FERRARI 308QV 328 Service Repair Shop Manual
FERRARI 308QV 328 Service Repair Shop Manual
Normale prijs
$16.99
Normale prijs
Aanbiedingsprijs
$16.99
Verzendkosten worden berekend bij de checkout.
Vehicle data plateRef 316660
- Brand
- Ferrari
- Vehicle
- Cars
- Models covered
- 308QV, 328
- Format
- PDF, searchable, print-ready
- Delivery
- Instant download after checkout
- Language
- English
Kan beschikbaarheid voor afhalen niet laden
What happens after you pay
- Download link opens on the order page immediately
- The same link is emailed to you β re-download any time
- Open on phone, tablet or PC; print only the pages you need
- Not sure it covers your model year? Ask us before you buy
π·οΈ Basic Information
Identification
Make:
Ferrari
Model:
308 QV / 328
Model Variant:
GTSi / GTB / GTS (308QV), GTB / GTS (328)
Codes
Chassis Code 308:
308 GTB/GTS (Tipo F106 AB), 308 GTB/GTS i.e. (Tipo F106 BB)
Chassis Code 328:
328 GTB/GTS (Tipo F106 CB)
π Introduction
Market Position
Segment:
Mid-engine, Rear-wheel-drive Sports Car
Target Audience:
Enthusiasts, Owners, Independent Workshops specializing in Italian exotics
Competitive Analysis
Contemporaries:
Porsche 911, Chevrolet Corvette (C3/C4), Lotus Esprit, De Tomaso Pantera
Key Features
Design:
Iconic Pininfarina styling, Sculptural bodywork
Performance:
Mid-mounted V8 engine, Balanced chassis, Exhilarating driving experience
π Manual Details
Coverage Areas
Applicable Years:
1977-1985 (308 QV), 1985-1989 (328)
Models Covered:
Ferrari 308 GTB, 308 GTS, 308 GTBi, 308 GTSi, 328 GTB, 328 GTS
Page Count
Estimated Page Count:
1000+
Manual Type
Type:
Service Repair Shop Manual
Language
Language:
English
Format
File Format:
PDF
π Manual Coverage
Systems Covered
Engine:
V8 Naturally Aspirated (Carbureted and Fuel Injection)
Fuel System:
Carburetor (Weber 40 DCNF, 40 DCNVA), Bosch K-Jetronic Fuel Injection
Ignition System:
Electronic Ignition (Marelli, Bosch)
Cooling System:
Radiator, Fan, Hoses, Thermostat
Transmission:
Manual Transaxle (5-Speed)
Clutch:
Hydraulic Clutch System
Differential:
Limited Slip Differential (LSD)
Brakes:
Ventilated Disc Brakes (Front and Rear), Hydraulic System, Parking Brake
Suspension:
Independent Front and Rear Suspension, Springs, Shock Absorbers, Bushings
Steering:
Rack and Pinion, Power Steering System
Electrical System:
Battery, Alternator, Starter, Wiring Diagrams, Fuses, Relays, Lighting
Body And Chassis:
Chassis Structure, Body Panels, Doors, Hood, Trunk, Bumpers, Glass
Interior:
Dashboard, Seats, Upholstery, Trim, HVAC System
Wheels And Tires:
Wheel specifications, Tire sizes, Alignment
Procedures Included
Maintenance:
Oil changes, Filter replacements, Tune-ups, Belt inspections/replacements
Troubleshooting:
Diagnostic procedures for engine, electrical, and mechanical issues
Repair:
Engine rebuild, Transmission overhaul, Brake system repair, Suspension component replacement
Overhaul:
Complete engine and transmission overhaul procedures
Diagnostics:
Detailed diagnostic charts and procedures for common faults
Adjustment:
Carburetor synchronization, Ignition timing adjustment, Valve clearance adjustment
Technical Depth
Depth:
Comprehensive from basic maintenance to complete engine rebuild and electrical system diagnostics
Detail Level:
Detailed step-by-step instructions with diagrams and specifications
π Manual Specifications
File Format
Compatibility:
All Versions of Windows, Mac, and Linux
Reader Requirement:
Adobe PDF Reader
Print Quality
Printable:
Yes
Download
Delivery:
Instant High Speed Download
βοΈ Engine Specifications
Primary Engine
Engine Type:
Ferrari Tipo F106 V8
Displacement 308:
2.9 L (2926 cc)
Displacement 328:
3.2 L (3185 cc)
Performance
Horsepower 308 Carb:
237 hp @ 6500 rpm (approx.)
