Best 1998-2003 Mitsubushi SPACE STAR Complete Service/Repair/Workshop Manual- ( 98 99 01 02 03 1998 1999 2000 2001 2002 03 )

Best 1998-2003 Mitsubushi SPACE STAR Complete Service/Repair/Workshop Manual- ( 98 99 01 02 03 1998 1999 2000 2001 2002 03 )

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 586067
Brand
Mitsubishi
Vehicle
Cars
Models covered
Mitsubushi, SPACE STAR
Years
1998, 1999, 2000, 2001, 2002, 2003
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Space Star
Platform:
Mitsubishi Carisma / Volvo S40/V40 Platform Shared
Codes
Chassis Codes:
DE2A, DE8A, N94W, N96W
Chassis Codes Years Covered:
1998-2003
👋 Introduction
Market Position
Segment:
Compact MPV (Multi-Purpose Vehicle) / Mini MPV
Target Audience:
Families seeking practicality, versatile interior space, and fuel efficiency in a compact footprint
Competitive Analysis
Key Competitors:
Opel/Vauxhall Zafira, Ford Focus C-Max, Renault Scénic, Citroën Xsara Picasso
Key Features
Interior Versatility:
Sliding rear seats, folding seats, flexible cargo configurations
Compact Exterior:
Maneuverable in urban environments, easy to park
Engine Options:
Range of efficient petrol and diesel engines
📋 Manual Details
Coverage Areas
Coverage Areas:
Complete Service, Repair, and Workshop
Page Count
Page Count:
Extensive (typically 1000+ pages for a complete factory manual)
Manual Type
Manual Type:
Factory Service Manual (FSM) / Workshop Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Powertrain:
Engine mechanical, lubrication, cooling, fuel, ignition, exhaust, emissions, engine management (ECU)
Transmission:
Manual and Automatic Transmission (ATX/INVECS) overhaul, operation, control systems, fluid specifications
Drivetrain:
Front Wheel Drive (FWD) system, driveshafts, CV joints, differential
Suspension:
Front and Rear suspension components, geometry, alignment, shock absorbers, springs, bushings
Steering:
Power steering system, steering rack, linkages, column, hydraulic system
Brakes:
Front and Rear brake systems (disc/drum configurations), ABS, hydraulic system, parking brake
Electrical:
12V DC system, battery, charging system (alternator), starting system (starter), lighting, wipers, horn, power accessories, fuses, relays, wiring diagrams
Climate Control:
HVAC system, A/C compressor, refrigerant, heater core, blower motor, controls
Body And Trim:
Exterior body panels, interior trim, doors, windows, seats, roof lining, bumpers
Safety Systems:
Airbag system (SRS), seatbelt mechanisms, pre-tensioners
Procedures Included
Preventive Maintenance:
Scheduled maintenance, fluid checks and changes, filter replacements, inspections
Diagnostics Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides, component testing
Repair Overhaul:
Engine component rebuilds, transmission overhaul, brake caliper replacement, suspension component replacement, electrical component repair
Disassembly Assembly:
Step-by-step instructions for removing and installing all major components
Specifications Tolerances:
Torque specifications, clearances, fluid capacities, component tolerances
Wiring Diagrams:
Detailed electrical wiring schematics for all vehicle systems
Technical Depth
Depth Of Information:
Comprehensive, suitable for professional technicians and advanced DIY enthusiasts
Diagnostic Tools:
Information on diagnostic scan tools and their usage for this model range
Component Identification:
Clear identification of all parts and their locations
Special Tools:
Identification of any special tools required for specific procedures
📊 Manual Specifications
File Format
File Format:
PDF
Searchability:
Likely text-searchable for efficient information retrieval
Printability:
Printable pages
Print Quality
Image Resolution:
High-resolution illustrations and diagrams for clarity
Binding Type
Binding Type:
N/A (Digital PDF)
Paper Type
Paper Type:
N/A (Digital PDF)
⚙️ Engine Specifications
Primary Engine
Engine Code 1:
4G93 (1.8L SOHC)
Displacement 1:
1834 cc
Horsepower 1:
Approx. 112-115 PS (82-85 kW)
Torque 1:
Approx. 160-165 Nm
Fuel System 1:
Multi-point Fuel Injection (MPI)
Engine Code 2:
4G94 (2.0L DOHC GDI)
Displacement 2:
1998 cc
Horsepower 2:
Approx. 135 PS (99 kW)
Torque 2:
Approx. 175 Nm
Fuel System 2:
Gasoline Direct Injection (GDI)
Engine Code 3:
4D68 (2.0L Diesel)
Displacement 3:
1998 cc
Horsepower 3:
Approx. 82-90 PS (60-66 kW)
Torque 3:
Approx. 140-170 Nm
Fuel System 3:
