Mitsubishi Mirage 1995-2003 Workshop/Repair Service Manual

Mitsubishi Mirage 1995-2003 Workshop/Repair Service Manual

$17.99
$17.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 415545
Brand
Mitsubishi
Vehicle
Cars
Models covered
Mirage, Misc
Years
1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Mirage
Model Years:
1995-2003
Generations Covered:
Sixth Generation (CJ/CK/CM/CN)
Codes
Chassis Codes:
CJ1A, CK1A, CM1A, CN1A
👋 Introduction
Market Position
Market Segment:
Subcompact hatchback and sedan, positioned as an affordable and fuel-efficient option.
Competitive Analysis
Key Competitors:
Honda Civic, Toyota Corolla, Ford Focus, Nissan Sentra, Hyundai Accent, Chevrolet Cavalier.
Key Features
Selling Points:
Affordability, good fuel economy, compact size for urban maneuverability, practical hatchback utility (on some models).
📋 Manual Details
Coverage Areas
Regions Covered:
North America, Europe, Asia, Oceania (specific regional variations may apply based on original manual source)
Page Count
Page Count:
1547
Manual Type
Manual Type:
Workshop/Repair Service Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine overhaul, disassembly, assembly, diagnosis, timing belt/chain, piston rings, cylinder head, crankshaft, camshafts, oil pump, cooling system, lubrication system.
Engine Performance:
Fuel injection system (MPI/GDI depending on variant), ignition system, emissions control system, turbocharging (if applicable).
Transmission:
Manual transmission (5-speed), Automatic transmission (4-speed INVECS-II), clutch system, driveline, axles, differential.
Brakes:
Front disc brakes, rear drum brakes (common), rear disc brakes (optional/performance trims), ABS system (if equipped), hydraulic system, parking brake.
Suspension Steering:
Front MacPherson struts, rear torsion beam (common), independent rear suspension (some variants), power steering system, steering linkage, wheel alignment specifications.
Electrical Electronics:
Battery, charging system (alternator), starting system, lighting system (headlights, taillights, interior), instrument cluster, body control module (BCM), fuses and relays, wiring diagrams, ECU diagnosis.
HVAC:
Air conditioning system, heater core, blower motor, climate control operation and diagnosis.
Body Chassis:
Body panel repair, door mechanisms, interior trim, glass replacement, structural components, corrosion protection.
Safety Features:
Airbag system (SRS), seat belts, child restraint systems, passive safety component diagnosis.
Procedures Included
Maintenance Procedures:
Oil changes, filter replacements, fluid checks and flushes, spark plug replacement, brake pad/shoe replacement, tire rotation, belt inspection/replacement.
Diagnostic Procedures:
Troubleshooting charts, symptom-based diagnostics, diagnostic trouble codes (DTCs), on-board diagnostics (OBD-I/OBD-II), component testing.
Repair Procedures:
Component removal and installation, engine rebuild, transmission overhaul, brake caliper replacement, suspension component replacement, electrical component repair.
Technical Specifications Data:
Torque specifications, clearances, fluid capacities, electrical specifications, diagnostic parameters.
Technical Depth
Depth Of Coverage:
Comprehensive, covering basic maintenance to complete engine and transmission rebuilds. Includes detailed diagnostic flowcharts and wiring diagrams.
📊 Manual Specifications
File Format
File Format:
PDF
Print Quality
Print Quality:
Digital scan, quality suitable for on-screen viewing and printing. Clarity of diagrams and text is generally good for PDF format.
Binding Type
Binding Type:
N/A (Digital PDF)
Paper Type
Paper Type:
N/A (Digital PDF)
⚙️ Engine Specifications
Primary Engine
Engine Options:
1.5L (4G15) SOHC I4, 1.8L (4G93) DOHC I4 (performance trims), 1.6L (4G92) DOHC I4 (some markets), 1.3L (4G13) SOHC I4 (some markets).
Performance
Horsepower Range:
Approximately 90-125 hp depending on engine and market.
Torque Range:
Approximately 95-120 lb-ft depending on engine and market.
Fuel System
Fuel Delivery:
Multi-point Fuel Injection (MPI).
