation of components, corrective maintenance, and testing for each major system
Personnel
Qualified Personnel Required:
True
📄 Aircraft Description
Configuration
Configuration:
Single-engine, low-wing monoplane
Construction
Construction Material:
All-metal stressed-skin
Capacity
Standard Seating:
2-place (PA-28-140), 4-place (PA-28-150, -160, -180, -235, PA-28R-180, -200)
Purpose
Aviation Field:
Personal and business aviation
Manufacturer
Manufacturer Location:
Vero Beach, Florida
Wing Design
Wing Type:
Laminar flow
Wing Structure:
Full cantilever
Wing Components
Aileron Control:
Cable and push rod
Aileron Balancing:
Dynamically balanced
Flaps Operation:
Manually operated trailing edge
Empennage
Empennage Components:
Fin, rudder, stabilator, stabilator trim tabs
Stabilator Balancing:
Dynamically balanced

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
