Mitsubishi Eclipse Spyder 1996-1997 Service Repair Manual

Mitsubishi Eclipse Spyder 1996-1997 Service Repair Manual

$16.99
$16.99
Promotion Épuisé
Frais d'expédition calculés à l'étape de paiement.
Vehicle data plateRef 344551
Brand
Mitsubishi
Vehicle
Cars
Models covered
Eclipse, Eclipse Spyder
Years
1996, 1997
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
Eclipse Spyder
Generation:
Second Generation (D30/D32)
Codes
Platform Code:
D30 (FWD), D32 (AWD)
👋 Introduction
Market Position
Segment:
Compact Sports Convertible
Competitive Analysis
Key Competitors:
Mazda Miata (MX-5), Toyota MR2, Nissan 240SX Convertible, Ford Mustang Convertible (lower trims)
Key Features
Vehicle Highlight:
Stylish convertible design with available turbocharged performance, offering a blend of performance and open-air driving experience.
📋 Manual Details
Coverage Areas
Model Years Covered:
1996-1997
Chassis Types Covered:
Convertible (Spyder)
Drivetrain Variants Covered:
Front-Wheel Drive (FWD), All-Wheel Drive (AWD)
Page Count
Estimated Pages:
Over 1500 (typical for comprehensive service manuals of this era)
Manual Type
Type:
Factory Service Manual / Workshop Manual
Language
Language:
English
Format
File Format:
PDF
Delivery Method:
Digital Download (.rar/.zip)
📖 Manual Coverage
Systems Covered
Powertrain Engine:
All engine mechanical, lubrication, cooling, control, fuel, and exhaust systems
Powertrain Transmission:
Clutch, manual transmission, automatic transmission, propeller shaft, rear final drive
Suspension Steering:
Front axle, rear axle, front suspension, rear suspension, brake system, parking brake system, brake control system, steering control system
Body Interior:
Body, locks, security, glasses, windows, mirrors, exterior trim, interior trim, instrument panel, seats
Electrical Lighting:
Starting/charging, lighting, driver information, wiper/washer/horn, body control, LAN system, audio/visual/navigation/telephone, auto cruise control, power supply/ground/circuit elements
Safety Restraint:
Seat belts, Supplemental Restraint System (SRS)
Procedures Included
Diagnostic Procedures:
Detailed diagnostic procedures, troubleshooting charts, fault code interpretation
Repair Procedures:
Step-by-step repair instructions for all major components and systems
Maintenance Procedures:
Scheduled maintenance, fluid changes, filter replacements, inspections
Adjustment Procedures:
Component adjustments, alignments, calibration
Technical Depth
Depth:
Comprehensive: Covers from basic maintenance to advanced diagnostics and complete overhauls, mirroring dealership technician use
📊 Manual Specifications
File Format
Print Quality:
High-resolution scans suitable for printing
Searchability:
Likely text-searchable if OCR'd during PDF creation
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Type:
N/A (Digital Download)
⚙️ Engine Specifications
Primary Engine
Engine Code 1:
4G63 (2.0L DOHC Turbocharged I4)
Engine Code 2:
6G72 (3.0L SOHC V6)
Performance
Horsepower 4G63:
Approx. 210 hp (157 kW) at 6000 rpm (for GS/GSi trims)
Torque 4G63:
Approx. 214 lb-ft (290 Nm) at 3000 rpm (for GS/GSi trims)
Horsepower 6G72:
Approx. 164 hp (122 kW) at 5500 rpm (for LS/GS trims)
Torque 6G72:
Approx. 185 lb-ft (251 Nm) at 4000 rpm (for LS/GS trims)
Fuel System
Fuel Injection Type:
Multi-Point Fuel Injection (MPI)
Fuel Type:
Unleaded Premium (91 octane recommended for turbo)
🔧 Transmission
Standard
Manual Transmission:
5-speed manual (likely F5M33 or similar, depending on engine/drivetrain)
Optional
Automatic Transmission:
4-speed automatic (likely F4A33 or similar, depending on engine/drivetrain)
Features
AWD System:
Viscous coupling center differential (for AWD models, often referred to as 'DOHC AWD' or 'GST AWD')
📐 Dimensions
Exterior
Wheelbase:
Approx. 100.4 inches (2550 mm)
Length:
Approx. 178.5 inches (4535 mm)
Width:
Approx. 69.7 inches (1770 mm)
Height:
Approx. 51.8 inches (1315 mm)
Weights
Curb Weight Est:
Approx. 3,000 - 3,300 lbs (1360 - 1497 kg) depending on engine and drivetrain
Wheel Bolt Pattern:
5x114.3 mm (5x4.5 inches)
Wheel Size Standard:
16 inch alloy wheels (common on GS/GSi)
🛡️ Safety Features
Ratings
NHTSA Ratings Est:
Refer to specific year; likely 4-star frontal for driver in 1996/97 models
Active Features
ABS:
Available (standard on some trims/models)
Passive Features
Airbags:
Driver and Passenger Airbags (standard)
Seat Belts:
3-point inertia-reel seat belts with pretensioners
💡 Technology Features
Infotainment
Audio System:
Factory AM/FM/Cassette or CD player, with optional premium audio systems.
Driver Assistance
Cruise Control:
Available 'Auto Cruise Control' system.
Connectivity
Lan System:
Internal vehicle network (LAN System) for various control modules.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,750 miles or 3 months (consult manual for specific engine/oil type)
Timing Belt Interval:
Approx. 60,000 miles or 4 years for 4G63 engine (CRITICAL service)
Fluid Specifications
Engine Oil Type 4G63:
API SG or SH, SAE 5W-30 or 10W-30 (refer to manual for climate suitability)
Engine Oil Type 6G72:
API SG or SH, SAE 5W-30 or 10W-30 (refer to manual for climate suitability)
Coolant Type:
Ethylene glycol based coolant, 50/50 mix with distilled water (e.g., Mitsubishi Super Long Life Coolant)
Transmission Fluid Manual:
API GL-4 or GL-5, SAE 75W-90 (check specific manual)
Transmission Fluid Automatic:
DIA Queen ATF SP-III or equivalent (check specific manual)
Known Issues
Turbo Lag 4G63:
Characteristic of the era's turbo engines; some units may experience worn turbocharger components.
Power Steering Pump:
Can be a point of failure over time, leading to noise or stiffness.
Suspension Components:
Bushings and ball joints can wear, affecting ride quality and handling.
Convertible Top Mechanism:
Hydraulic lines or seals for the power convertible top can leak or fail.
📚 Vehicle History
Brand Heritage
Brand Legacy:
Mitsubishi has a long history in performance vehicles, notably with the Lancer Evolution and earlier sports cars.
Model Evolution
Generation Context:
The second generation Eclipse (and its Spyder convertible variant) continued the sport-compact legacy established by the first generation, offering more refined styling and improved performance options.
Production
Manufacturing Location:
Normal, Illinois, USA (Diamond-Star Motors plant, a joint venture with Chrysler)
🏆 Awards & Recognition
Recognitions
Model Recognition Context:
While not as overtly lauded as some other models, the Eclipse line was popular in its segment and gained a following among enthusiasts for its styling and performance variants.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
