Mitsubishi FTO 1998 Chassis Workshop Service Repair Manual

Mitsubishi FTO 1998 Chassis Workshop Service Repair Manual

$16.99
$16.99
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
Vehicle data plateRef 344552
Brand
Mitsubishi
Vehicle
Cars
Models covered
FTO
Years
1998
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Mitsubishi
Model:
FTO
Year:
1998
Chassis Code:
DE2A, DE3A
Codes
Engine Codes Covered:
6A12 (V6 SOHC/DOHC MIVEC), 6A13 (V6 DOHC MIVEC)
Transmission Codes Covered:
F5M42 (5-speed Manual), F4A42 (4-speed Automatic - INVECS-II)
👋 Introduction
Market Position
Positioning:
The Mitsubishi FTO was a sporty coupe produced by Mitsubishi Motors, often considered a 'halo car' for the brand, known for its striking design and performance-oriented features, particularly in its V6 variants and later MIVEC models.
Competitive Analysis
Competitors 1998:
Toyota Celica GT-Four, Nissan Silvia S14, Mazda RX-7 FD, Honda Prelude
Key Features
Design Philosophy:
Aerodynamic styling, driver-focused cockpit, emphasis on handling and performance
Drivetrain Options:
Front-wheel drive (FWD) and optional All-wheel drive (AWC - Viscous Coupling unit on some models, especially earlier V6) variants available.
📋 Manual Details
Coverage Areas
Primary Coverage:
Chassis, Powertrain, Electrical, Body
Secondary Coverage:
Maintenance, Diagnostics, Repair Procedures
Page Count
Estimated Page Count:
900+
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
File Format:
PDF
Delivery Method:
Digital Download (.rar/.zip)
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine assembly, cylinder head, block, pistons, crankshaft, camshafts, timing system
Engine Lubrication:
Oil pump, oil filter, oil cooler, lubrication passages, oil pressure diagnostics
Engine Cooling:
Radiator, water pump, thermostat, cooling fan, coolant flow, temperature sensors
Engine Control:
ECU, ignition system, fuel injection, sensor diagnostics (crank, cam, O2, MAP, TPS), emissions control
Fuel System:
Fuel pump, injectors, fuel filter, fuel lines, fuel tank, pressure regulator
Exhaust System:
Exhaust manifold, catalytic converter, mufflers, pipes, O2 sensors
Accelerator Control:
Throttle body, accelerator cable, cruise control system operation
Clutch:
Clutch assembly, hydraulic system, clutch pedal, clutch fork, release bearing
Manual Transmission:
Gearbox assembly, gears, bearings, synchros, shift mechanism, fluid specifications
Automatic Transmission:
INVECS-II, torque converter, valve body, clutch packs, solenoids, fluid specifications, control system
Propeller Shaft:
Driveshaft, universal joints, center bearing (if applicable)
Rear Final Drive:
Differential assembly, gears, bearings, fluid specifications
Front Axle:
CV joints, drive shafts, hub bearings
Rear Axle:
Suspension mounting points, axle shafts (if applicable)
Front Suspension:
MacPherson struts, control arms, anti-roll bar, bushings, alignment specifications
Rear Suspension:
Multi-link suspension, trailing arms, coil springs, shock absorbers, alignment specifications
Brake System:
Front and rear disc brakes, calipers, pads, rotors, hydraulic lines, fluid specifications
Parking Brake:
Cable operation, rear caliper parking brake mechanism
Brake Control:
ABS system components, sensors, hydraulic unit
Steering Control:
Power steering system, steering rack, tie rods, steering column, wheel alignment
Seat Belts:
Pretensioner operation, belt mechanisms, anchor points
Srs:
Airbag system components, sensors, control module, deployment procedures
Body Lock Security:
Door locks, ignition lock, central locking system, alarm system (if equipped)
Glasses Windows Mirrors:
Window regulators, power window system, mirror adjustments and motors
Exterior Interior:
Body panels, bumpers, trim, interior trim panels, headliner, carpet
Instrument Panel:
Gauges, warning lights, instrument cluster removal and repair
Seats:
Seat adjustment mechanisms, seat belts, airbag integration
Automatic Air Conditioner:
Refrigerant system, compressor, condenser, evaporator, blower motor, controls, diagnostics
Starting Charging:
Starter motor, alternator, battery, charging system diagnostics
Lighting System:
Headlights, taillights, interior lighting, turn signals, bulb replacement, wiring diagrams
Driver Information System:
Trip computer, warning indicators, diagnostic trouble codes (DTCs)
Wiper Washer Horn:
Wiper motor, washer pump, wiper arms, wiper blades, horn operation
Body Control System:
BCM (Body Control Module) functions, lighting control, power accessories
Lan System:
Internal vehicle communication network (e.g., MOST, CAN bus - if applicable for this year/model)
Audio Visual Navigation Telephone:
Stereo system, speakers, antenna, navigation unit (if factory-fitted), telephone system integration
Auto Cruise Control:
Cruise control system operation, components, diagnostics
Power Supply Ground Circuit:
Wiring diagrams, fuses, relays, grounding points, electrical troubleshooting
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Procedures Included
Routine Maintenance:
Oil changes, filter replacements, spark plug replacement, fluid checks and top-offs
Diagnostic Procedures:
Troubleshooting charts, symptom-based diagnostics, DTC interpretation
Repair Procedures:
Step-by-step instructions for component removal, installation, and adjustment
Overhaul Procedures:
Engine rebuild, transmission overhaul, differential rebuild (detailed disassembly and reassembly)
Wiring Diagrams:
Comprehensive electrical schematics for all vehicle systems
Torque Specifications:
Precise torque values for all critical fasteners
Technical Depth
Depth:
Comprehensive: Covers everything from basic maintenance to full engine and transmission rebuilds, including diagnostics and electrical troubleshooting.
