Dodge

Dodge Caliber 2007 to 2013 Full Repair + Service Manual

Dodge Caliber 2007 to 2013 Full Repair + Service Manual

$17.99
$17.99
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
Vehicle data plateRef 374905
Brand
Dodge
Vehicle
Cars
Models covered
Caliber
Years
2007, 2008, 2009, 2010, 2011, 2012, 2013
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Dodge
Model:
Caliber
Years Covered:
2007, 2008, 2009, 2010, 2011, 2012, 2013
Codes
Platform:
Chrysler JS platform (based on Mitsubishi GS platform)
👋 Introduction
Market Position
Segment:
Compact SUV / Crossover
Target Audience:
Budget-conscious consumers seeking a versatile, practical vehicle with a stylish exterior and a range of engine options.
Competitive Analysis
Key Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Mazda CX-5, Nissan Rogue, Hyundai Tucson.
Key Features
Design:
Distinctive, SUV-like exterior styling with a tall roofline and hatchback utility, differentiating it from more conventional sedans.
Interior:
Spacious cabin for its class, versatile seating arrangements, available features like a chilled glove box and enhanced audio systems.
Powertrain Options:
Wide range of engines, including fuel-efficient base options and more powerful choices, catering to various driving needs.
📋 Manual Details
Coverage Areas
Coverage:
All mechanical, electrical, body, and maintenance aspects for the specified Dodge Caliber model years.
Page Count
Page Count:
Comprehensive (estimated 2000+ pages, typical for full factory service manuals)
Manual Type
Manual Type:
Full Repair and Service Manual (Factory Service Manual equivalent)
Language
Language:
English
Format
Format:
Digital (likely PDF, potentially with searchable capabilities)
📖 Manual Coverage
Systems Covered
Powertrain:
Engine (2.0L, 2.4L, 1.8L, 1.8L Diesel), Transmission (CVT, 5-speed Manual, 6-speed Manual), Drivetrain (FWD).
Chassis:
Suspension (front MacPherson strut, rear multi-link/independent), Brakes (ABS, front discs, rear drums/discs), Steering (power rack and pinion).
Electrical:
Wiring diagrams, lighting, power windows, mirrors, audio systems, instrument cluster, body control modules (BCM), Powertrain Control Module (PCM).
Body And Trim:
Interior trim, exterior panels, bumpers, doors, glass, seats, airbags.
Procedures Included
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement.
Diagnostics:
Troubleshooting guides for common issues, DTC (Diagnostic Trouble Code) interpretation and resolution, electrical system diagnostics.
Repair:
Engine overhaul, transmission rebuilds, brake system repairs, suspension component replacement, exhaust system repair, cooling system service.
Installation:
Component replacement procedures, timing belt/chain replacement, accessory installation.
Technical Depth
Depth:
Comprehensive: From basic fluid checks to complete engine and transmission overhauls, including detailed diagnostic procedures and torque specifications.
📊 Manual Specifications
File Format
File Format:
PDF (Portable Document Format)
Print Quality
Print Quality:
High-resolution, suitable for printing individual pages or the entire manual. Contains clear diagrams and text.
Binding Type
Binding Type:
N/A (Digital format, but if printed, typically coil-bound or perfect-bound for usability)
Paper Type
Paper Type:
N/A (Digital format)
⚙️ Engine Specifications
Primary Engine
Engine 1 Displacement:
2.0L (1998 cc)
Engine 1 Configuration:
Inline 4-cylinder, DOHC, 16-valve
Engine 1 Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Engine 1 Power:
Approximately 140-158 hp @ 6000-6500 rpm (depending on specific variant and market)
Engine 1 Torque:
Approximately 130-140 lb-ft @ 4500-5000 rpm (depending on specific variant and market)
Secondary Engine
Engine 2 Displacement:
2.4L (2360 cc)
Engine 2 Configuration:
Inline 4-cylinder, DOHC, 16-valve, World Engine (GEMA family)
Engine 2 Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Engine 2 Power:
Approximately 172 hp @ 6000 rpm
Engine 2 Torque:
Approximately 165 lb-ft @ 4000 rpm
Other Engines
Engine 3 Options:
1.8L (1798 cc) Inline 4-cylinder (Chrysler/Global Engine Alliance), 1.8L CRD Turbodiesel (for European markets).
Fuel System
Fuel Type:
Unleaded Gasoline (87 octane recommended, higher for performance variants), Diesel (for CRD models).
Performance
Compression Ratio:
Varies by engine; e.g., 2.0L approx. 9.5:1, 2.4L approx. 9.5:1
🔧 Transmission
Standard
Transmission 1 Type:
5-speed Manual (Getrag / Chrysler T350)
Optional
Transmission 2 Type:
Continuously Variable Transmission (CVT) - Jatco JF011E (marketed as AutoStick by Dodge)
Transmission 3 Type:
6-speed Manual (Getrag / Chrysler NS35T5, typically with 2.4L engine)
Features
Cvt Features:
Simulated gear changes in some later models, front-wheel drive only.
Fluid Specification
Manual Transmission Fluid:
MS-9070 (or equivalent API GL-4 SAE 75W-90 gear oil)
Cvt Transmission Fluid:
Chrysler CVTF (Jatco NS-2 specification) - requires specific CVT fluid, NOT regular ATF.
📐 Dimensions
Exterior
Length:
Approximately 168.4 - 170.9 inches (4275 - 4340 mm) depending on model year and trim.
Width:
Approximately 69.1 inches (1755 mm)
Height:
Approximately 60.4 inches (1535 mm)
Wheelbase:
Approximately 103.7 inches (2634 mm)
