Polaris Sportsman 400 500 Xplorer 1996-2003 Service Repair Workshop Manual 1997 1998 1999 2000 2001 2002

Polaris Sportsman 400 500 Xplorer 1996-2003 Service Repair Workshop Manual 1997 1998 1999 2000 2001 2002

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 87930
Brand
Polaris
Vehicle
ATV
Models covered
Misc, Sportsman 400, Sportsman 500, Xplorer
Years
1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
This manual covers the Polaris Sportsman 400, Sportsman 500, and Xplorer models produced between 1996 and 2003. A pioneer in the ATV industry, these versatile machines were developed for a range of uses, from trail riding to utility tasks. Known for their robust engineering and reliable performance, these ATVs feature a 4-stroke engine, automatic PVT transmission with selectable 2WD/AWD, and hydraulic disc brakes. The Sportsman series is celebrated for its comfort and capability, while the Xplorer models often offered enhanced trail performance. This comprehensive service, repair, and workshop manual provides in-depth technical information essential for the maintenance and repair of your ATV. It details procedures for all major systems, including the powertrain, chassis, and electrical components, as well as bodywork. The manual covers scheduled maintenance, troubleshooting common issues, detailed disassembly and assembly instructions, and critical technical specifications such as torque values and fluid capacities. This resource is designed to assist ATV owners, independent repair shops, and DIY mechanics in effectively maintaining and repairing these vehicles, ensuring optimal performance and longevity.