📊 Manual Specifications
File Format
Quality:
High-resolution PDF, readable text
Print Quality
Printability:
Yes, printable pages
Binding Type
Binding:
N/A (Digital PDF)
Paper Type
Paper Type:
N/A (Digital PDF)
Software Requirements
Decompression Software:
WinZip, WinRAR, or 7-Zip (free)
PDF Reader Software:
Adobe Acrobat Reader or compatible PDF viewer (free)
⚙️ Engine Specifications
Primary Engine
Engine 1:
6A12
Engine 1 Type:
60-degree V6 SOHC
Engine 1 Displacement:
2.0 Liters (1998 cc)
Engine 1 Power Output Sohc:
Approx. 170-180 PS (125-132 kW)
Engine 1 Power Output DOHc Mivec:
Approx. 195-200 PS (143-147 kW)
Engine 1 Torque Sohc:
Approx. 180-190 Nm (133-140 lb-ft)
Engine 1 Torque DOHc Mivec:
Approx. 190-200 Nm (140-148 lb-ft)
Secondary Engine
Engine 2:
6A13
Engine 2 Type:
60-degree V6 DOHC MIVEC (Mitsubishi Innovative Valve timing Electronic Control system)
Engine 2 Displacement:
2.5 Liters (2498 cc)
Engine 2 Power Output:
Approx. 220-225 PS (162-165 kW)
Engine 2 Torque:
Approx. 240-250 Nm (177-184 lb-ft)
Fuel System
Fuel Injection:
Electronic Multi-Point Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline (Octane rating typically 95 RON)
🔧 Transmission
Standard
Transmission 1:
5-speed Manual (F5M42)
Optional
Transmission 2:
4-speed Automatic with INVECS-II (F4A42)
Features
Automatic Features:
Sport Mode, Snow Mode (INVECS-II adaptive shift control)
Fluid Specifications
Manual Transmission Fluid:
API GL-4, SAE 75W-90
Automatic Transmission Fluid:
DIAQueen ATF-SP II M (or equivalent DEXRON III)
📐 Dimensions
Exterior
Length:
Approx. 4310 mm (169.7 in)
Width:
Approx. 1755 mm (69.1 in)
Height:
Approx. 1305 mm (51.4 in)
Wheelbase:
Approx. 2500 mm (98.4 in)
Weights
Curb Weight Approx:
1200 - 1350 kg (2646 - 2976 lbs) depending on engine and transmission
🛡️ Safety Features
Ratings
Crash Test Results:
Specific official crash test ratings for the 1998 FTO are not widely published for all regions. However, the vehicle was designed to contemporary safety standards.
Active Features
ABS:
Anti-lock Braking System (ABS) typically standard on higher trims and optional on others.
Passive Features
Airbags:
Driver and passenger airbags (SRS) standard on most models.
Seat Belts:
Three-point inertia-reel seat belts with pre-tensioners for front occupants.
💡 Technology Features
Infotainment
Audio System:
Factory-fitted radio/cassette player with speaker system. Optional CD player. Aftermarket upgrades common.
Driver Assistance
Cruise Control:
Available as an option or standard on higher trim levels.
Traction Control:
TCL (Traction Control) system available on some AWC models.
Connectivity
Internal Network:
The manual covers electrical systems and potential internal communication protocols for diagnostic purposes.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 7,500 - 10,000 miles (12,000 - 15,000 km) or 6-12 months, whichever comes first.
Timing Belt Replacement:
Crucial for 6A12/6A13 engines. Recommended replacement every 60,000 - 90,000 miles (96,000 - 145,000 km) or 5-7 years. Failure can cause catastrophic engine damage.
Spark Plug Replacement:
Iridium plugs often last up to 100,000 miles; platinum plugs around 60,000 miles. Consult manual for specific type.
Fluid Specifications
Engine Oil Capacity 6A12:
Approx. 4.0 - 4.5 Liters (with filter)
Engine Oil Type:
API SL or higher, SAE 5W-30 or 10W-40 (depending on climate). Consult manual for exact viscosity.
Coolant Capacity:
Approx. 6.0 - 7.0 Liters
Coolant Type:
Ethylene glycol based antifreeze (green or pink type), mixed 50/50 with distilled water.
Known Issues
Engine Mivec Actuators:
Potential issues with MIVEC solenoid operation or actuator failure, leading to poor performance.
Suspension Bushings:
Wear and tear on suspension bushings can lead to increased road noise and compromised handling.
Automatic Transmission:
INVECS-II can sometimes exhibit clunky shifting or require a reset/relearn procedure. ATF changes are critical.
Rust Corrosion:
Like many Japanese cars of this era, underbody rust and corrosion can be an issue in certain climates.
📚 Vehicle History
Brand Heritage
Mitsubishi Motors:
Mitsubishi Motors has a long history in motorsport and performance vehicle development, influencing models like the FTO.
Model Evolution
Fto Designation:
'FTO' stands for 'Future, Total, Optimize', reflecting its forward-thinking design and sporty intentions.
Mivec Technology:
The FTO was one of the first Mitsubishi production cars to feature the MIVEC (Mitsubishi Innovative Valve timing Electronic Control system), enhancing both power and efficiency.
Production
Production Period:
1994-2000
Key Milestone 1998:
The 1998 model year falls within the later stages of the FTO's production, often featuring updated styling and specifications.
🏆 Awards & Recognition
Recognitions
Japan Performance Car:
The FTO was awarded 'Car of the Year Japan' for 1994-1995, specifically for its innovative MIVEC engine and sporty design.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
