1995-1999 Mitsubishi Eclipse Service Repair Manual

1995-1999 Mitsubishi Eclipse Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 396241
Brand
Mitsubishi
Vehicle
Cars
Models covered
Eclipse, Misc
Years
1995, 1996, 1997, 1998, 1999
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Eclipse
Generation:
2nd Generation
Chassis Codes:
D31A, D32A, D38A
Codes
Product Id:
MITSUBISHI-ECLIPSE-1995-1999-SRM-PDF
👋 Introduction
Market Position
Market Segment:
Compact sports coupe/convertible market.
Competitive Analysis
Key Competitors:
Dodge Neon, Toyota Celica, Honda Prelude, Nissan 200SX/240SX, Mazda MX-6, Ford Probe.
Key Features
Unique Selling Points:
Available turbocharged engines (GS-T, GT), available AWD, sleek styling, customizable platform (aftermarket support).
Target Audience
Target Audience:
Enthusiasts seeking performance, tuners, DIY mechanics, and owners requiring in-depth repair knowledge.
📋 Manual Details
Coverage Areas
Systems Covered:
Engine, Transmission, Drivetrain, Suspension, Steering, Brakes, Fuel System, Cooling System, Exhaust System, Electrical System, Body, Interior, HVAC, Emissions Control, Diagnostics
Page Count
Page Count:
Estimated 1000+ pages (typical for comprehensive dealership service manuals)
Manual Type
Manual Type:
Factory Authorized Service and Repair Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine Service:
Detailed diagnostics, disassembly, assembly, timing belt replacement, component testing, repair procedures for all engine variants.
Transmission Service:
Repair and overhaul procedures for both manual and automatic transmissions, including clutch service, gear synchronization, valve body diagnostics.
Drivetrain Service:
Front-wheel drive (FWD) and All-wheel drive (AWD) system maintenance, CV joint replacement, differential service, driveshaft balancing.
Suspension Steering:
Front and rear suspension component replacement (struts, shocks, control arms, ball joints), steering rack diagnosis and repair, power steering system service.
Brake System:
Disc brake service (pads, rotors, calipers), rear drum brake service (if applicable), ABS system diagnostics and repair, brake fluid flush procedures.
Fuel Cooling Exhaust:
Fuel pump and injector testing, fuel filter replacement, radiator and coolant system maintenance, exhaust system component replacement and repair.
Electrical Electronics:
Wiring diagrams, component testing, starter, alternator, battery service, lighting system repair, power windows, locks, and mirror systems.
Body Interior:
Panel replacement, door and window seal service, interior trim removal and installation, seat mechanisms, airbag system precautions.
HVAC Emissions:
Air conditioning system service and recharge, heater core replacement, emission control system diagnostics (catalytic converter, EGR valve, O2 sensors).
Procedures Included
Maintenance Procedures:
Oil changes, filter replacements, spark plug replacement, fluid checks and changes, tire rotation, brake inspection.
Troubleshooting Diagnostics:
System-specific diagnostic flowcharts, common fault codes, symptom-based troubleshooting guides, using scan tools (OBD-I/OBD-II).
Repair Overhaul:
Complete engine rebuild procedures, transmission overhaul, suspension component replacement, body panel repair and replacement.
Installation Replacement:
Step-by-step instructions for replacing major components such as alternators, starters, fuel pumps, radiators, and suspension parts.
Technical Specifications Data:
Torque specifications for all fasteners, engine compression test values, fluid capacities, electrical component resistance values.
Technical Depth
Depth Of Coverage:
Comprehensive; covers everything from basic preventative maintenance to full engine and transmission rebuilds and advanced electrical diagnostics.
📊 Manual Specifications
File Format
File Format:
PDF
Print Quality
Print Quality:
High-resolution scans of original factory documentation, ensuring clarity of text and diagrams.
Binding Type
Binding Type:
N/A (Digital PDF format)
Paper Type
Paper Type:
N/A (Digital PDF format)
Searchability
Searchability:
Text-searchable PDF, allowing for quick access to specific topics and procedures.
Interactivity
Interactivity:
Bookmarks for easy navigation, hyperlinked sections for quick jumps to related information.
