Mitsubushi

2003-2008 Mitsubushi GrandIS Service Repair Manual

2003-2008 Mitsubushi GrandIS Service Repair Manual

$16.99
$16.99
セール 売り切れ
配送料はチェックアウト時に計算されます。
Vehicle data plateRef 586012
Brand
Mitsubushi
Vehicle
Cars
Models covered
GrandIS, Mitsubishi
Years
2003, 2004, 2005, 2006, 2007, 2008
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Grandis
Year:
2003-2008
Codes
Platform:
Mitsubishi GS platform
👋 Introduction
Market Position
Market Segment:
Mid-size MPV (Multi-Purpose Vehicle) / Minivan
Competitive Analysis
Competitors:
Ford Galaxy, Volkswagen Sharan, SEAT Alhambra, Chrysler Voyager, Renault Espace, Kia Carnival, Hyundai Trajet
Key Features
Unique Selling Points:
Distinctive 'face-forward' design, versatile seating configurations, powerful V6 engine option, good handling for its class.
Purpose
Manual Utility:
Essential resource for DIY mechanics, independent repair shops, and owners seeking to perform maintenance or understand their vehicle's systems.
📋 Manual Details
Coverage Areas
Regions Covered:
Global (specific regional variations may exist not detailed in this single manual)
Trim Levels Covered:
Covers all available trim levels for the 2003-2008 Mitsubishi Grandis (e.g., GLX, GLS, GTV, Sport).
Page Count
Page Count:
Estimated 1500-2000+ pages (typical for comprehensive service manuals of this era)
Manual Type
Manual Type:
Factory Service Manual (FSM) / Workshop Manual
Content Type:
Diagnostic, Repair, Overhaul, Maintenance, Wiring Diagrams, Specifications, Illustrations.
Language
Language:
English
Format
Format:
Digital (PDF) - Searchable and Printable
📖 Manual Coverage
Systems Covered
Engine Systems:
Engine mechanicals, lubrication, cooling, fuel injection, ignition, emissions control, engine diagnostics
Transmission Systems:
Automatic transmission (INVECS-II), manual transmission (if applicable), clutch, driveline, differentials
Suspension Steering:
Front suspension (MacPherson strut), rear suspension (Multi-link beam axle), steering system (power steering), wheel alignment
Brakes:
Front and rear disc brakes, Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), parking brake
Electrical Electronics:
Battery, charging system, starting system, lighting, wipers, horn, power windows, power locks, instrument cluster, audio system, comfort controls, basic body electronics
Body Chassis:
Body construction, exterior panels, doors, hood, tailgate, interior trim, chassis components, corrosion protection
HVAC:
Heating, ventilation, air conditioning (HVAC) system operation and service
Procedures Included
Maintenance:
Scheduled maintenance, oil changes, filter replacements, spark plug replacement, brake fluid changes, coolant flushes, belt inspections/replacements
Diagnostics:
Troubleshooting guides for common symptoms, diagnostic trouble codes (DTCs), on-board diagnostics (OBD-II)
Repair:
Step-by-step repair procedures for all major systems, component removal and installation, torquing specifications, assembly instructions
Specifications:
Detailed technical specifications, measurements, clearances, fluid capacities, electrical schematics
Wiring Diagrams:
Extensive electrical wiring diagrams for all major systems included.
Diagnostic Tools:
Information on using diagnostic tools, interpreting sensor data, and understanding error codes.
Technical Depth
Depth:
Comprehensive: Covers basic maintenance to complex engine and transmission rebuilds, including electrical troubleshooting and body repair.
Troubleshooting Methodology:
Systematic approach to diagnosing faults, including symptom-based troubleshooting trees and diagnostic procedures.
📊 Manual Specifications
File Format
File Format:
PDF (Portable Document Format)
Print Quality
Print Quality:
High-resolution scans/reproductions suitable for clear printing and viewing on screen.
Binding Type
Binding Type:
N/A (Digital Format)
Paper Type
Paper Type:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine Code Petrol V6:
6G72 (3.0L SOHC V6)
Engine Displacement V6:
2972 cc (3.0 Liters)
Engine Layout V6:
V6 SOHC (Single Overhead Camshaft)
Bore X Stroke V6:
86.1 mm x 86.0 mm
Compression Ratio V6:
9.5:1
Horsepower V6:
163 PS (161 hp; 120 kW) at 5,500 rpm (European spec)
Torque V6:
270 Nm (199 lb-ft) at 3,750 rpm (European spec)
Performance
Acceleration 0 100Kmh V6:
Approx. 11.2 seconds
Top Speed V6:
Approx. 191 km/h (119 mph)
Fuel System
Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Fuel Type:
Unleaded Petrol (Octane rating as per local market standards, typically 95 RON recommended)
Cooling System
Coolant Type:
Ethylene Glycol based coolant (e.g., Mitsubishi DiaQueen Super Long Life Coolant)
Lubrication System
Engine Oil Type:
API SG/SH/SJ or higher, SAE 10W-30 or 10W-40 recommended. Consult manual for specific viscosity based on climate.
Engine Management
ECU Type:
Proprietary Mitsubishi ECU (e.g., DIAGNOSTIC SYSTEM)
🔧 Transmission
Standard
Transmission Type:
4-speed INVECS-II Automatic Transmission
Optional
Optional Transmission:
5-speed Manual Transmission (less common)
Features
Invccs Ii Description:
Intelligent & Innovative Vehicle Electronic Control System - adaptive shift logic that learns driver behavior.
Fluid Specifications
Automatic Transmission Fluid Type:
Mitsubishi DIA QUEEN ATF-SPII or equivalent Dexron III/Mercon compatible fluid.
Gear Ratios
Automatic Gear Ratios:
Refer to manual for specific ratios; typical for period MPVs.
📐 Dimensions
Exterior
Length:
Approx. 4,575 mm (179.9 in)
Width:
Approx. 1,775 mm (69.9 in)
Height:
Approx. 1,735 mm (68.3 in)
Wheelbase:
Approx. 2,830 mm (111.4 in)
Ground Clearance:
Approx. 160 mm (6.3 in)
Weights
Curb Weight:
Approx. 1,700 - 1,800 kg (3,748 - 3,968 lbs) depending on specification
Gross Vehicle Weight Rating:
Consult specific vehicle VIN plate or manual.
Interior
Seating Capacity:
6 or 7 seats (3 rows)
Cargo
Cargo Volume Rear Seats Folded:
Substantial, designed for family use. Specific volume figures vary by configuration.
🛡️ Safety Features
Ratings
Euro Ncap Rating:
Early models achieved 4-star rating; later models may vary. Consult specific year's Euro NCAP results.
Active Features
ABS:
Standard Anti-lock Braking System
Ebd:
Standard Electronic Brake-force Distribution
Traction Control:
Optional on some higher trims
Passive Features
Airbags:
Driver and front passenger airbags standard. Side airbags and curtain airbags available on higher trims.
Seatbelts:
3-point seatbelts with pretensioners for front seats, 3-point seatbelts for rear seats.
Child Seat Anchors:
ISOFIX/LATCH mounting points for child seats.
💡 Technology Features
Infotainment
Audio System:
Factory fitted AM/FM/CD player with speaker system. Higher trims may have premium audio or CD-changer options.
Navigation:
Optional GPS navigation system available on select higher trims.
Driver Assistance
Parking Sensors:
Optional rear parking sensors available on some models.
Connectivity
Auxiliary Input:
Not standard; later models or aftermarket units may offer AUX input.
Comfort Features
Cruise Control:
Standard or optional depending on trim level.
Power Features:
Power windows, power mirrors, power door locks are standard or optional depending on trim.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 7,500 miles (12,000 km) or 6 months, whichever comes first. Consult manual for specific conditions.
Air Filter Replacement Interval:
Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on driving conditions.
Spark Plug Replacement Interval:
Typically 60,000 miles (96,000 km) for standard plugs, potentially 100,000 miles for iridium/platinum plugs (if equipped).
Transmission Fluid Change Interval:
Every 30,000 - 50,000 miles (48,000 - 80,000 km) or as per severe service schedule.
Coolant Replacement Interval:
Initial replacement at 60,000 miles (96,000 km), then every 30,000 miles (48,000 km) or 2 years.
Fluid Specifications
Engine Oil Capacity V6:
Approx. 4.5 Liters (4.8 US Quarts) with filter change.
Transmission Fluid Capacity Automatic:
Approx. 7.5 Liters (7.9 US Quarts) for complete refill; approx. 3.5 Liters (3.7 US Quarts) for drain and fill.
Coolant Capacity:
Approx. 8.0 Liters (8.5 US Quarts).
Brake Fluid Type:
DOT 3 or DOT 4.
Known Issues
Common Wear Items:
Suspension components (bushings, ball joints), exhaust system, potentially ignition coils and spark plugs due to age.
Transmission Behavior:
INVECS-II can sometimes exhibit delayed shifting or 'hunting' for gears if TCM is not properly calibrated or if solenoid issues arise.
Engine Performance Quirks:
Minor oil leaks from valve cover gaskets or oil pan gasket are common with age and mileage.
Refrigerant
HVAC Refrigerant Type:
R134a
📚 Vehicle History
Brand Heritage
Parent Company:
Mitsubishi Motors Corporation (MMC)
Model Evolution
Generation:
First Generation (2003-2008/2009 depending on market)
Design Concept:
Designed to offer a spacious and flexible interior in a relatively compact exterior footprint, with a focus on family usability.
Production
Manufacturing Plant:
Mizushima Plant, Kurashiki, Okayama, Japan
Production Years:
2003 - 2008/2009
🏆 Awards & Recognition
Recognitions
Awards:
While specific major automotive 'awards' are not widely publicized for the Grandis, it was recognized for its practical family-oriented features in various regional automotive publications.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
