2006 Hyundai Santa FE Service & Repair Manual Software

2006 Hyundai Santa FE Service & Repair Manual Software

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 195669
Brand
Hyundai
Vehicle
Cars
Models covered
Santa FE
Years
2006
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Hyundai
Model:
Santa Fe
Year:
2006
Codes
Chassis Code:
SM
👋 Introduction
Market Position
Segment:
Compact to mid-size SUV
Competitive Analysis
Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Chevrolet Equinox
Key Features
Features:
Practicality, value for money, available AWD, comfortable ride.
📋 Manual Details
Coverage Areas
Primary Coverage:
Full Service and Repair for 2006 Hyundai Santa Fe
Secondary Coverage:
Maintenance, Troubleshooting, Diagnostics, Component Replacement
Page Count
Estimated Pages:
Approximately 1500-2000 (Digital)
Manual Type
Type:
Service and Repair Manual Software
Language
Language:
English
Format
Format:
Online Software/Web-Based Access
📖 Manual Coverage
Systems Covered
Engine:
Complete engine diagnostics, overhaul, timing, fuel injection, ignition, cooling, lubrication systems.
Drivetrain:
Front-wheel drive (FWD) and All-wheel drive (AWD) systems, including differentials, axles, and driveshafts.
Transmission:
Automatic transmission (4-speed) service, repair, fluid specifications, and diagnostic procedures.
Brakes:
Front and rear brake systems (disc), ABS, EBD, brake pad and rotor replacement, caliper service, brake fluid.
Suspension Steering:
Front MacPherson strut and rear multi-link suspension, power steering system, wheel alignment.
Electrical:
Comprehensive wiring diagrams, charging system, starting system, lighting, instruments, power accessories, fuse/relay locations.
HVAC:
Heating, ventilation, and air conditioning (HVAC) system service, refrigerant handling, component testing.
Body Chassis:
Body panel removal/installation, interior trim, glass, bumpers, chassis component torque specifications.
Procedures Included
Maintenance:
Scheduled maintenance tasks, oil changes, filter replacements, fluid checks and changes, tune-ups.
Troubleshooting:
Diagnostic flowcharts and symptom-based troubleshooting for common issues.
Repair:
Step-by-step repair instructions for all major systems, including detailed diagrams.
Diagnostics:
OBD-II diagnostic trouble code (DTC) definitions and diagnostic procedures.
Technical Depth
Depth:
Factory-level technical data for DIY enthusiasts and professional technicians.
📊 Manual Specifications
File Format
Format:
Web-browser accessible software
Print Quality
Quality:
High-resolution digital graphics and text, scalable for clarity.
Binding Type
Binding:
N/A (Digital Access)
Paper Type
Paper:
N/A (Digital Access)
⚙️ Engine Specifications
Primary Engine
Engine Type:
2.7L V6 Lambda II (G6CU)
Displacement:
2656 cc (162.1 cu in)
Bore X Stroke:
86.5 mm x 75.1 mm (3.41 in x 2.96 in)
Compression Ratio:
9.8:1
Horsepower:
173 hp @ 6000 rpm
Torque:
178 lb-ft @ 4500 rpm
Fuel System
Fuel Delivery:
Electronic Fuel Injection (MPI)
Fuel Type:
Unleaded Regular 87 Octane
Engine Codes Variants
Alternative Engine:
2.4L Inline-4 (G4JS) - Fewer markets, 138 hp
🔧 Transmission
Standard
Transmission Type:
4-speed Automatic Transaxle (H-Matic)
Optional
Optional Transmission:
N/A for 2006 model year
Features
Drive Modes:
FWD and available AWD with electronically controlled coupling.
Fluid Specifications
Automatic Transmission Fluid:
Hyundai/Kia Genuine ATF SP-III or equivalent.
📐 Dimensions
Exterior
Length:
177.2 in (4498 mm)
Width:
71.3 in (1811 mm)
Height:
66.7 in (1694 mm)
Wheelbase:
104.3 in (2649 mm)
Interior
Passenger Volume:
Approx. 102 cu ft
Cargo
Cargo Volume Behind Rear Seat:
Approx. 30 cu ft
Cargo Volume With Rear Seat Folded:
Approx. 67 cu ft
Weights
Curb Weight FWD:
Approx. 3600 lbs (1633 kg)
Curb Weight AWD:
Approx. 3750 lbs (1701 kg)
🛡️ Safety Features
Ratings
NHTSA Frontal Driver:
5-Star
NHTSA Frontal Passenger:
5-Star
IIHS Roof Strength:
Good
Active Features
ABS:
Standard Anti-lock Braking System
Traction Control:
Available Traction Control System (TCS)
Electronic Stability Control:
Available Electronic Stability Control (ESC)
Passive Features
Airbags:
Standard front airbags, optional front side-impact airbags.
💡 Technology Features
Infotainment
Audio System:
AM/FM/CD stereo system, optional premium audio with subwoofer.
Driver Assistance
Cruise Control:
Standard cruise control
Connectivity
Aux Input:
Available auxiliary audio input jack.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months (whichever comes first).
Engine Air Filter Replacement:
Every 30,000 miles (48,000 km).
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or 12 months.
Transmission Fluid Change:
Every 60,000 miles (96,000 km) or 48 months.
Spark Plug Replacement:
Every 105,000 miles (168,000 km) for V6 iridium plugs.
Fluid Specifications
Engine Oil Type:
SAE 5W-20 API SM or higher
Engine Oil Capacity:
Approx. 4.8 US quarts (4.5 Liters) with filter change.
Coolant Type:
Hyundai Blue Super Long Life Coolant (or equivalent ethylene glycol-based coolant).
Brake Fluid Type:
DOT 3
Known Issues
Common Issues:
CV joint wear, minor electrical gremlins (e.g., power window switches), potential for catalytic converter issues.
📚 Vehicle History
Brand Heritage
Brand Origin:
South Korea
Model Evolution
Generation:
First Generation (2001-2006)
Production
Assembly Location:
Ulsan, South Korea; Beijing, China (for Chinese market)
🏆 Awards & Recognition
Recognitions
Safety Awards:
Received 5-star frontal crash test ratings from NHTSA.