Horsepower 308 F Inj:
214 hp @ 6300 rpm (approx.)
Horsepower 328:
270 hp @ 6300 rpm (approx.)
Torque 308 Carb:
265 Nm @ 4500 rpm (approx.)
Torque 328:
314 Nm @ 4750 rpm (approx.)
Fuel System
Carburetor Model:
Weber 40 DCNF (308QV), Weber 40 DCNVA (308 QV)
Injection System:
Bosch K-Jetronic CIS (308 QV i.e., 328)
Engine Internals
Bore X Stroke 308:
81 mm x 71 mm
Bore X Stroke 328:
83 mm x 73.6 mm
Compression Ratio 308:
9.2:1 (approx.)
Compression Ratio 328:
9.8:1 (approx.)
Valvetrain:
Dual Overhead Camshafts (DOHC), 2 valves per cylinder
π§ Transmission
Standard
Type:
5-Speed Manual Transaxle
Features
Drive Layout:
Mid-engine, Rear-wheel drive
Transmission Fluid:
API GL-4 SAE 75W-90 Synthetic Gear Oil (e.g., Red Line MTL)
π Dimensions
Exterior
Length 308:
4230 mm (166.5 in)
Length 328:
4235 mm (166.7 in)
Width:
1720 mm (67.7 in)
Height:
1130 mm (44.5 in)
Wheelbase:
2340 mm (92.1 in)
Weights
Curb Weight 308:
1430 kg (3153 lbs) (approx.)
Curb Weight 328:
1470 kg (3241 lbs) (approx.)
Wheels And Tires
Wheel Bolt Pattern:
5x108
Front Tire Size:
205/55 VR16
Rear Tire Size:
225/50 VR16
π‘οΈ Safety Features
Ratings
Crash Test Data:
Not extensively tested by modern standards; designed for a different era of safety
Active Features
Brakes:
Four-wheel disc brakes, typically vented front and rear.
Passive Features
Seatbelts:
Three-point retractable seatbelts
Body Structure:
Steel monocoque chassis with composite body panels.
π‘ Technology Features
Infotainment
Audio System:
Period-correct AM/FM Radio with cassette player (factory option)
Driver Assistance
ABS:
Not available on early 308 models; ABS introduced on later 308 QV and standard on 328.
Connectivity
Connectivity Features:
N/A (era-appropriate technology)
π§ Maintenance
Service Intervals
Oil Change Interval:
Every 3,000 miles or 12 months, whichever comes first
Major Service Interval:
Every 12,000 miles or 24 months (includes timing belt replacement)
Fluid Specifications
Engine Oil Type:
10W-40 or 20W-50 API SG/SH (consult manual for exact spec depending on climate)
Engine Oil Capacity:
Approx. 10.5 Liters (with filter)
Coolant Type:
Ethylene Glycol based antifreeze (50/50 mix with distilled water)
Brake Fluid Type:
DOT 4
Known Issues
Common Problems 308:
Carburetor tuning, Fuel line degradation, Ignition coil failure, Clutch wear, Oil leaks (especially around cam covers)
Common Problems 328:
Timing belt tensioner issues (pre-tensioner design), Fuel injector seals, Electrical gremlins, A/C system recharge/leaks
Part Numbers
Timing Belt 308:
OEM Ferrari Part Number example: 106404 (varies by specific model)
Timing Belt 328:
OEM Ferrari Part Number example: 130704 (varies by specific model)
Oil Filter:
Mann-Filter W 940/1, Mahle OC 194, Champion COF040, Fram PH8172
π Vehicle History
Brand Heritage
Founder:
Enzo Ferrari
Legacy:
Renowned for racing heritage and road-going supercars
Model Evolution
308 Introduction:
Introduced in 1975 as a successor to the Dino 246 GT/GTS.
308 Variants:
Available in GTB (Berlinetta) and GTS (Spider) configurations. Carbureted models (pre-1980) and fuel-injected (i.e.) models followed.
328 Introduction:
Introduced in 1985 as an evolution of the 308, featuring a larger displacement engine and updated styling.
Production
Production Years 308:
1975-1985
Production Years 328:
1985-1989
Manufacturing Location:
Maranello, Italy
π Awards & Recognition
Recognitions
Design Awards:
Consistently praised for its Pininfarina design, considered a benchmark of 1980s automotive styling.
Ratings
Performance Reviews:
Praised by automotive press for its handling, responsiveness, and V8 engine soundtrack.
Delivery & file format
Delivery & file format
