1998 Mitsubishi FTO Workshop Service Repair Manual

1998 Mitsubishi FTO Workshop Service Repair Manual

$16.99
$16.99
セール 売り切れ
配送料はチェックアウト時に計算されます。
Vehicle data plateRef 392037
Brand
Mitsubishi
Vehicle
Cars
Models covered
FTO
Years
1998
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
FTO
Year:
1998
Codes
Chassis Code:
DE Series (e.g., DE2A, DE3A)
Engine Codes:
6A12 (V6 MIVEC), 6A13 (V6 MIVEC Turbo)
👋 Introduction
Market Position
Segment:
Compact Sports Coupe
Target Audience:
Enthusiasts, DIY mechanics, professional repair shops.
Competitive Analysis
Competitors:
Toyota Celica, Nissan 180SX/Silvia, Honda Prelude, Mazda MX-6.
Key Features
Design:
Distinctive 'cat's eye' headlights, sleek aerodynamic profile, available in 2-door coupe.
Powertrain:
Front-wheel drive (FWD) or optional Active Yaw Control (AYC) on higher trims, V6 MIVEC engines.
Manual Value:
Factory-sourced, detailed, and comprehensive for effective DIY maintenance and repair, saving significant costs.
📋 Manual Details
Coverage Areas
Regions:
Primarily Japanese Domestic Market (JDM) specifications, with general applicability to export markets where the FTO was sold.
Page Count
Estimated Pages:
1000+
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF (Digital Download)
📖 Manual Coverage
Systems Covered
Engine:
Engine mechanical, lubrication, cooling, fuel injection, ignition, emissions control, turbocharger systems.
Transmission:
Manual and INVECS-II Sport Mode Automatic transmission systems, clutch, driveline, differentials.
Brakes:
Hydraulic brake system, parking brake, ABS (Anti-lock Braking System).
Steering:
Power steering system, steering column, wheel alignment.
Suspension:
Front and rear suspension components, shock absorbers, springs, bushings.
Electrical:
Charging system, starting system, lighting, instrumentation, power windows, mirrors, audio systems, engine control modules (ECU), body control modules (BCM).
Body:
Exterior body panels, interior trim, seats, glass, doors, locks, hinges, bumpers.
HVAC:
Heating, ventilation, and air conditioning (HVAC) system diagnosis and repair.
Safety:
SRS (Supplemental Restraint System) airbags and associated components.
Procedures Included
Maintenance:
Routine maintenance checks, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacements, spark plug service, belt adjustments.
Repair:
Engine rebuild procedures, transmission overhaul, brake caliper replacement, suspension component replacement, electrical component diagnosis and repair, body panel repair.
Diagnostics:
Troubleshooting guides for common issues, diagnostic trouble codes (DTCs) for engine and other systems, testing procedures for electrical components.
Disassembly Assembly:
Complete step-by-step instructions for major component disassembly and reassembly.
Special Tools:
Identification and usage of specialized tools required for specific repair procedures.
Technical Depth
Depth:
Comprehensive: Covers everything from basic fluid changes to complete engine and transmission rebuilds, including detailed diagnostic procedures.
📊 Manual Specifications
File Format
File Type:
PDF
Searchable:
Likely text-searchable (depending on PDF creation process)
Print Quality
Printability:
All pages printable
Binding Type
Binding:
Not Applicable (Digital)
Paper Type
Paper:
Not Applicable (Digital)
⚙️ Engine Specifications
Primary Engine
Engine Code 1:
6A12
Engine Type 1:
V6 SOHC MIVEC (Mitsubishi Innovative Valve timing Electronic Control)
Displacement 1:
2.0 Liters (1998 cc)
Bore X Stroke 1:
79.0 mm x 68.2 mm
Compression Ratio 1:
10.0:1
Horsepower 1:
Approx. 168-170 hp @ 6000 rpm (JDM spec)
Torque 1:
Approx. 144-145 lb-ft (195 Nm) @ 4000 rpm (JDM spec)
Optional Engine
Engine Code 2:
6A13TT (Twin Turbo)
Engine Type 2:
V6 DOHC MIVEC Twin Turbocharged
Displacement 2:
2.5 Liters (2498 cc)
Compression Ratio 2:
8.5:1
Horsepower 2:
Approx. 247 hp @ 6000 rpm (JDM spec)
Torque 2:
Approx. 245 lb-ft (332 Nm) @ 3000 rpm (JDM spec)
Fuel System
Fuel Injection:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline
Ignition System:
Electronic ignition with distributor (coil-on-plug on some later models or variations)
🔧 Transmission
Standard
Transmission Type 1:
5-speed Manual (5MT)
Optional
Transmission Type 2:
4-speed INVECS-II Sport Mode Automatic (F4A4x series)
Features
Invcs Ii Sport Mode:
Adaptive transmission control with manual shifting override.