Recommended Fuel:
87 Octane Unleaded Gasoline (check specific vehicle requirements).
Engine Codes
Common Engine Code:
4G15 (1.5L)
🔧 Transmission
Standard
Standard Transmission:
5-speed manual transmission.
Optional
Optional Transmission:
4-speed automatic transmission (INVECS-II).
Features
Automatic Transmission Features:
INVECS-II (Intelligent and Innovative Control Expert System II) with adaptive shift logic.
Fluid Specifications
Manual Transmission Fluid:
API GL-4, SAE 75W-90 or 80W-90 gear oil (check manual for exact specification and capacity).
Automatic Transmission Fluid:
DIA-Queen ATF-II or equivalent (check manual for exact specification and capacity).
📐 Dimensions
Exterior
Body Styles:
3-door hatchback, 5-door hatchback, 4-door sedan.
Length:
Approximately 3980-4200 mm (depending on body style).
Width:
Approximately 1680-1710 mm (depending on model).
Height:
Approximately 1395-1420 mm (depending on body style).
Weights
Curb Weight Range:
Approximately 950-1100 kg (depending on trim and body style).
Wheelbase:
Approximately 2440-2500 mm (depending on model variant).
🛡️ Safety Features
Ratings
NHTSA Ratings:
Varies by year and testing protocols. Typically moderate to good for its class and era, but specific data needs to be consulted for individual years.
Active Features
Braking System:
Front disc, rear drum standard. Optional ABS on select models/trims.
Passive Features
Airbags:
Driver and front passenger airbags standard on most models from mid-production of this generation.
Seatbelts:
3-point front seatbelts with pretensioners, 3-point rear seatbelts.
💡 Technology Features
Infotainment
Audio System:
Basic AM/FM radio with cassette player, optional CD player. Speaker configurations vary by trim.
Driver Assistance
ABS:
Available on higher trims or as an option, typically front-wheel ABS.
Connectivity
Connectivity Features:
Limited by era, primarily focused on power windows, power locks (on higher trims), and basic audio controls.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 5,000-7,500 miles or 6-12 months (refer to manual for specific interval and oil type).
Timing Belt Replacement:
Recommended every 60,000-90,000 miles or 5-7 years. Critical due to interference engine design on some variants.
Spark Plug Replacement:
Every 30,000-60,000 miles depending on plug type (copper vs. platinum).
Fluid Specifications
Engine Oil Specification:
API SG or SH, SAE 5W-30 or 10W-30 (verify with owner's manual, depending on climate).
Coolant Specification:
Ethylene glycol-based coolant, typically a 50/50 mix with distilled water. Check for Mopar, Dex-Cool, or specific Mitsubishi coolant type.
Brake Fluid Specification:
DOT 3 or DOT 4 brake fluid.
Known Issues
Engine Reliability:
Generally reliable, but timing belt maintenance is critical. Some reports of oil consumption on higher mileage engines.
Transmission Issues:
Automatic transmission fluid changes are important. Manual transmissions generally robust.
Electrical Issues:
Failing alternators, starter motors, and window regulators can occur with age and mileage.
Suspension Wear:
Bushings, ball joints, and strut mounts can wear over time, leading to noise and handling issues.
Part Numbers
Oil Filter Example:
Mitsubishi: MD069782, Fram: PH7317, Bosch: 3323 (verify for specific engine).
Timing Belt Kit Example:
Gates TCK151 (includes belt, tensioner, idler pulley - verify for specific engine).
📚 Vehicle History
Brand Heritage
Mitsubishi Legacy:
Mitsubishi has a long history in automotive manufacturing, known for reliable and accessible vehicles. The Mirage nameplate has been used across several generations of their compact cars.
Model Evolution
Sixth Generation Introduction:
The Mirage underwent significant redesign for the 1995 model year, often referred to as the 'CJ' generation globally, with regional variations in designation (CK, CM, CN). It was based on the Mitsubishi platform shared with the Colt.
Production
Manufacturing Locations:
Primarily Japan, with production also occurring in other global facilities depending on market demand.
🏆 Awards & Recognition
Recognitions
General Reputation:
The Mirage in this generation was often recognized for its value and fuel efficiency, though it typically didn't win major awards against more premium competitors.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
