MASERATI QUATTROPORTE 2004-2012 Workshop Repair Manual

MASERATI QUATTROPORTE 2004-2012 Workshop Repair Manual

$17.99
$17.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 396590
Brand
Maserati
Vehicle
Cars
Models covered
QUATTROPORTE
Years
2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you โ€” re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
๐Ÿท๏ธ Basic Information
Identification
Make:
Maserati
Model:
Quattroporte
Model Generation:
M139
Model Years Covered:
2004-2012
Codes
Chassis Code:
M139
๐Ÿ‘‹ Introduction
Market Position
Vehicle Segment:
Luxury Grand Tourer Sedan
Brand Positioning:
High-performance, Italian luxury, sporting pedigree
Competitive Analysis
Key Competitors:
Porsche Panamera, Mercedes-Benz CLS-Class, BMW 7 Series, Audi A8, Jaguar XJ
Key Features
Design Philosophy:
Elegant Italian styling, spacious interior, performance-oriented
Manual Value Proposition:
Provides factory-level technical information for owners and independent specialists, enabling cost-effective repairs and maintenance.
Manual Utility
Target Audience:
Maserati Quattroporte owners (DIY enthusiasts), independent Maserati specialists, automotive repair shops
๐Ÿ“‹ Manual Details
Coverage Areas
Primary Coverage:
Workshop Repair and Service
Secondary Coverage:
Maintenance, Troubleshooting, Diagnostics, Parts Cataloguing
Page Count
Estimated Pages:
2000+
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF (Download)
๐Ÿ“– Manual Coverage
Systems Covered
Powertrain:
Engine System, Gearbox/Transmission, Clutch System, Radiator, Exhaust System, Intake System, Engine Control
Chassis:
Suspension, Wheel and Tire, Steering System, Brake System, Wheel Alignment
Electrical And Electronics:
Airbag-Sidebag, Electronic System, Battery System, Alarm System, Communication, Instrument Panel
Comfort And Convenience:
Air Conditioning, Heating System, Sunroof/Dashboard
Body:
Body Work
Procedures Included
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Repair:
Detailed step-by-step repair procedures for all covered systems
Troubleshooting:
Diagnostic flowcharts and common issue resolution
Diagnostics:
Component testing, system diagnostics, error code interpretation
Disassembly And Assembly:
Exploded views and reassembly instructions
Technical Depth
Depth:
Comprehensive (from basic maintenance to major overhauls)
Detail Level:
Detailed written procedures with pictures and diagrams
Illustration Quality:
High-quality illustrations, including exploded views
Special Tools:
Coverage of required special tools for specific repairs
Parts Information:
Includes a spare parts catalogue section
๐Ÿ“Š Manual Specifications
File Format
Format:
PDF
Searchability:
Likely searchable text content within PDF
Print Quality
Printability:
Fully printable (selected pages or whole manual)
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Type:
N/A (Digital Download)
Software Requirements
Reader:
PDF Reader (e.g., Adobe Acrobat Reader)
โš™๏ธ Engine Specifications
Primary Engine
Engine Code:
M139
Engine Type:
Naturally Aspirated V8
Displacement:
4.2 Liters (4199 cc)
Valvetrain:
DOHC (Dual Overhead Camshafts), 4 valves per cylinder
Timing System:
Variable Valve Timing (VVT)
Performance
Horsepower Est:
400 hp @ 7000 rpm (typical for the 4.2L)
Torque Est:
339 lb-ft @ 4750 rpm (typical for the 4.2L)
Fuel System
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Premium Unleaded Gasoline (91+ Octane Recommended)
Engine Management
ECU:
Bosch Motronic (specific variant may vary)
Cooling System
Coolant Type:
Proprietary Maserati coolant or equivalent (refer to manual for specific part number/spec)
Lubrication
Oil Type Est:
SAE 5W-40 Synthetic (refer to manual for specific Maserati approval)
Oil Capacity Est:
Approx. 8.5 - 9.5 Liters (with filter, refer to manual)
๐Ÿ”ง Transmission
Standard
Type 2004-2007:
6-speed ZF 6HP26 Automatic Transaxle
Optional
Type 2008+:
6-speed ZF 6HP26/6HP28 Automatic Transaxle (upgraded)
Features
Drivetrain:
Rear-Wheel Drive (RWD)
Transaxle Design:
Integrated rear axle unit with differential
Fluid Specifications
Transmission Fluid Type:
ZF LifeguardFluid 6 or equivalent (refer to manual for specific part number/spec)
๐Ÿ“ Dimensions
Exterior
Length:
Approx. 5097 mm (200.7 in)
Width:
Approx. 1895 mm (74.6 in) (excluding mirrors)
Height:
Approx. 1438 mm (56.6 in)
Weights
Curb Weight Est:
Approx. 1900-2000 kg (4189-4409 lbs)
Gross Vehicle Weight Rating Est:
Approx. 2500 kg (5512 lbs)
๐Ÿ›ก๏ธ Safety Features
Ratings
Crash Test Results:
Refer to Euro NCAP or NHTSA for specific model year tests, if available. Generally designed to high luxury standards.
