Mitsubishi Eclipse 2008 Repair Service Manual

Mitsubishi Eclipse 2008 Repair Service Manual

$17.99
$17.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 390929
Brand
Mitsubishi
Vehicle
Car
Models covered
4 D Series, Eclipse, Engines
Years
2008
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Eclipse
Year:
2008
Generation:
Fourth Generation (2006-2011)
Body Styles:
2-door Coupe (GS, GT), 2-door Convertible (GS, GT)
👋 Introduction
Market Position
Vehicle Segment:
Compact Sports Coupe/Convertible
Target Demographic:
Enthusiasts, young drivers, those seeking sporty styling and performance
Competitive Analysis
Key Competitors:
Honda Civic Si, Acura RSX, Nissan Sentra SE-R, Ford Mustang (lower trims), Chevrolet Camaro (older generations)
Key Features
Design:
Aggressive styling, available all-wheel drive (GT models), choice of coupe or convertible body styles
Manual Benefit:
Empowers owners with factory-level knowledge for confident maintenance and repair
Manual Benefit
Value Proposition:
Cost-effective alternative to dealership service, provides in-depth technical understanding
📋 Manual Details
Coverage Areas
Primary Focus:
Repair and Service
Scope:
Comprehensive vehicle maintenance, diagnostics, and repair
Page Count
Estimated Pages:
1000+
Manual Type
Type:
Repair Service Manual / Workshop Manual
Language
Language:
English
Format
Format:
PDF
Delivery Method:
Instant Download
Compatibility:
All Versions of Windows & Mac
Requirements:
Adobe PDF Reader, WinZip
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine assembly, disassembly, tuning, lubrication, cooling system, fuel system, exhaust system
Engine Management:
Ignition system, emission control systems, engine control module (ECM) diagnostics
Transmission:
Manual Transmission (F5M43), Automatic Transmission (W4A5A/W4A5B) - inspection, repair, overhaul, fluid specifications
Drivetrain:
Front-wheel drive system, drive shafts, CV joints, differential
Suspension:
Front suspension (MacPherson struts), rear suspension (multi-link), shock absorbers, springs, control arms, wheel alignment
Steering:
Power steering system, steering column, steering rack/gearbox
Brakes:
Front disc brakes, rear disc brakes, ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), brake fluid, caliper, rotor, pad replacement
Electrical System:
Battery, charging system (alternator), starting system (starter motor), lighting system, horn, wipers, power windows, mirrors, interior lighting
Body And Chassis:
Body panel removal and installation, doors, hood, trunk lid, bumpers, interior trim, seating systems
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) system diagnosis and repair
Interior And Exterior:
Body seals, glass, exterior trim, interior components
Diagnostic Trouble Codes:
OBD-II (On-Board Diagnostics II) codes and troubleshooting procedures
Procedures Included
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Disassembly:
Step-by-step instructions for removing components
Assembly:
Step-by-step instructions for reinstalling components
Repair:
Detailed repair procedures for various systems and components
Cleaning:
Specific cleaning instructions for certain parts or systems
Troubleshooting:
Diagnostic flowcharts and problem-solving guides
Specifications:
Critical torque values, clearances, and measurements
Technical Depth
Depth:
Covers from basic maintenance to complex component overhauls and diagnostics
Target Audience:
Professional technicians and advanced DIY mechanics
📊 Manual Specifications
File Format
Quality:
High Resolution PDF
Searchability:
Text-searchable content (if generated from original OCR'd factory manuals)
Print Quality
Printability:
Full Printable
Zoom Functionality:
Zoom IN/OUT capability for detailed viewing
Binding Type
Binding Type:
Digital (No physical binding)
Paper Type
Paper Type:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine Code Gs:
4G69 (2.4L MIVEC SOHC Inline-4)
Engine Code Gt:
6G75 (3.8L MIVEC SOHC V6)
Performance Gs
Horsepower Gs:
162 hp @ 6000 rpm
Torque Gs:
162 lb-ft @ 4000 rpm
Performance Gt
Horsepower Gt:
263 hp @ 6000 rpm
Torque Gt:
260 lb-ft @ 4500 rpm
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline (87 Octane recommended for GS, 91 Octane recommended for GT)
Engine Internals
Bore Stroke Gs:
87.0 mm x 96.0 mm
Bore Stroke Gt:
95.0 mm x 88.0 mm
Compression Ratio Gs:
9.5:1
Compression Ratio Gt:
10.0:1
🔧 Transmission
Standard
Gs Transmission:
5-speed Manual Transmission (F5M43)
