2000 2002 Mitsubishi Eclipse Service Repair Manual

2000 2002 Mitsubishi Eclipse Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 257070
Brand
Mitsubishi
Vehicle
Cars
Models covered
Eclipse
Years
2000, 2001, 2002
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Eclipse
Model Variant:
Spyder
Model Years Covered:
2000, 2001, 2002
Codes
Chassis Code Generation:
Third Generation (D50A)
👋 Introduction
Market Position
Segment:
Compact Sports Car / Convertible
Competitive Analysis
Key Competitors:
Honda Civic Si, Toyota Celica, Nissan Sentra SE-R, Ford Focus SVT, Chevrolet Cavalier Z24
Key Features
Engine Options:
Known for its available V6 engine and sporty styling.
Spyder Variant:
The Spyder model offers a retractable soft-top for open-air driving.
Design:
Distinctive styling with a focus on sportiness and driver engagement.
📋 Manual Details
Coverage Areas
Engine Coverage:
All gasoline engine variants
Transmission Coverage:
Manual and Automatic transmissions
Chassis Coverage:
Suspension, Steering, Brakes, Exhaust
Electrical Coverage:
Wiring diagrams, ECUs, Lighting, Accessories, Powertrain Control
Body Coverage:
Exterior panels, Interior trim, Convertible top system (Spyder)
Maintenance Procedures:
Scheduled maintenance, Fluid changes, Filter replacements
Diagnostic Troubleshooting:
Component testing, Fault code interpretation, Symptom-based diagnostics
Repair Procedures:
Engine overhaul, Transmission rebuild, Suspension component replacement
Page Count
Estimated Pages:
1500+
Manual Type
Type:
Factory Authorized Service Manual / Repair Manual
Language
Language:
English
Format
Format:
PDF
Compatibility:
All Windows and Mac OS versions
Downloadable:
Yes
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine assembly, Cylinder head, Piston, Crankshaft, Timing belt/chain, Lubrication system, Cooling system
Engine Performance:
Fuel injection, Ignition system, Emissions control, Turbocharger (if applicable)
Powertrain Control:
ECU diagnostics, Sensor data, Actuator control
Transmission Drivetrain:
Clutch system, Gearbox operation, Driveshafts, Differential
Suspension Steering:
Front suspension, Rear suspension, Power steering system, Wheel alignment
Brake System:
Front and rear brakes, ABS system, Parking brake
Electrical Systems:
Battery, Charging system, Starting system, Lighting, Instrumentation, HVAC controls, Power accessories, Convertible top controls
Body And Frame:
Body structure, Doors, Hood, Trunk, Bumpers, Convertible top mechanism and hydraulics
Procedures Included
Routine Maintenance:
Oil and filter changes, Air filter replacement, Spark plug replacement, Coolant checks, Brake fluid checks
Component Replacement:
Alternator, Starter motor, Water pump, Radiator, Belts, Hoses, Brake pads/rotors, Shocks/struts
Diagnostics:
OBD-II diagnostics, Circuit testing, Pressure testing, Leak detection
Rebuilding Overhauling:
Engine top-end and bottom-end rebuild, Transmission overhaul, Differential service
Special Procedures:
Timing belt replacement, Convertible top system repair, Airbag system service, ABS bleeding
Technical Depth
Depth:
Comprehensive; covers basic maintenance to complete engine and transmission rebuilds
Diagnostics Level:
Advanced; includes wiring diagrams, component testing procedures, and diagnostic flowcharts
Repair Detail:
Detailed step-by-step instructions with torque specifications and illustrations
📊 Manual Specifications
File Format
Format:
PDF
Searchability:
Searchable text content
Printability:
Printable pages
Print Quality
Quality:
High resolution, clear text and diagrams
Binding Type
Binding:
N/A (Digital PDF)
Paper Type
Paper:
N/A (Digital PDF)
⚙️ Engine Specifications
Primary Engine
Engine 1 Type:
Inline 4-cylinder
Engine 1 Displacement:
2.4 L (2378 cc)
Engine 1 Code:
4G64
Engine 1 Horsepower:
145 hp @ 5700 rpm
Engine 1 Torque:
153 lb-ft @ 4000 rpm
Optional Engine
Engine 2 Type:
V6
Engine 2 Displacement:
3.0 L (2972 cc)
Engine 2 Code:
6G72 (SOHC / DOHC variants)
Engine 2 Horsepower:
197 hp @ 5500 rpm (SOHC), 205 hp @ 6000 rpm (GT DOHC)
Engine 2 Torque:
205 lb-ft @ 4000 rpm (SOHC), 214 lb-ft @ 4000 rpm (GT DOHC)
Fuel System
Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (87 octane recommended, 91+ for higher performance)
Engine Management
ECU Type:
Proprietary Mitsubishi ECU with OBD-II interface
Timing System
Timing Belt 4Cyl:
Yes, requires periodic replacement. Refer to manual for interval and procedure.
Timing Belt V6:
Yes, requires periodic replacement. Refer to manual for interval and procedure.
