Citroen Ax 1987-1997 Workshop Service Repair Manual

Citroen Ax 1987-1997 Workshop Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 396366
Brand
Citroen
Vehicle
Cars
Models covered
AX
Years
1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Citroën
Model:
AX
Year Range:
1987-1997
Codes
Platform Code:
PSA PF1
👋 Introduction
Market Position
Vehicle Segment:
Subcompact hatchback, city car.
Target Audience:
Budget-conscious buyers, first-time car owners, individuals seeking an economical and maneuverable urban vehicle.
Competitive Analysis
Key Competitors:
Ford Fiesta, Volkswagen Polo, Peugeot 205, Renault Supercinq, Fiat Uno.
Key Features
Design Philosophy:
Lightweight construction, compact dimensions, fuel efficiency, aerodynamic design.
Unique Selling Points:
Innovative use of plastics and composite materials to reduce weight, surprisingly spacious interior for its size, good handling.
Manual Value Proposition
Value To Owner:
Enables owners to perform maintenance and repairs themselves, saving significant costs on dealership service. Facilitates accurate diagnostics and proactive problem-solving.
📋 Manual Details
Coverage Areas
Models Covered:
Citroën AX (all styles and variations within the 1987-1997 model years)
Page Count
Estimated Page Count:
Hundreds of pages (exact count not specified, but described as comprehensive)
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF Download
📖 Manual Coverage
Systems Covered
Engine Systems:
Engine mechanical (including assembly, disassembly, tuning), fuel system, ignition system, cooling system, lubrication system, emissions control.
Transmission Systems:
Manual transmission, clutch, transaxle assembly, and related components.
Drivetrain Systems:
Front-wheel drive system, driveshafts, CV joints.
Suspension Systems:
Front and rear suspension, shock absorbers, springs, control arms, bushings.
Steering Systems:
Steering rack, tie rods, steering column, power steering (if applicable to specific models).
Brake Systems:
Front and rear brakes (disc and drum), hydraulic system, parking brake, ABS (if applicable).
Electrical Systems:
Battery, charging system, starting system, lighting system, instruments and indicators, wiring diagrams, fuses, relays, ECUs.
Body And Chassis Systems:
Body panels, doors, windows, interior trim, frame, rust prevention.
HVAC Systems:
Heating, ventilation, and air conditioning (if applicable).
Fuel And Exhaust Systems:
Fuel tank, fuel pump, fuel lines, exhaust manifold, catalytic converter, muffler.
Procedures Included
Maintenance Procedures:
Routine maintenance checks, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt adjustments.
Repair Procedures:
Step-by-step repair instructions for all major mechanical and electrical components, including engine overhaul, transmission rebuild, brake caliper replacement, suspension component repair.
Troubleshooting Guidance:
Diagnostic procedures for common problems, symptom-based troubleshooting, fault code interpretation (if applicable).
Electrical Diagnostics:
Detailed wiring diagrams, circuit testing procedures, diagnostic steps for electrical faults.
Specifications And Torques:
Tightening torques for critical fasteners, engine clearances, fluid capacities, electrical component specifications.
Technical Depth
Depth:
Comprehensive; covers everything from basic maintenance to complete engine and transmission rebuilds, including detailed electrical system diagnostics.
📊 Manual Specifications
File Format
Format:
PDF
Compatibility:
Compatible with all PC-based Windows operating systems and Mac.
Print Quality
Printability:
Printable without any restriction; individual pages or the entire manual can be printed.
Binding Type
Binding:
Digital download (no physical binding)
Paper Type
Paper Type:
Not applicable (digital format)
Delivery Method
Delivery:
Instant download link provided on checkout page after payment.
Software Requirements
Required Software:
Adobe PDF Reader
⚙️ Engine Specifications
Primary Engine
Engine Codes Examples:
TU1 (1.1L), TU2 (1.3L), XU5 (1.6L - GTi).
Performance
Power Output Range:
Approximately 50 hp (1.1L) to 100 hp (1.3 GTi).
Torque Output Range:
Approximately 80 Nm (1.1L) to 120 Nm (1.3 GTi).
Fuel System
Fuel Delivery:
Carburetor (early models) or multi-point fuel injection (later models, GTi).
Fuel Type
Fuel Type:
Unleaded gasoline.
Engine Layout
Configuration:
Inline 4-cylinder, transverse mounting.
Cooling System
Cooling Type:
Liquid-cooled.
🔧 Transmission
Standard
Type:
5-speed manual transaxle.
Optional
Type:
Some models may have offered a 3-speed automatic transmission.
Features
Drive Type:
Front-wheel drive.
📐 Dimensions
Exterior
Length:
Approx. 3600 mm (141.7 in)
Width:
Approx. 1620 mm (63.8 in)
Height:
Approx. 1370 mm (53.9 in)
Weights
Curb Weight:
Approx. 750-850 kg (1650-1870 lbs) depending on engine and specification.
🛡️ Safety Features
Ratings
Euro Ncap Rating:
Not rated under modern Euro NCAP standards.
Active Features
Braking System:
Standard front disc brakes, rear drum brakes. Later models or higher trims may have had rear discs.
Stability Control:
Not typically available on most models.
Passive Features
Airbags:
Driver-side airbag became standard on later models, particularly in certain markets.
Seatbelts:
Front three-point seatbelts, rear lap belts.
💡 Technology Features
Infotainment
Audio System:
Basic radio/cassette player on most models. Optional CD players on later or higher trims.
Dashboard Features:
Simple analog gauges for speed, RPM, fuel, and temperature. Warning lights for various systems.
Driver Assistance
Cruise Control:
Not a common feature, typically found only on higher-spec models or optional.
Connectivity
Bluetooth:
Not available.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 10,000 km or 12 months (refer to manual for specific engine type).
Timing Belt Replacement:
Crucial; consult manual for specific interval (e.g., 80,000-120,000 km or 5-7 years) due to potential for catastrophic engine damage if it fails.
Fluid Specifications
Engine Oil Specification:
API SG or higher, SAE 10W-40 or 5W-40 (check manual for ambient temperature suitability).
Coolant Specification:
Ethylene glycol based antifreeze, mixed 50/50 with distilled water. Consult manual for specific type (e.g., G11).
Brake Fluid Specification:
DOT 3 or DOT 4 (check manual for specific recommendation).
Transmission Fluid Specification:
API GL-4, SAE 75W-80 or 75W-90 gear oil (check manual).
Known Issues
Electrical Gremlins:
Common for older vehicles; wiring loom degradation, intermittent connection issues in lighting and dashboard.
Suspension Wear:
Bushings, ball joints, and shock absorbers can wear over time, leading to noise and handling issues.
Rust And Corrosion:
Wheel arches, sills, and underbody are prone to rust, especially in regions with road salt.
Carburetor Issues:
Older carbureted models may require periodic adjustment or cleaning for optimal performance.
📚 Vehicle History
Brand Heritage
Manufacturer:
Citroën, a French automobile manufacturer known for innovative design and engineering.
Model Evolution
Introduction Year:
1986.
Facelifts:
Minor updates and trim changes occurred throughout its production run, including revisions to bumpers, lighting, and interior styling.
Production
Production Period:
1986-1997.
Manufacturing Locations:
Primarily France and Spain.
🏆 Awards & Recognition
Recognitions
European Car Of The Year:
Runner-up for European Car of the Year in 1987.
Ratings
Consumer Reports Rating:
Specific ratings vary by year and test, but generally praised for economy and practicality.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
