APRILIA ATLANTIC 125 200 BIKE Workshop Service Repair Manual

APRILIA ATLANTIC 125 200 BIKE Workshop Service Repair Manual

$16.99
$16.99
Alennusmyynti Loppuunmyyty
Toimituskulut lasketaan kassalla.
Vehicle data plateRef 494398
Brand
Aprilia
Vehicle
Motorcycle
Models covered
ATLANTIC 125, ATLANTIC 200, Misc, Motorcycles
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Aprilia
Model:
Atlantic 125/200
Model Designation:
Aprilia Atlantic 125/200
Generation
Production Years:
Circa 2003-2008 (specific years covered depend on manual edition)
Codes
Chassis Codes:
RP3, RP4 (Typical for this generation)
👋 Introduction
Market Position
Segment:
Mid-size scooter, popular in urban commuting and light touring
Target Audience:
Owner-operators, independent repair shops, technical enthusiasts
Competitive Analysis
Competitors:
Honda SH125/150, Yamaha X-MAX 125/250, Suzuki Burgman 125/200
Key Features
Design:
Sporty styling, comfortable riding position, practical storage
Performance:
Balanced performance suitable for city use and occasional highway travel
Manual Value Proposition:
Enables DIY maintenance and repair, reducing reliance on dealerships and saving costs.
📋 Manual Details
Coverage Areas
Continent:
Global (Primarily European market focus)
Region:
Europe, North America, Asia (depending on specific regional variants documented)
Page Count
Estimated Pages:
Approx. 300-500 pages (typical for comprehensive workshop manuals)
Manual Type
Type:
Workshop Service Repair Manual
Language
Primary Language:
English
Potential Additional Languages:
Italian, French, German, Spanish (often found in regional editions)
Format
Digital Format:
PDF
📖 Manual Coverage
Systems Covered
Powertrain:
Engine, Fuel System, Ignition System, Cooling System, Exhaust System
Chassis:
Frame, Suspension (Front & Rear), Steering, Braking System (Front & Rear)
Electrical:
Wiring Diagrams, Lighting System, Battery, Starting System, Charging System, Instrumentation
Bodywork:
Fairings, Seat, Fuel Tank, Body Panels, Bodywork Removal/Installation
Procedures Included
Maintenance:
Scheduled Maintenance, Oil Changes, Filter Replacements, Spark Plug Service, Brake Fluid Flush, Coolant Flush
Repair:
Engine Overhaul, Transmission Repair, Suspension Component Replacement, Brake System Repair, Electrical Component Diagnosis and Replacement
Troubleshooting:
Diagnostic Flowcharts, Common Fault Identification, Symptom-Based Troubleshooting
Disassembly Reassembly:
Step-by-step instructions with torque specifications for major components
Technical Depth
Depth:
Comprehensive - from routine maintenance to full engine and transmission rebuilds
Diagnostics:
Detailed diagnostic procedures, electrical schematics, component testing
Special Tools:
Lists and descriptions of required special tools
📊 Manual Specifications
File Format
Type:
PDF (Portable Document Format)
Searchability:
Searchable text content
Print Quality
Resolution:
High resolution for clear diagrams and text
Binding Type
Format Note:
Digital format (PDF), not a physical book. Compatible with Adobe Acrobat Reader.
Paper Type
Format Note:
N/A (Digital format)
Compatibility
Operating Systems:
All Windows OS, All Mac OS Versions
⚙️ Engine Specifications
Primary Engine
Type:
Four-stroke, liquid-cooled, SOHC
Displacement 125Cc:
124.9 cc (approx.)
Displacement 200Cc:
197.2 cc (approx.)
Bore X Stroke 125Cc:
52.4 mm x 57.9 mm (typical)
Bore X Stroke 200Cc:
62.5 mm x 65 mm (typical)
Performance
Horsepower 125Cc:
Approx. 14-15 HP @ 9,500 RPM
Horsepower 200Cc:
Approx. 19-20 HP @ 8,500 RPM
Torque 125Cc:
Approx. 11 Nm @ 8,000 RPM
Torque 200Cc:
Approx. 17 Nm @ 7,000 RPM
Fuel System
Type:
