2008 POLARIS SPORTSMAN 500 EFI / X2 / TOURING / 500 H.O. * DIY Service / Repair / Maintenance Manual 08

2008 POLARIS SPORTSMAN 500 EFI / X2 / TOURING / 500 H.O. * DIY Service / Repair / Maintenance Manual 08

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 25215
Brand
Polaris
Vehicle
ATV
Models covered
SPORTSMAN 500 EFI, SPORTSMAN 500 H.O., SPORTSMAN TOURING, SPORTSMAN X2
Years
2008
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Polaris
Model:
Sportsman 500
Year:
2008
Sub Models:
EFI, X2, Touring, 500 H.O.
👋 Introduction
Market Position
Target User:
DIY enthusiasts, ATV owners seeking to perform their own maintenance and repairs, saving on dealership labor costs.
Competitive Analysis
Value Proposition:
Provides dealer-level technical information, enabling users to perform complex repairs and maintenance with confidence, mirroring professional service.
Key Features
Accuracy:
Same information used by Polaris dealership technicians, ensuring high accuracy and reliability.
Comprehensiveness:
Covers all aspects of the ATV, from basic checks to complete rebuilds.
Usability:
User-friendly, with clear instructions, diagrams, and easy navigation.
📋 Manual Details
Coverage Areas
Primary Coverage:
Service, Repair, Maintenance
Secondary Coverage:
Troubleshooting, Diagnostics, Component Overhaul
Page Count
Estimated Page Count:
High (Specific count not provided, but described as comprehensive and dealer-level)
Manual Type
Type:
Digital Service / Repair Manual
Language
Language:
English
Format
Format:
PDF Download
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine overhaul, valve adjustments, piston/cylinder inspection, crankshaft, camshaft, timing systems
Fuel System:
EFI system (throttle body, injectors, fuel pump, pressure regulator), fuel tank, lines, filters
Ignition System:
Ignition coil, spark plug, CDI unit, wiring schematics
Transmission Drivetrain:
CVT system (clutches, belt), gearcase, differential, driveshafts, AWD system
Suspension Steering:
Front and rear suspension components (shocks, control arms, bushings), steering linkage, handlebars
Braking System:
Hydraulic brake system (master cylinders, calipers, lines, rotors), parking brake
Electrical System:
Battery, starter, alternator, lighting (headlights, taillights, brake lights), instrumentation, wiring diagrams
Cooling System:
Radiator, fan, coolant hoses, thermostat
Chassis Frame:
Frame inspection, body panels, racks, seat, footwells
Procedures Included
Maintenance Tasks:
Oil changes, filter replacements (oil, air, fuel), spark plug replacement, coolant flushes, lubrication
Diagnostic Procedures:
Troubleshooting common symptoms, fault code interpretation (if applicable for EFI), electrical diagnostics
Repair Procedures:
Engine component replacement, transmission overhaul, brake caliper rebuild, suspension component replacement
Assembly Disassembly:
Detailed instructions for disassembling and reassembling major components and the entire ATV
Technical Depth
Depth:
Comprehensive: Covers basic maintenance to full engine and transmission rebuilds, including detailed torque specifications and clearances.
📊 Manual Specifications
File Format
Format:
PDF
File Size:
52 MB
Print Quality
Printability:
Print only what you need, with option to enlarge images.
Image Quality:
High-resolution diagrams and illustrations suitable for detailed viewing.
Binding Type
Binding:
Digital (No physical binding)
Paper Type
Paper Type:
Digital (No physical paper type)
Navigation
Searchability:
Searchable content and index for quick information retrieval.
Compatibility
Operating Systems:
Windows (Vista, XP, ME, 98, NT, 2000) and Mac OS.
⚙️ Engine Specifications
Primary Engine
Type:
4-Stroke, Liquid-Cooled, SOHC, 4-Valve
Displacement:
499 cc (for the 500 H.O. and EFI variants)
Bore X Stroke:
93.25 mm x 72 mm (Typical for 500 H.O. variants)
Compression Ratio:
10.0:1 (Typical for 500 H.O. variants)
Performance
Horsepower:
Approximately 34 HP (varies slightly by specific sub-model and tuning)
Torque:
Not specified in product info, but torque figures are detailed in the manual.