Interior
Passenger Volume:
Approximately 95-98 cubic feet (2689 - 2775 liters)
Cargo
Cargo Volume Behind Rear Seats:
Approximately 14.0 - 21.1 cubic feet (396 - 597 liters) depending on configuration.
Cargo Volume With Rear Seats Folded:
Approximately 49.4 - 53.1 cubic feet (1400 - 1504 liters)
Weights
Curb Weight:
Approximately 3050 - 3400 lbs (1383 - 1542 kg) depending on engine and driveline.
🛡️ Safety Features
Ratings
NHTSA Front Impact Driver:
Good (2007 model year)
NHTSA Front Impact Passenger:
Good (2007 model year)
NHTSA Side Impact Front Seat Occupant:
Good (2007 model year)
NHTSA Side Impact Rear Seat Occupant:
Good (2007 model year)
IIHS Front Offset Crash Test:
Acceptable (2007 model year), Marginal (later model years tested differently or not tested)
Active Features
ABS:
Standard on most trims; Antilock Braking System (ABS) available with Brake Assist.
Traction Control:
Available (TCS), often part of stability control systems in later models.
Stability Control:
Available (ESC/ESP - Electronic Stability Program) on many models, especially those with CVT or higher trims.
Passive Features
Airbags:
Standard multi-stage front airbags, available front side-impact airbags and full-length side curtain airbags.
Seatbelts:
3-point seatbelts with pretensioners and load limiters for all occupants.
💡 Technology Features
Infotainment
Audio System:
Available Boston Acoustics premium audio system with subwoofer, SiriusXM Satellite Radio, Uconnect multimedia system (late models).
Navigation:
Optional factory-installed navigation system available on higher trims.
Driver Assistance
Parking Sensors:
Available rear parking assist system.
Connectivity
Bluetooth:
Uconnect Bluetooth hands-free communication system available on later models and as an option.
Other Features
Climate Control:
Manual or automatic climate control options, available heated seats.
Lighting:
Halogen headlights, optional fog lights, interior dome and map lights.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically 5,000 - 7,500 miles (8,000 - 12,000 km) or 6 months, whichever comes first, depending on driving conditions and oil type used (refer to manual for specific recommendations and synthetic oil use).
Engine Air Filter:
Recommended replacement every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection.
Cabin Air Filter:
Recommended replacement every 15,000 - 20,000 miles (24,000 - 32,000 km) or annually.
Spark Plugs:
Varies by engine; typically 60,000 miles (96,000 km) for Iridium plugs, 30,000 miles (48,000 km) for platinum or copper plugs.
Transmission Fluid Change:
CVT fluid: Lifetime fill recommended by some, but regular inspection and replacement every 60,000-100,000 miles (96,000-160,000 km) is prudent. Manual transmission fluid: Inspect periodically, replace every 60,000-100,000 miles (96,000-160,000 km).
Fluid Specifications
Engine Oil Specification:
SAE 5W-20 or SAE 5W-30 (refer to owner's manual for specific engine and temperature recommendations). MS-6395 compliant.
Coolant:
Chrysler HOAT (Hybrid Organic Acid Technology) Pink/Orange coolant. MS-9769 specification. Do NOT mix with OAT or IAT coolants.
Brake Fluid:
DOT 3 or DOT 4 (refer to manual for exact specification).
Known Issues
Transmission Cvts:
Early CVT models were prone to valve body issues, solenoid failures, and torque converter problems, often leading to shuddering or loss of drive. Regular fluid changes are critical.
Engine Mounts:
Premature wear and failure of engine mounts can lead to excessive vibration and clunking noises.
Suspension:
Front suspension components (struts, ball joints) and rear suspension bushings can wear out, leading to noise and poor handling.
Cv Axles:
Outer CV joints can wear out, causing clicking noises during turns.
Power Steering:
Some models experienced issues with power steering pump or electric power steering (EPS) systems, leading to stiffness or noise.
📚 Vehicle History
Brand Heritage
Parent Company:
Chrysler Group LLC (then owned by Cerberus Capital Management, later Fiat Chrysler Automobiles).
Model Evolution
Introduction Year:
2007
Facelift Year:
A minor refresh occurred for the 2011 model year, primarily with updated interior materials, new wheel designs, and revised option packages. No significant mechanical redesign.
Production
Production End Year:
2012 (for North American market), 2013 (global markets and final production year).
Manufacturing Location:
Belvidere, Illinois, USA; also other plants globally for different markets.
🏆 Awards & Recognition
Recognitions
Consumer Reports Ratings:
Generally received average to below-average reliability ratings from Consumer Reports over its production run, particularly concerning the CVT transmission.
Ratings
Kbb Value:
Resale value is typically in the lower to mid-range for its class, reflecting market reception and reliability perceptions.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the model year and engine before you buy

Manufacturers change procedures, wiring and part numbers between model years and engine options. If your VIN plate shows a year or engine code that is not listed on the data plate above, contact us with the model, year and VIN and we will confirm coverage before you order.