🔧 Transmission
Standard Transmission
Type 4Cyl:
5-Speed Manual
Type V6:
5-Speed Manual
Optional Transmission
Type 4Cyl:
4-Speed Automatic
Type V6:
4-Speed Automatic
Features
All Wheel Drive:
Optional on GT V6 models (AWD system)
Fluid Specifications
Manual Transmission Fluid:
API GL-4, SAE 75W-90 recommended (Verify with manual for specific fill)
Automatic Transmission Fluid:
DIA-Queen ATF-SP II M (or equivalent Dexron III/Mercon)
📐 Dimensions
Exterior
Length:
Approximately 176.7 inches (4488 mm)
Width:
Approximately 69.1 inches (1755 mm)
Height:
Approximately 51.4 inches (1306 mm)
Wheelbase:
Approximately 103.1 inches (2619 mm)
Ground Clearance:
Approximately 5.0 inches (127 mm)
Interior
Passenger Volume:
Approximately 84.0 cu ft (2378 L)
Cargo
Cargo Volume Coupe:
Approximately 10.4 cu ft (294 L)
Cargo Volume Spyder Top Up:
Approximately 4.9 cu ft (139 L)
Weights
Curb Weight 4Cyl:
Approximately 3050-3150 lbs (1383-1429 kg)
Curb Weight V6 FWD:
Approximately 3150-3250 lbs (1429-1474 kg)
Curb Weight V6 AWD:
Approximately 3300-3400 lbs (1497-1542 kg)
Gross Vehicle Weight Rating:
Varies by model, refer to vehicle's placard.
Wheel And Tire
Wheelbase Bolt Pattern:
5x114.3 mm (5x4.5 inches)
Standard Tire Size 4Cyl:
P205/55R16
Optional Tire Size V6:
P215/50R17
Standard Wheel Size:
16-inch alloy
Optional Wheel Size:
17-inch alloy
🛡️ Safety Features
Ratings
NHTSA Front Impact Driver:
4/5 Stars (2000 model year data)
NHTSA Front Impact Passenger:
4/5 Stars (2000 model year data)
IIHS Front Offset Deform:
Acceptable (Good ratings for some model years)
Active Features
ABS:
Standard on most models, optional on base models.
Traction Control:
Optional on some models, particularly GT V6 AWD.
Passive Features
Airbags Front:
Driver and passenger front airbags standard.
Airbags Side:
Optional side-impact airbags available on some trims.
Seatbelts:
3-point front and rear seatbelts with pretensioners.
Convertible Structure:
Reinforced A-pillars and chassis for rollover protection in Spyder models.
💡 Technology Features
Infotainment
Audio System:
Factory AM/FM/CD player, optional premium audio systems with subwoofer.
Display:
Center console display for climate control and audio information.
Driver Assistance
Cruise Control:
Standard on most models.
Connectivity
Power Windows Locks:
Standard on most trims, power accessories common.
Climate Control
HVAC System:
Manual or automatic climate control systems.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,750 miles (6,000 km) or 3 months (severe service), 7,500 miles (12,000 km) or 6 months (normal service). Verify with manual.
Timing Belt Replacement Interval:
Every 60,000 miles (96,000 km) or 5 years, whichever comes first. Crucial for engine longevity.
Spark Plug Replacement Interval:
Refer to manual; typically 60,000-100,000 miles depending on plug type (e.g., platinum or iridium).
Coolant Flush Interval:
Every 30,000 miles (48,000 km) or 2 years.
Fluid Specifications
Engine Oil Type:
API Certified, SAE 5W-30 synthetic or conventional (check viscosity index based on climate).
Engine Oil Capacity:
4.5 US quarts (4.3 L) with filter for 4-cyl; 4.7 US quarts (4.4 L) with filter for V6. Verify with manual.
Brake Fluid Type:
DOT 3 or DOT 4
Power Steering Fluid Type:
ATF Dexron II or III
Known Issues
Timing Belt Failure:
Critical failure if not replaced on schedule, leading to catastrophic engine damage (interference engine).
Oil Leaks:
Common oil pan gasket and valve cover gasket leaks.
Suspension Wear:
Front struts, ball joints, and control arm bushings can wear prematurely.
V6 Engine Misfires:
Can occur due to ignition coil issues, spark plugs, or fuel injector problems.
Convertible Top Issues:
Hydraulic leaks, motor failure, and fabric wear on the Spyder models.
Part Numbers
Timing Belt Kit 4Cyl:
Example Part Number: Gates TCKWP304 (Includes belt, tensioner, idler, water pump)
Oil Filter 4Cyl:
Example Part Number: Fram PH3569, Wix 51348
Oil Filter V6:
Example Part Number: Fram PH3569, Wix 51348
📚 Vehicle History
Brand Heritage
Mitsubishi Motors:
Mitsubishi Motors Corporation, a Japanese multinational automotive manufacturer with a history dating back to 1917.
Model Evolution
Eclipse Generations:
The third generation (2000-2005) represented a significant redesign from the previous DSM (Diamond-Star Motors) platform.
Third Gen Design:
Featured a more rounded, aerodynamic styling compared to the angular second generation.
Production
Manufacturing Location:
Normal, Illinois, USA (via Diamond-Star Motors plant)
Production Period:
1999 (for 2000 model year) through 2005
🏆 Awards & Recognition
Recognitions
Car And Driver:
Frequently appeared on Car and Driver's Ten Best lists in earlier generations, continued sporty appeal.
Consumer Reports:
Reliability ratings varied by year and powertrain; refer to specific year's reports for detailed analysis.