Carburetor (e.g., Dell'Orto PHBH/PHVA for 125) or Fuel Injection (for some 200cc variants, particularly later models)
Fuel Type:
Unleaded Gasoline (95 RON recommended)
Lubrication
Type:
Wet sump
Ignition
Type:
Electronic ignition (CDI or ECU controlled)
🔧 Transmission
Standard
Type:
Automatic CVT (Continuously Variable Transmission)
Features
Drive:
Belt drive
Gear Ratios:
Continuously variable, optimized for performance and economy
📐 Dimensions
Exterior
Length:
Approx. 2000-2100 mm
Width:
Approx. 760-790 mm
Height:
Approx. 1350-1450 mm (including windscreen)
Weights
Dry Weight 125Cc:
Approx. 145-155 kg
Dry Weight 200Cc:
Approx. 155-165 kg
Gross Vehicle Weight:
Approx. 300-320 kg
Cargo
Storage Capacity:
Under-seat storage for one full-face helmet, glove compartment
🛡️ Safety Features
Ratings
Crash Test Ratings:
N/A (Motorcycle/Scooter specific ratings vary by region and are not standardized like cars)
Active Features
Braking System:
Hydraulic Disc Brakes (Front and Rear). ABS optional on some later models.
Lighting:
Halogen Headlamp, LED Taillight/Brake Light
Passive Features
Frame Construction:
Steel tubular frame
Tires:
Tubeless tires, typical sizes: Front 14" or 15", Rear 14" or 15"
Mirrors:
Integrated rearview mirrors
💡 Technology Features
Infotainment
Instrumentation:
Analog/digital combination instrument cluster: speedometer, tachometer, fuel gauge, odometer, trip meter, indicator lights.
Driver Assistance
ABS:
Optional Anti-lock Braking System (ABS) available on some later models.
Connectivity
Features:
Basic, primarily mechanical and electrical systems. No advanced digital connectivity.
🔧 Maintenance
Service Intervals
Oil Change Frequency:
Every 3,000-5,000 km or annually (refer to manual for precise interval)
Air Filter Check:
Every 3,000-5,000 km
Spark Plug Replacement:
Every 6,000-10,000 km
Transmission Fluid Check:
Check periodically, replacement based on mileage/time (refer to manual)
Brake Fluid Replacement:
Every 2 years or as per manual recommendation
Fluid Specifications
Engine Oil Type:
SAE 10W-40, API SG/SH/SJ or higher, JASO MA certified motorcycle oil (e.g., Motul 5100 10W40)
Engine Oil Capacity:
Approx. 1.1-1.3 liters (including filter, refer to manual)
Coolant Type:
Ethylene Glycol based antifreeze with corrosion inhibitors (e.g., Piaggio/Aprilia Piaggio Group coolant or equivalent)
Brake Fluid Type:
DOT 4
Known Issues
Common Problems:
Electrical connector corrosion, regulator/rectifier failure (on some models), wear on CVT components (belt, rollers), carburetor jetting issues (if carbureted).
Typical Repairs:
CVT belt replacement, battery and charging system checks, carburetor cleaning and adjustment, brake pad and fluid replacement.
📚 Vehicle History
Brand Heritage
Manufacturer:
Aprilia is an Italian manufacturer with a strong heritage in motorcycle racing and performance scooters.
Model Evolution
Positioning:
The Atlantic series represented Aprilia's push into the maxi-scooter market, offering a blend of sportiness and practicality.
Development:
Evolved from earlier Aprilia scooter platforms, incorporating modern design and technology of its era.
Production
Manufacturing Location:
Italy (primarily)
Discontinuation:
The Atlantic line was eventually superseded by newer Aprilia scooter models.
🏆 Awards & Recognition
Recognitions
Market Reception:
Generally well-received for its sporty styling and performance within its class during its production run.
Ratings
Consumer Reports:
N/A (specific model ratings not widely available in standardized formats).
Certifications
Emissions:
Euro 2 or Euro 3 compliant (depending on model year and market).

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