⚙️ Engine Specifications
Primary Engine
Base Engine:
2.4L DOHC 4G64 Inline-4
Base Engine Hp:
140 hp @ 5500 rpm
Base Engine Torque:
145 lb-ft @ 4000 rpm
Performance Engine
Performance Engine 1:
2.0L DOHC Turbocharged 4G63 Inline-4 (GS-T)
Performance Engine 1 Hp:
210 hp @ 6000 rpm (FWD)
Performance Engine 1 Torque:
214 lb-ft @ 3000 rpm (FWD)
Performance Engine 2:
2.0L DOHC Turbocharged 4G63 Inline-4 AWD (GSX)
Performance Engine 2 Hp:
205 hp @ 6000 rpm (AWD)
Performance Engine 2 Torque:
203 lb-ft @ 3000 rpm (AWD)
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Recommended Fuel:
87 Octane (4G64), 91 Octane Premium Unleaded (4G63 Turbocharged)
Engine Codes
Engine Code Base:
4G64
Engine Code Turbo:
4G63T
🔧 Transmission
Standard Transmission
Standard Gearbox Base:
5-speed manual (FWD models)
Standard Gearbox Turbo:
5-speed manual (GS-T FWD), 5-speed manual (GSX AWD)
Optional Transmission
Optional Gearbox Base:
4-speed automatic (FWD models)
Optional Gearbox Turbo:
4-speed automatic (GS-T FWD), 4-speed automatic (GSX AWD)
Features
AWD System:
Full-time viscous coupling center differential with automatic torque biasing front and rear differentials (GSX models).
📐 Dimensions
Exterior
Wheelbase:
103.7 inches (2634 mm)
Length:
178.5 inches (4534 mm)
Width:
69.4 inches (1763 mm)
Height:
50.4 inches (1280 mm) (Coupe)
Weights
Curb Weight Base:
Approx. 3000 lbs (1361 kg)
Curb Weight Turbo FWD:
Approx. 3150 lbs (1429 kg)
Curb Weight Turbo AWD:
Approx. 3350 lbs (1519 kg)
Wheel Tire
Standard Wheel Size:
16-inch alloy
Standard Tire Size:
205/55R16
Wheel Bolt Pattern:
5x114.3 mm (5x4.5 inches)
🛡️ Safety Features
Ratings
NHTSA Driver Front Impact:
4-star (1995-1997 models with driver airbag)
NHTSA Passenger Front Impact:
4-star (1995-1997 models with driver airbag)
Active Features
ABS:
Standard on GSX, optional on other trims.
Passive Features
Airbags:
Driver and passenger airbags standard from 1995 onwards.
Seatbelts:
Three-point front seatbelts, height adjustable.
💡 Technology Features
Infotainment
Audio System:
Factory AM/FM/Cassette or optional CD player; premium sound systems available on higher trims.
Driver Assistance
Cruise Control:
Available on most models.
Connectivity
OBD Standard:
OBD-I in early models, transitioning to OBD-II in later years (manual will cover both diagnostics methods).
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,750 miles or 3 months (whichever comes first), or 7,500 miles/6 months with synthetic oil.
Timing Belt Replacement:
Every 60,000 miles or 5 years (critical for 4G63T engines to prevent catastrophic damage).
Spark Plug Replacement:
Every 30,000 miles (standard plugs), 60,000 miles (platinum plugs).
Fluid Specifications
Engine Oil Type:
API SG or higher, SAE 5W-30 recommended (check owner's manual for specific viscosity based on climate).
Engine Oil Capacity:
Approx. 4.5 quarts (4.3 L) with filter (4G63/4G64).
Coolant Type:
Mitsubishi DiaQueen Super Long Life Coolant (or equivalent ethylene glycol-based antifreeze).
Transmission Fluid Manual:
API GL-4 SAE 75W-90 gear oil.
Transmission Fluid Automatic:
DIA QUEEN ATF-SP II M (or equivalent Dexron III/Mercon).
Known Issues
Turbo Oil Lines:
Risk of oil starvation and turbo failure if oil lines are not maintained or replaced (common on 4G63T).
Clutch Wear:
Clutches can wear prematurely, especially in performance-oriented driving.
Rear Main Seal Leaks:
Rear main seal leaks can occur over time.
Catalytic Converter:
Can become clogged or fail, leading to performance issues.
Window Regulators:
Power window regulators can fail.
📚 Vehicle History
Brand Heritage
Mitsubishi Motors:
Mitsubishi Motors Corporation is a Japanese multinational automotive manufacturer, tracing its roots back to 1917.
Model Evolution
First Generation:
The first generation Eclipse (1989-1994) was a joint venture with Chrysler (Eagle Talon, Plymouth Laser).
Second Generation Introduction:
The second generation Eclipse was launched for the 1995 model year, featuring a completely new design and platform.
Design Studio:
Designed in the United States by Mitsubishi's North American design studio, reflecting American styling trends.
Production
Manufacturing Location:
Normal, Illinois, USA (Diamond-Star Motors plant)
Production Years
Model Years Covered:
1995, 1996, 1997, 1998, 1999
🏆 Awards & Recognition
Recognitions
Car And Driver 10 Best:
Eclipse GSX was named to Car and Driver's 10 Best list for 1996.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