Active Features
Braking System:
Four-wheel disc brakes (ventilated front and rear), ABS, EBD, Brake Assist
Stability Control:
Electronic Stability Control (ESC) / Maserati Stability Program (MSP)
Traction Control:
Traction Control System (TCS)
Passive Features
Airbags:
Frontal airbags, front side airbags, curtain airbags (standard/optional varies by year/market)
Seatbelts:
Pretensioning seatbelts with load limiters
Child Seat Anchors:
ISOFIX/LATCH system
๐Ÿ’ก Technology Features
Infotainment
Infotainment System:
Bespoke Maserati infotainment system with navigation, CD player, and premium sound system options (e.g., Bose).
Display:
Central dashboard screen for infotainment and vehicle settings.
Driver Assistance
Cruise Control:
Standard adaptive cruise control available on some trims/options.
Parking Assistance:
Parking sensors (front and rear), optional rearview camera on later models.
Connectivity
Connectivity Features:
Bluetooth for hands-free calling (availability varies by year and trim).
Suspension Tech
Adaptive Suspension:
Optional Skyhook adaptive damping system for adjustable ride comfort and handling.
๐Ÿ”ง Maintenance
Service Intervals
Oil Change Interval Est:
Every 10,000 - 15,000 km or 12 months (whichever comes first, refer to manual for exact specification).
Major Service Interval Est:
Significant service (e.g., timing belt/chain check, spark plugs) typically around 60,000 - 100,000 km.
Fluid Specifications
Brake Fluid Type:
DOT 4 or DOT 4+ (refer to manual for specific Maserati approval)
Coolant Specification:
Maserati blue coolant or equivalent (specific part number in manual)
Power Steering Fluid Type:
Hydraulic fluid compliant with Maserati specifications (refer to manual)
Known Issues
Common Issues:
Transmission valve body issues, Skyhook suspension (if equipped) faults, electrical gremlins, exhaust manifold cracks (older models), wear on interior materials.
Preventative Maintenance Focus:
Regular fluid and filter changes, inspection of suspension components, electrical system checks.
Parts Availability
Parts Catalog Use:
Essential for identifying correct part numbers for maintenance and repairs, given specialized nature of Maserati parts.
๐Ÿ“š Vehicle History
Brand Heritage
Brand Origin:
Founded in Bologna, Italy in 1914 by the Maserati brothers.
Brand Focus:
Renowned for luxury sports cars, racing heritage, and distinctive Italian design.
Model Evolution
Quattroporte Legacy:
The Quattroporte nameplate signifies a 'four-door' luxury sedan and has been used by Maserati for several generations since the 1960s.
M139 Introduction:
The M139 generation marked Maserati's return to the ultra-luxury sedan segment with a significant design and engineering overhaul.
Design Influence:
Designed by Pininfarina, emphasizing classic GT proportions and elegant lines.
Production
Production Period:
2003/2004 - 2012
Manufacturing Location:
Grugliasco, Turin, Italy (at the former Fiat Mirafiori plant)
๐Ÿ† Awards & Recognition
Recognitions
Design Awards:
Often praised for its striking Italian design, receiving accolades in automotive design circles.
Ratings
Performance Ratings:
Consistently rated as a strong performer in its segment, balancing luxury and sportiness.
Certifications
Manual Certification:
Factory-approved workshop manual standards, used by dealership technicians.
