Victory Vision 2012-2017 Motorcycle Service Repair Manual

Victory Vision 2012-2017 Motorcycle Service Repair Manual

$17.99
$17.99
Promotion Épuisé
Frais d'expédition calculés à l'étape de paiement.
Vehicle data plateRef 474914
Brand
Victory
Vehicle
Motorcycle
Models covered
Motorcycles, Vision
Years
2012, 2013, 2014, 2015, 2016, 2017
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Victory
Model:
Vision Tour
Product Name:
Victory Vision 2012-2017 Motorcycle Service Repair Manual
Applicable Model Years:
2012, 2013, 2014, 2015, 2016, 2017
👋 Introduction
Market Position
Segment:
Luxury Touring Motorcycle
Key Selling Points:
Comfort, integrated storage, powerful V-twin engine, advanced features for long-distance riding.
Competitive Analysis
Competitors:
Harley-Davidson Electra Glide, Indian Roadmaster, Honda Gold Wing, BMW K 1600 GTL.
Key Features Vehicle
Engine Type:
Freedom 106/6 V-Twin (air-cooled, 50-degree V-twin)
Fueling:
Electronic Fuel Injection (EFI)
Transmission:
6-speed constant mesh
Key Features Manual
Value Proposition:
Empowers owners to perform essential maintenance and repairs, saving time and money.
Target Audience:
Victory Vision Tour owners seeking to maintain their motorcycle's performance and longevity.
📋 Manual Details
Coverage Areas
General Information:
True
Maintenance:
True
Frame Body Exhaust:
True
Lubrication Cooling:
True
Fuel System Fuel Injection:
True
Engine Removal Installation:
True
Cylinder Head Valves:
True
Cylinder Piston:
True
Clutch Primary Shift:
True
Transmission Crankshaft:
True
Drive Line:
True
Front Wheel Suspension:
True
Rear Wheel Suspension:
True
Tires:
True
Brakes:
True
Charging System:
True
Ignition System Battery:
True
Electric Starter:
True
Lighting Instrumentation:
True
Page Count
Estimated Page Count:
Refer to actual manual for precise count (typically 500+ pages for full coverage)
Manual Type
Type:
Service Repair Manual
Language
Language:
English
Format
Format:
Digital (PDF)
📖 Manual Coverage
Systems Covered
Engine Systems:
Comprehensive coverage including engine removal/installation, cylinder head/valves, cylinder/piston, lubrication, cooling, and fuel injection.
Drivetrain Systems:
Detailed information on clutch, primary drive, transmission, crankshaft, and final drive (belt drive system).
Suspension And Wheels:
In-depth coverage of front and rear suspension components (forks, shocks), wheel bearings, and tire servicing.
Braking Systems:
Complete breakdown of brake system components, hydraulic lines, calipers, rotors, and bleeding procedures.
Electrical Systems:
Extensive coverage of charging system (alternator, regulator/rectifier), ignition system, battery, starter motor, lighting, and instrumentation.
Frame And Bodywork:
Information on frame, body panels, fairings, exhaust system maintenance, and associated hardware.
Procedures Included
Maintenance Procedures:
Routine maintenance checks, fluid changes (oil, brake fluid, coolant), filter replacements, and general upkeep.
Diagnostic Procedures:
Troubleshooting guides, fault code interpretation (if applicable to the era), and systematic diagnostic steps for various systems.
Repair Procedures:
Detailed, step-by-step instructions for component removal, overhaul, repair, and reassembly of all major motorcycle systems.
Assembly Disassembly:
Exploded diagrams and detailed instructions for the proper disassembly and reassembly of complex assemblies like the engine and transmission.
Technical Depth
Depth:
Professional quality, suitable for advanced DIY mechanics and professional technicians.
Diagrams Illustrations:
Includes detailed exploded diagrams and schematics to aid in component identification and assembly.
Torque Specifications:
Provides critical torque values for fasteners throughout the motorcycle.
Electrical Schematics:
Likely includes wiring diagrams for troubleshooting and repair of electrical systems.
📊 Manual Specifications
File Format
Format:
PDF
Searchability:
Typically searchable PDF, allowing quick keyword searches.