Gt Transmission:
6-speed Manual Transmission (F5M43)
Optional
Gs Optional Transmission:
6-speed Automatic Transmission (W4A5A/W4A5B)
Gt Optional Transmission:
5-speed Automatic Transmission (W4A5A/W4A5B with Sportronic)
Features
AWD Availability:
Available on GT models with V6 engine and manual transmission
Fluid Specifications
Manual Transmission Fluid:
API GL-4, SAE 75W-90 (e.g., Mitsubishi DiaQueen LSD Gear Oil)
Automatic Transmission Fluid:
DIA QUEEN ATF-SP III (or equivalent)
📐 Dimensions
Exterior
Length:
180.5 inches (4585 mm)
Width:
71.5 inches (1816 mm)
Height Coupe:
53.0 inches (1346 mm)
Height Convertible:
53.7 inches (1364 mm)
Wheelbase:
105.7 inches (2685 mm)
Weights
Curb Weight Gs Coupe Manual:
3,131 lbs (1,420 kg)
Curb Weight Gt Coupe V6 Manual AWD:
3,560 lbs (1,615 kg)
Curb Weight Gt Convertible V6 Manual:
3,682 lbs (1,670 kg)
Cargo
Cargo Volume Coupe:
13.1 cu ft (371 L)
Cargo Volume Convertible:
6.3 cu ft (178 L) with top up
Wheels Tires
Wheel Size Gs:
17-inch alloy
Tire Size Gs:
215/50R17
Wheel Size Gt:
18-inch alloy
Tire Size Gt:
235/40R18
Bolt Pattern:
5 x 114.3 mm (5 x 4.5 inches)
🛡️ Safety Features
Ratings
NHTSA Frontal Crash Driver:
★★★★★ (5 Stars)
NHTSA Frontal Crash Passenger:
★★★★★ (5 Stars)
NHTSA Side Impact Front Seat:
★★★★ (4 Stars)
NHTSA Side Impact Rear Seat:
★★★★ (4 Stars)
IIHS Frontal Offset Driver:
Good
IIHS Side Impact:
Good
Active Features
ABS:
Standard (4-wheel disc brakes with ABS)
Traction Control:
Available (TCS)
Electronic Stability Control:
Available (Active Stability Control - ASC)
Passive Features
Airbags Front:
Standard (Driver and Passenger Airbags)
Airbags Side:
Standard (Front Side-Impact Airbags)
Seatbelts:
3-point seatbelts with pretensioners and load limiters
💡 Technology Features
Infotainment
Audio System:
Standard AM/FM/CD with 6 speakers, optional Rockford Fosgate premium audio system with subwoofer.
Navigation:
Optional factory-installed navigation system (may vary by trim and package)
Driver Assistance
Cruise Control:
Standard
Connectivity
Auxiliary Input:
Standard on most models (3.5mm auxiliary audio input jack)
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,750 miles (6,000 km) or 6 months, whichever comes first (severe conditions) or 7,500 miles (12,000 km) or 12 months (normal conditions).
Engine Air Filter Replacement:
Every 30,000 miles (48,000 km)
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or 12 months
Spark Plug Replacement Gs:
105,000 miles (168,000 km) (Iridium type)
Spark Plug Replacement Gt:
105,000 miles (168,000 km) (Iridium type)
Timing Belt Replacement:
Not applicable for 2.4L (uses maintenance-free timing chain). For 3.8L V6, it uses a timing chain, which is typically considered maintenance-free for the life of the engine but requires inspection.
Fluid Specifications
Engine Oil Capacity Gs:
4.5 quarts (4.3 L) with filter (4G69 engine)
Engine Oil Capacity Gt:
6.9 quarts (6.5 L) with filter (6G75 engine)
Engine Oil Viscosity Gs:
5W-30 (API SN or higher)
Engine Oil Viscosity Gt:
5W-30 (API SN or higher)
Coolant Type:
Mitsubishi Super Long Life Coolant (Green) or equivalent HOAT coolant
Brake Fluid Type:
DOT 3
Known Issues
Common Issues 2.4L:
Oil consumption in some higher mileage engines, potential issues with the crankshaft position sensor, water pump leaks.
Common Issues 3.8L V6:
Catalytic converter failure, occasional intake manifold gasket leaks, potential for carbon buildup in higher mileage engines.
Transmission Issues:
Some reports of automatic transmission slipping or harsh shifting, especially in earlier models. Manual transmission clutch wear is typical for the driving style.
Suspension Issues:
Worn front control arm bushings and rear sway bar links can lead to knocking noises and poor handling.
📚 Vehicle History
Brand Heritage
Manufacturer:
Mitsubishi Motors Corporation (Japan)
Model Evolution
Introduction Eclipse Nameplate:
1989 (as a joint venture with Chrysler)
Fourth Generation Launch:
2005 (for the 2006 model year)
Design Philosophy:
Shifted to a more muscular, aggressive styling compared to previous generations, featuring a 'shark nose' design.
Production End:
2011
Production
Manufacturing Plant:
Normal, Illinois, USA (Diamond-Star Motors plant)
🏆 Awards & Recognition
Recognitions
IIHS Top Safety Pick:
Yes, for certain model years and configurations.
Ratings
Consumer Reports:
Generally rated average to below average for reliability in its class during its production run.