Driveline
Layout:
Front-Wheel Drive (FWD)
Ayc:
Available on higher trims (e.g., GSR, Aero) for improved handling and traction.
📐 Dimensions
Exterior
Length:
Approx. 4,295 mm (169.1 in)
Width:
Approx. 1,700 mm (66.9 in)
Height:
Approx. 1,300 mm (51.2 in)
Wheelbase:
Approx. 2,500 mm (98.4 in)
Weights
Curb Weight:
Approx. 1,250 - 1,400 kg (2,755 - 3,086 lbs) depending on engine and trim
🛡️ Safety Features
Ratings
Crash Test Data:
Limited official crash test data available for JDM models; generally considered robust for its era but lacks modern safety suite.
Active Features
ABS:
Available as an option or standard on higher trims.
Ayc:
Active Yaw Control for enhanced cornering stability.
Passive Features
Airbags:
Driver's airbag standard; passenger airbag often optional or unavailable.
Seatbelts:
Three-point inertia-reel seatbelts with pre-tensioners.
💡 Technology Features
Infotainment
Audio System:
Factory fitted radio cassette player with optional CD player and amplifier.
Climate Control:
Manual climate control system.
Driver Assistance
Cruise Control:
Optional on some models.
Connectivity
Data Ports:
OBD-I or OBD-II connector (depending on specific market and manufacturing date) for diagnostic scanning.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 7,500-10,000 km (4,500-6,000 miles) or 6-12 months, whichever comes first.
Oil Filter Replacement:
With every oil change.
Air Filter Replacement:
Every 15,000-20,000 km (9,000-12,000 miles) or annually.
Spark Plug Replacement:
Approx. 100,000 km (60,000 miles) for iridium/platinum plugs, check manual for specific types.
Coolant Replacement:
Every 2 years or 40,000 km (24,000 miles).
Fluid Specifications
Engine Oil Spec:
API SG/SH or higher, viscosity typically 5W-30, 10W-30, or 10W-40 depending on climate. Refer to manual for precise spec.
Coolant Type:
Ethylene glycol based coolant (ensure proper color and type for Mitsubishi).
Brake Fluid Spec:
DOT 3 or DOT 4 brake fluid.
Transmission Fluid Manual:
API GL-4 or GL-5 gear oil (viscosity typically 75W-90).
Transmission Fluid Automatic:
Mitsubishi DIA Queen ATF-SP II M or equivalent.
Power Steering Fluid:
Dexron II/III or equivalent ATF.
Known Issues
Engine Mounts:
Wear and tear leading to vibration, especially on higher mileage vehicles.
Timing Belt:
Critical component; replacement recommended per schedule (typically 90,000-100,000 km or 6-7 years). Failure can cause catastrophic engine damage.
Mivec Actuator:
Can become noisy or fail, affecting engine performance; requires specialized diagnosis and repair.
Oxygen Sensor:
Can degrade over time, affecting fuel economy and emissions.
Suspension Bushings:
Degradation leading to clunking noises and poor handling.
Automatic Transmission:
INVECS-II can be sensitive to fluid changes and maintenance; potential for shifting issues if neglected.
📚 Vehicle History
Brand Heritage
Manufacturer:
Mitsubishi Motors Corporation
Model Evolution
Generation 1:
First Generation (1992-2001), with a facelift in 1997.
Design Concept:
Designed as a stylish and affordable front-wheel-drive sports coupe to compete in a popular segment.
Key Milestones:
Introduction of MIVEC technology, availability of AYC system, significant facelift in 1997 improving aesthetics and features.
Production
Production Years:
1992-2001
Manufacturing Location:
Japan
🏆 Awards & Recognition
Recognitions
Automotive Journalism:
Often praised by automotive press of its era for styling, handling (especially with AYC), and value proposition within the sports coupe segment.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
