Mitsubishi Outlander 2007-2009 Workshop Service Repair Manual

Mitsubishi Outlander 2007-2009 Workshop Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 447300
Brand
Mitsubishi
Vehicle
Cars
Models covered
Outlander
Years
2007, 2008, 2009
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Outlander
Year Range:
2007-2009
Codes
Chassis Code Generation 2:
CU/CF Series
👋 Introduction
Market Position
Segment:
Compact Crossover SUV
Competitive Analysis
Key Competitors 2Nd Gen:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Subaru Forester
Key Features
Platform:
Shared platform with Mitsubishi Lancer (GS platform)
Design Philosophy:
Sporty and car-like handling with SUV practicality, available all-wheel drive (AWC)
Value Proposition
Diy Repairs:
Enables owners and independent technicians to perform a wide range of repairs and maintenance, saving on dealership costs.
📋 Manual Details
Coverage Areas
Coverage:
Comprehensive repair and overhaul for 2007-2009 Mitsubishi Outlander
Page Count
Page Count:
Not Specified (typically several thousand pages for a full workshop manual)
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine:
Engine mechanical, engine management, lubrication, cooling, fuel, ignition, exhaust systems
Transmission:
Transmission (automatic and manual, if applicable), clutch, driveline components
Electrical:
Complete electrical system, wiring diagrams, lighting, charging system, starting system, body electronics, infotainment
Chassis:
Suspension (front and rear), steering system, brake system (hydraulic and parking), wheels and tires
Body:
Body construction, interior trim, exterior trim, doors, windows, glass, HVAC system
Fuel System:
Fuel pump, fuel filter, fuel injectors, fuel tank, evaporative emission control system.
Ignition:
Ignition coils, spark plugs, crankshaft position sensor, camshaft position sensor.
Lubrication System:
Oil pump, oil filter, oil pan, oil passages, lubrication schedules.
Exhaust:
Exhaust manifold, catalytic converter, muffler, oxygen sensors.
Procedures Included
Maintenance:
Scheduled maintenance, tune-ups, fluid changes, filter replacements
Repair:
Removal and installation procedures for all major components, component overhauls, diagnostic procedures
Diagnostics:
Troubleshooting guides, symptom-based diagnostics, diagnostic trouble codes (DTCs)
Assemblies Disassemblies:
Detailed procedures for the assembly and disassembly of all vehicle systems and components.
Technical Depth
Depth:
Detailed overhaul procedures, special tool identification and usage, torque specifications, clearances, and tolerances
Special Tools:
References special Mitsubishi tool numbers and descriptions for specific repair operations.
Manual Completeness
Completeness:
Stated to be a complete service manual for all necessary repairs.
📊 Manual Specifications
File Format
File Type:
PDF
Print Quality
Printable:
Yes
Binding Type
Binding:
Not Applicable (Digital PDF)
Paper Type
Paper Quality:
Not Applicable (Digital PDF)
Delivery
Delivery Method:
Electronic Delivery via Email
⚙️ Engine Specifications
Primary Engine
Engine Code Usdm:
4G69 (2.4L SOHC)
Engine Displacement 2.4L:
2378 cc
Engine Configuration 2.4L:
Inline 4-cylinder
Horsepower 2.4L:
160-165 hp @ 6000 rpm (varies slightly by year/market)
Torque 2.4L:
162-165 lb-ft @ 4000 rpm (varies slightly by year/market)
Optional Engine
Engine Code V6:
6B31 (3.0L SOHC MIVEC V6)
Engine Displacement 3.0L:
2998 cc
Engine Configuration 3.0L:
60-degree V6
Horsepower 3.0L:
215-220 hp @ 6250 rpm
Torque 3.0L:
200-205 lb-ft @ 3750 rpm
Fuel System
Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Engine Management
ECU Type:
Proprietary Mitsubishi Engine Control Unit (ECU)
🔧 Transmission
Standard
Transmission Type 2.4L:
5-speed Manual Transmission (5MT)
Optional
Transmission Type 2.4L Optional:
Continuously Variable Transmission (CVT) - Called 'Invecs-III'
Transmission Type 3.0L:
6-speed Automatic Transmission (6AT) - Sportronic with paddle shifters on some trims
Features
Awc System:
Available electronically controlled All-Wheel Control (AWC) system with multiple drive modes (e.g., Normal, Snow, Lock)
📐 Dimensions
Exterior
Length:
Approx. 178.8 inches (4542 mm)
Width:
Approx. 70.9 inches (1801 mm)
Height:
Approx. 66.1 inches (1679 mm)
Wheelbase:
Approx. 103.3 inches (2624 mm)
Weights
Curb Weight Min:
Approx. 3461 lbs (1570 kg) for 2.4L FWD
Curb Weight Max:
Approx. 3881 lbs (1760 kg) for 3.0L AWD
Cargo
Cargo Volume Behind 2Nd Row:
Approx. 21.7 cubic feet (614 liters)
Cargo Volume Max:
Approx. 64.4 cubic feet (1823 liters) with rear seats folded
🛡️ Safety Features
Ratings
NHTSA Front Impact Driver 2007-09:
5-Star
NHTSA Front Impact Passenger 2007-09:
5-Star
NHTSA Side Impact Front Passenger 2007-09:
5-Star
NHTSA Side Impact Rear Passenger 2007-09:
5-Star
IIHS Rollover 2007-09:
4-Star (often rated 'Good' for specific tests)
Active Features
ABS:
Standard Anti-lock Braking System
Traction Control:
Standard Traction Control System (TCS)
Electronic Stability:
Standard Electronic Stability Control (ESC) - Mitsubishi Active Stability and Traction Control (MSTC)
Passive Features
Airbags:
Front, front-side, and side-curtain airbags (standard on most trims)
💡 Technology Features
Infotainment
Audio System:
Available Rockford Fosgate premium audio system, touchscreen infotainment units on higher trims.
Connectivity:
Auxiliary audio input (standard), available Bluetooth hands-free calling on higher trims.
Driver Assistance
Cruise Control:
Standard cruise control
Keyless Entry:
Available keyless entry and push-button start on premium trims.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,750 to 7,500 miles (6,000 to 12,000 km) or 6 months, depending on driving conditions and oil type used.
Engine Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed.
Cabin Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed.
Spark Plugs 2.4L:
Replace at approximately 100,000 miles (160,000 km) - Consult manual for specific type (e.g., Iridium).
Transmission Fluid Cvt:
Change at approximately 60,000 miles (96,000 km) - Requires specific CVT fluid.
Transmission Fluid 6At:
Change at approximately 60,000 miles (96,000 km) - Requires specific ATF.
Fluid Specifications
Engine Oil 2.4L:
SAE 5W-30 API SN or ILSAC GF-5; Capacity: Approx. 4.8 US quarts (4.5 liters) with filter.
Engine Oil 3.0L:
SAE 5W-30 API SN or ILSAC GF-5; Capacity: Approx. 4.8 US quarts (4.5 liters) with filter.
Coolant:
DIA-CHEM RR 52010 (or equivalent long-life, pink/red coolant)
Brake Fluid:
DOT 3 or DOT 4
Known Issues
Cvt Issues:
Some early models with CVT transmissions have reported premature failure or 'slipping' symptoms, often related to fluid degradation or solenoid issues.
Power Steering:
Occasional reports of power steering pump leaks or noisy pumps.
Catalytic Converter:
Some vehicles have experienced premature catalytic converter failure, especially in regions with higher sulfur fuel content.
📚 Vehicle History
Brand Heritage
Company Origin:
Japan (founded 1870 as a shipping firm)
Model Evolution
Generation 2 Launch Year:
2007
Generation 2 Design Direction:
Redesigned from the ground up, moving to a more car-like monocoque chassis, shared with the Lancer platform.
Production
Manufacturing Plant:
Japan (Mizushima Plant)
🏆 Awards & Recognition
Recognitions
Safety Award IIHS Top Pick:
While specific 'Top Pick' awards can vary year by year, this generation generally performed well in IIHS crash testing, achieving good ratings in many categories.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.

View full details
  • Instant download Link on the order page and in your inbox within a minute.
  • Secure checkout Encrypted Shopify payments — card, PayPal, Apple Pay, Google Pay.
  • Print-ready PDF Searchable text; print only the pages you take to the bench.
  • Coverage check Not sure it fits? Send the model and VIN before you buy.