Fuel System
Injection Type:
Electronic Fuel Injection (EFI) for applicable models
Fuel Type:
Unleaded gasoline, 87 octane minimum
Ignition System
Ignition Type:
Digital CDI (Capacitor Discharge Ignition)
🔧 Transmission
Standard
Type:
Automatic, Variable Transmission (CVT) with Engine Braking
Drive Modes:
2WD/4WD with Polaris's on-demand, 4-mode AWD system (ADC - Automatic Descent Control).
Optional
Gears:
High, Low, Neutral, Reverse, Park
Features
Clutch Type:
Primary and Secondary Clutch assembly
Fluid Specifications
Gearcase Oil:
Refer to manual for specific Polaris synthetic gearcase lubricant or equivalent SAE 75W-90 GL-5.
📐 Dimensions
Exterior
Length:
Approx. 83" (210.8 cm) for standard Sportsman 500, varies slightly for X2/Touring
Width:
Approx. 46" (116.8 cm)
Height:
Approx. 45" (114.3 cm)
Wheelbase
Wheelbase:
Approx. 50.5" (128.3 cm)
Weights
Dry Weight:
Approx. 650-700 lbs (295-317.5 kg), varies by sub-model
Towing Capacity:
1500 lbs (680 kg)
Rack Capacity Front:
100 lbs (45.4 kg)
Rack Capacity Rear:
200 lbs (90.7 kg)
🛡️ Safety Features
Ratings
Atv Safety Standards:
Designed to meet ANSI standards for recreational off-highway vehicles. Manual provides safety guidelines.
Active Features
Braking System Type:
Hydraulic disc brakes front and rear, sealed, wet multi-disc rear brake
Parking Brake:
Yes, integrated into transmission/rear brake system
Passive Features
Lighting:
Dual headlights, taillight, brake light
Handlebars:
Tapered, rubber-mounted handlebars for vibration damping.
💡 Technology Features
Infotainment
Instrumentation:
Digital LCD display showing speedometer, odometer, trip meter, RPM, fuel level, clock, AWD indicator, high-temperature warning.
Driver Assistance
AWD System:
Polaris's Automatic On-Demand All-Wheel Drive (AWD) system that engages the front drive when rear wheel slip is detected.
Connectivity
Charging System:
12V DC charging system with a battery, capable of powering accessories.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or 6 months. Manual provides detailed procedure and oil type.
Air Filter Cleaning:
Every 25 hours or as needed based on conditions. Manual details cleaning/replacement.
Spark Plug Replacement:
Every 250 hours or annually. Manual specifies gap and torque.
Cv Belt Inspection:
Every 50 hours. Manual details inspection for wear and damage.
Fluid Specifications
Engine Oil:
Polaris PS-4 5W-50 Full Synthetic or equivalent meeting API CI-4 specification. Manual provides exact capacity.
Coolant:
Ethylene glycol-based antifreeze mixed 50/50 with distilled water. Manual specifies capacity.
Brake Fluid:
DOT 3 or DOT 4 brake fluid. Manual specifies type and procedure for bleeding.
Known Issues
Common Wear Items:
CV joint boots, tie rod ends, ball joints, suspension bushings due to off-road use. CVT belt wear.
Efi System:
Throttle body cleaning and TPS (Throttle Position Sensor) calibration are common maintenance items for optimal performance.
📚 Vehicle History
Brand Heritage
Manufacturer:
Polaris Industries Inc.
Model Evolution
Sportsman Line:
The Sportsman line has been a cornerstone of Polaris's ATV offerings, known for its comfort, versatility, and off-road capability. The 500cc engine platform has been a popular and enduring choice.
Production
Manufacturing Location:
Primarily manufactured in Roseau, Minnesota, USA.
Market Segment:
Mid-size to large utility and recreational ATVs.
🏆 Awards & Recognition
Recognitions
Model Reputation:
The Polaris Sportsman line has consistently received praise for its ride quality, comfort, and robust utility features within the ATV market.
Industry Awards:
While specific awards for the 2008 Sportsman 500 aren't detailed, the Sportsman series as a whole has been a strong performer and benchmark in the ATV industry.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