Printability:
Designed for printing individual sections or the entire manual.
Print Quality
Quality:
Professional digital reproduction, mimicking original factory manual clarity.
Binding Type
Binding:
Not applicable (digital format)
Paper Type
Paper:
Not applicable (digital format)
Navigation
Navigation Method:
Bookmarked for easy access to specific sections.
⚙️ Engine Specifications
Primary Engine
Engine Family:
Victory Freedom V-Twin
Displacement:
1731 cc (106 cubic inches)
Bore X Stroke:
101 mm x 108 mm (typical for Freedom 106)
Compression Ratio:
9.4:1 (typical for Freedom 106)
Performance
Horsepower:
Approx. 95-100 HP @ 5000 RPM (estimated for Freedom 106)
Torque:
Approx. 106-110 lb-ft @ 3200 RPM (estimated for Freedom 106)
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI) with single throttle body
Fuel Type:
Unleaded gasoline, minimum 91 octane recommended
Cooling System
Cooling Method:
Air-cooled with oil cooler
🔧 Transmission
Standard
Type:
6-speed constant mesh
Clutch:
Wet, multi-plate
Primary Drive:
Gear drive
Final Drive:
Belt drive
Features
Overdrive Gears:
Includes overdrive gears for relaxed highway cruising.
📐 Dimensions
Exterior
Wheelbase:
Approx. 66.7 inches (1694 mm)
Seat Height:
Approx. 26.5 inches (673 mm)
Weights
Dry Weight:
Approx. 700 lbs (317.5 kg) (estimated)
Gross Vehicle Weight Rating:
Specify from VIN plate/manual
Cargo
Storage Capacity:
Integrated hard saddlebags and trunk with significant storage volume.
🛡️ Safety Features
Ratings
Safety Certification:
Meets applicable DOT and EPA standards.
Active Features
Braking System:
Linked braking system (front and rear brakes partially integrated).
Passive Features
Lighting:
Full complement of DOT-approved headlights, taillights, and turn signals.
Frame Construction:
Robust frame design for stability and handling.
💡 Technology Features
Infotainment
Audio System:
Integrated premium audio system (speakers, amplifier) with connectivity options.
Cruise Control:
Standard electronic cruise control for highway comfort.
Instrumentation:
Digital and analog display with comprehensive information.
Driver Assistance
ABS:
Available Anti-lock Braking System (ABS) on some models/trims.
Connectivity
Auxiliary Input:
Likely includes an auxiliary audio input or USB port for media devices.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Refer to manual, typically every 5,000 miles or 6 months.
Transmission Oil Change:
Refer to manual, typically every 10,000 miles or 12 months.
Belt Drive Inspection:
Refer to manual, often at 5,000-10,000 mile intervals for tension and condition.
Spark Plug Replacement:
Refer to manual, typically around 15,000-20,000 miles.
Fluid Specifications
Engine Oil Viscosity:
Refer to manual, commonly SAE 20W-40 or 10W-40 motorcycle specific oil.
Transmission Fluid Type:
Refer to manual, often a dedicated transmission lubricant.
Brake Fluid Type:
DOT 4 recommended.
Coolant Type:
Ethylene glycol-based antifreeze suitable for motorcycles (check manual for specific type/mix ratio).
Known Issues
Potential Wear Items:
Belt drive components (belt, pulleys), clutch plates, suspension bushings, brake pads.
Electrical Connections:
Corrosion or loose connections can affect lighting or sensor performance, especially in adverse weather. Manual helps identify locations.
Fuel System Cleaning:
Periodic cleaning of fuel injectors may be beneficial for optimal performance, detailed in the manual.
📚 Vehicle History
Brand Heritage
Manufacturer:
Victory Motorcycles was a division of Polaris Industries.
Model Evolution
Introduction Year:
The Victory Vision was introduced for the 2008 model year.
Key Updates Within Range:
Updates across 2012-2017 typically included minor aesthetic changes, ECU re-maps for performance, and potentially component refinements. The core design remained consistent.
Production
Production Status:
Victory Motorcycles ceased production in 2017.
🏆 Awards & Recognition
Recognitions
Industry Reviews:
Generally well-received for its touring capabilities, comfort, and distinctive styling.
