Ford Edge 2008 Service & Repair Workshop Manual

Ford Edge 2008 Service & Repair Workshop Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 451063
Brand
Ford
Vehicle
Cars
Models covered
Edge
Years
2008
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Ford
Model:
Edge
Year:
2008
Codes
Platform:
Ford CD3 Platform
👋 Introduction
Market Position
Segment:
Mid-size Crossover SUV
Competitive Analysis
Key Competitors:
Toyota Highlander, Honda Pilot, Nissan Murano, Chevrolet Equinox
Key Features
Platform Sharing:
Shared platform with Mazda CX-9 and Ford Fusion (CD3 platform)
Styling:
Distinctive 'Edge' styling, sporty crossover appearance
📋 Manual Details
Coverage Areas
Geographic Coverage:
North America (Primary)
Page Count
Estimated Page Count:
1500+
Manual Type
Type:
Factory Service & Repair Workshop Manual
Language
Language:
English
Format
Format:
Downloadable PDF
📖 Manual Coverage
Systems Covered
Powertrain:
Engine, Transmission, Drivetrain (AWD/FWD)
Chassis:
Suspension, Steering, Brakes, Wheels & Tires
Electrical:
Body Control Module (BCM), Powertrain Control Module (PCM), Lighting, HVAC Controls, Audio System, Power Accessories, Starting & Charging
Body:
Exterior Body Panels, Interior Trim, Seats, Glass, Doors, Hood, Tailgate
HVAC:
Air Conditioning, Heating, Ventilation System Components & Controls
Fuel System:
Fuel pump, injectors, fuel pressure regulator, evaporative emissions system.
Cooling System:
Radiator, water pump, thermostat, cooling fans, coolant hoses.
Exhaust System:
Catalytic converter, mufflers, exhaust pipes, oxygen sensors.
Procedures Included
Maintenance:
Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Top-offs, Inspections
Repair:
Engine Overhaul, Transmission Overhaul, Brake Component Replacement, Suspension Component Replacement, Electrical Component Diagnosis & Replacement
Troubleshooting:
Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting Guides, Electrical Schematics
Diagnostics:
Detailed diagnostic procedures for all major systems, including powertrain control, chassis electronics, and body electrical systems. Includes specific diagnostic charts and flowcharts.
Engine Repair:
Engine component removal and installation, cylinder head service, piston and connecting rod service, crankshaft service, timing chain/belt service.
Transmission Repair:
Transmission fluid and filter change, torque converter replacement, valve body service, complete transmission overhaul (for the 6F50 automatic).
Brake System Repair:
Brake pad and rotor replacement, caliper overhaul, brake line service, ABS component diagnosis and replacement.
Suspension Steering Repair:
Shock absorber and strut replacement, control arm service, ball joint replacement, power steering system service, steering rack replacement.
Technical Depth
Depth:
Comprehensive: From basic fluid checks to complete engine and transmission rebuilds, including diagnostic procedures.
Electrical Diagnostics:
Extensive coverage of the vehicle's electrical system, including wiring diagrams, connector pinouts, and diagnostic strategies for electrical faults.
📊 Manual Specifications
File Format
File Type:
PDF
Print Quality
Printability:
High Resolution, Printable (single pages or full manual)
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Quality:
N/A (Digital Download)
⚙️ Engine Specifications
Primary Engine
Engine Code:
3.5L V6 (Duratec 35)
Displacement:
3.5 Liters (3496 cc)
Performance
Horsepower:
265 hp @ 6250 rpm
Torque:
250 lb-ft @ 4500 rpm
Fuel System
Injection Type:
Sequential Electronic Fuel Injection (SEFI)
Fuel Type:
Unleaded Gasoline (87 Octane Recommended)
Engine Components
Block Material:
Aluminum Alloy
Cylinder Head Material:
Aluminum Alloy
Valvetrain:
DOHC, 4 valves per cylinder, Variable Cam Timing (VCT)
🔧 Transmission
Standard
Transmission Type:
6-speed Automatic (6F50)
Optional
Drivetrain:
All-Wheel Drive (AWD) Optional on most trims, Standard on SEL AWD and Limited AWD
Features
Transmission Features:
SelectShift Automatic with manual mode
Fluid Specifications
Transmission Fluid Type:
Mercon LV (or equivalent)
📐 Dimensions
Exterior
Length:
189.7 inches (4818 mm)
Width:
76.1 inches (1933 mm)
Height:
66.9 inches (1700 mm)
Wheelbase:
111.7 inches (2837 mm)
Weights
Curb Weight FWD:
4,085 lbs (1853 kg)
Curb Weight AWD:
4,237 lbs (1922 kg)
Towing Capacity:
3,500 lbs (1588 kg) (with optional towing package)
🛡️ Safety Features
Ratings
NHTSA Front Crash Rating:
5-Star (Driver and Passenger)
NHTSA Side Crash Rating:
5-Star (Front and Rear Seat)
IIHS Side Impact Rating:
Good
Active Features
ABS:
Standard Anti-lock Braking System (ABS)
Esp:
Standard Electronic Stability Control (AdvanceTrac with Roll Stability Control)
Traction Control:
Standard Traction Control
Passive Features
Airbags:
Front Airbags, Front Side-Impact Airbags, Side-Curtain Airbags (First and Second Row)
Seatbelts:
Three-point safety belts with pretensioners and load limiters
💡 Technology Features
Infotainment
Infotainment System:
Ford SYNC (Optional on some trims, standard on Limited and SEL with Premium Package), offering voice-activated controls for audio and phone.
Audio Options:
Premium Sony audio system available.
Driver Assistance
Parking Assist:
Rear parking sensors available.
Connectivity
Connectivity Features:
Bluetooth connectivity for hands-free calling (with SYNC).
Lighting
Headlights:
Halogen projector headlights with available HID (High-Intensity Discharge) Xenon headlights on higher trims.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 7,500 miles (12,000 km) or 6 months (whichever comes first) with synthetic blend oil; 10,000 miles (16,000 km) or 12 months with full synthetic oil.
Tire Rotation Interval:
Every 7,500 miles (12,000 km)
Cabin Air Filter Replacement:
Every 15,000-20,000 miles (24,000-32,000 km) or as needed
Fluid Specifications
Engine Oil Specification:
SAE 5W-20, meeting Ford Specification WSS-M2C153-H (Full Synthetic Recommended)
Coolant Specification:
Ford Premium Long Life Engine Coolant (Green), HOAT (Hybrid Organic Acid Technology)
Brake Fluid Specification:
DOT 3
Known Issues
Common Complaints:
Occasional transmission issues (harsh shifting, delayed engagement), minor electrical gremlins, HVAC system issues (blend door actuator failure).
📚 Vehicle History
Brand Heritage
Ford Brand Focus:
Ford's long history of producing durable and popular vehicles across various segments.
Model Evolution
First Generation:
The 2008 model year marks the first generation of the Ford Edge, introduced for the 2007 model year.
Production
Assembly Location:
Oakville Assembly Plant, Ontario, Canada
🏆 Awards & Recognition
Recognitions
Safety Award:
IIHS Top Safety Pick (for earlier models, consistency across years varies)

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