Indirect Injection Diesel
Performance
Acceleration 0 60Mph:
Varies by engine, typically 10-13 seconds
Top Speed:
Approx. 170-185 km/h
Fuel System
Fuel Type:
Unleaded Petrol (RON 95/98), Diesel
Fuel Tank Capacity:
Approx. 50 Liters (13.2 US Gallons)
🔧 Transmission
Standard
Transmission Type:
5-speed Manual
Optional
Transmission Type:
4-speed Automatic (INVECS-II)
Features
Automatic Control:
Adaptive shift control (INVECS-II) adjusting to driving style
Manual Gear Ratios:
Specific ratios detailed in the manual
Automatic Gear Ratios:
Specific ratios detailed in the manual
Fluid Specifications
Manual Transmission Fluid:
API GL-4, SAE 75W-90 or 80W-90
Automatic Transmission Fluid:
Dia Queen ATF SP-II M (or equivalent)
📐 Dimensions
Exterior
Length:
Approx. 4275 mm (168.3 in)
Width:
Approx. 1715 mm (67.5 in)
Height:
Approx. 1600-1640 mm (63.0-64.6 in)
Wheelbase:
Approx. 2620 mm (103.1 in)
Interior
Seating Capacity:
5 Seats
Cargo
Cargo Volume Seats Up:
Approx. 370-400 Liters
Cargo Volume Seats Down:
Approx. 1500-1600 Liters
Weights
Curb Weight:
Approx. 1200-1350 kg
Gross Vehicle Weight Rating:
Approx. 1800-1900 kg
Towing Capacity:
Varies, consult manual for specific limits
Wheels Tires
Wheel Bolt Pattern:
4x114.3 mm (4x4.5 inches)
Standard Tire Size:
185/65 R14, 195/60 R15 (depending on trim)
🛡️ Safety Features
Ratings
Euro Ncap Rating:
Not independently rated by Euro NCAP for early models, later European versions generally performed average to below average for the time
Active Features
ABS:
Available on higher trims and optional
Traction Control:
Less common, may be present on specific export models
Passive Features
Airbags:
Driver and front passenger airbags standard or optional depending on market
Seatbelts:
3-point inertia-reel seatbelts with pre-tensioners
Child Seat Anchors:
ISOFIX points generally not standard, may vary by market
💡 Technology Features
Infotainment
Audio System:
Factory fitted radio/cassette or CD player, often with basic speaker configurations
Display:
Basic LCD display for radio and clock functions
Driver Assistance
Cruise Control:
Available on higher trim levels
Connectivity
Auxiliary Input:
Not standard, aftermarket solutions may be required
Bluetooth:
Not available from factory; aftermarket installations are common
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 15,000 km or 12 months, whichever comes first (check manual for specific engine type)
Air Filter Replacement:
Every 30,000 km or 24 months
Spark Plug Replacement:
Approx. 60,000-100,000 km depending on plug type (standard vs. long-life)
Timing Belt Replacement:
Typically every 90,000-100,000 km or 5-6 years (critical for 4G93/4G94 engines - interference engines)
Fluid Specifications
Engine Oil Capacity:
Approx. 4.0-4.5 Liters (with filter), consult manual for specific engine
Engine Oil Specification:
API SG/SH/SJ or higher, Viscosity SAE 10W-40 or 5W-30 (depending on climate and engine)
Coolant Type:
Ethylene glycol based coolant, Mitsubishi Super Long Life Coolant (or equivalent)
Brake Fluid Type:
DOT 3 or DOT 4
Power Steering Fluid:
DEXRON II/III or equivalent ATF
Known Issues
Engine Gdi Carbon Buildup:
Direct Injection engines (GDI) can be prone to carbon deposits on intake valves; requires specialized cleaning.
Timing Belt Failure:
Critical to adhere to timing belt replacement schedule; failure can cause catastrophic engine damage.
Suspension Wear:
Bushings and ball joints can wear over time, leading to noise and poor handling.
Electrical Gremlins:
Some owners report minor electrical issues, often related to earth points or connectors.
Diesel Glow Plugs:
Diesel models may require glow plug replacement for reliable cold starts.
📚 Vehicle History
Brand Heritage
Manufacturer:
Mitsubishi Motors Corporation
Model Evolution
First Generation Launch:
1998
Facelift:
Minor updates in 2001, including styling tweaks and interior refinements
Platform Sharing:
Developed in conjunction with the Mitsubishi Carisma and sharing its platform with the first-generation Volvo S40/V40.
Production
Production Period:
1998-2005
Manufacturing Locations:
Primarily Netherlands (NedCar plant)
🏆 Awards & Recognition
Recognitions
Industry Awards:
While not a recipient of major 'Car of the Year' awards, it was recognized for its practicality and value in its segment by various automotive publications.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
