Mercury Mariner

Mercury Mariner (outboard) 135-150-150 XR6-150 Magnum III-150 EFI- 175 EFI-200 EFI 150-200-225 (1992 & Newer) (Super Magnum-ProMax) Service Manual

Mercury Mariner (outboard) 135-150-150 XR6-150 Magnum III-150 EFI- 175 EFI-200 EFI 150-200-225 (1992 & Newer) (Super Magnum-ProMax) Service Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Vehicle data plateRef 24656
Brand
Mercury Mariner
Vehicle
Marine
Models covered
135, 150, 150 EFI, 150 Magnum III, 150 XR6, 175 EFI, 200 EFI, 225, Beta Marine, Magnum Models, Mercury, Outboard Engines, ProMax, Super Magnum
Years
1992
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mercury Mariner
Model:
Outboard
Year:
1992 & Newer
Generation:
Super Magnum-ProMax Series
📋 Manual Details
Publication
Manual Type:
Service and Repair Manual
Language:
English
Format:
PDF Download
Content
Target Audience:
Do-it-yourselfer and Experienced Mechanic
Coverage:
Step-by-step instructions, hundreds of photos and illustrations, detailed substeps, notes, cautions, warnings
⚙️ Engine Specifications
Engine 135
Engine Type:
2-Stroke
Displacement:
Approx. 2.0L (122 cu in)
Power:
135 HP
Engine 150
Engine Type:
2-Stroke
Displacement:
Approx. 2.0L (122 cu in)
Power:
150 HP
Engine 175 Efi
Engine Type:
2-Stroke (EFI)
Displacement:
Approx. 2.5L (153 cu in)
Power:
175 HP
Engine 200 Efi
Engine Type:
2-Stroke (EFI)
Displacement:
Approx. 2.5L (153 cu in)
Power:
200 HP
Engine 225
Engine Type:
2-Stroke
Displacement:
Approx. 3.0L (183 cu in)
Power:
225 HP
Engine Promax
Engine Type:
2-Stroke (High Performance)
Displacement:
V6
Power:
Up to 225 HP (depending on specific ProMax model)
🔧 Transmission
Gearcase
Type:
Outboard Gearcase
Gear Ratio:
Varies by specific model and application (refer to manual for details)
🔧 Maintenance
Lubrication
Recommended Oil Type:
Mercury Outboard 2-Stroke Oil (TCW3 certified)
Oil Capacity Gearcase:
Varies by model, typically around 16-20 oz (refer to manual for exact capacity)
Cooling System
Cooling System Type:
Water Cooled
Water Pump Impeller Replacement Interval:
Recommended every 2-3 years or as needed based on operating conditions
Ignition
Spark Plug Type:
Specific Mercury or Champion spark plugs (refer to manual for exact part number)
Spark Plug Gap:
Refer to specific engine model specifications in the manual
📄 Electrical
Charging System
Charging System Type:
Alternator
Output Amperage:
Typically 10-20 Amps (Varies by model)
📄 Fuel System
Fuel Delivery
Fuel Type:
Unleaded gasoline
Fuel Octane Rating:
90-92 Octane Recommended (refer to manual for specific requirements)
Fuel Filter Replacement:
Recommended annually or as needed

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
