Suzuki VZ 800 Service Repair Manual

Suzuki VZ 800 Service Repair Manual

$16.99
$16.99
Sale Ausverkauft
Versand wird beim Checkout berechnet
Vehicle data plateRef 399771
Brand
Suzuki
Vehicle
Motorcycle
Models covered
Carry, VZ 800
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your model year? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Suzuki
Model:
VZ 800
Model Nickname:
Intruder 800 / Boulevard C50
Codes
Engine Code Common:
V-twin, 45-degree liquid-cooled, 4-stroke
👋 Introduction
Market Position
Category:
Cruiser Motorcycle
Target Audience:
Suzuki VZ 800 owners, DIY mechanics, aspiring motorcycle technicians
Competitive Analysis
Competitors:
Honda Shadow series, Yamaha V-Star series, Kawasaki Vulcan series
Key Features
Manual Benefits:
Enables self-maintenance and repair, reduces reliance on professional mechanics, cost-effective solution.
Manual Accessibility:
Instant download, easy to carry (digital format), easy to understand language.
Visual Aids:
Includes proper pictures with illustrations for easier repair.
📋 Manual Details
Coverage Areas
Covered Models:
Suzuki VZ 800 (specific years not explicitly stated, but typically covers a range of production years for this model, commonly 1997-2004 Intruder 800 and its successor, the Boulevard C50, from 2005 onwards)
Primary Focus:
Service and Repair
Page Count
Estimated Pages:
Typically between 300-500 pages for a comprehensive service manual, though exact count is not provided.
Manual Type
Type:
Service Repair Manual
Language
Language:
Simple English
Format
Format:
Digital Download (likely PDF)
📖 Manual Coverage
Systems Covered
Engine:
Cylinder Head/Valve, Crankcase, Transmission, Cylinder/Piston, Engine Removal/Installation, Lubrication system, Ignition System, Alternator/Starter Clutch, Electric Starter
Drivetrain:
Clutch/Gearshift Linkage, Rear Driving Mechanism, Front Driving Mechanism (if applicable, though VZ800 is typically shaft-driven rear), Selectable 4WD System (Unlikely for this cruiser model, likely a misstatement in product description, but manual claims coverage.)
Chassis And Suspension:
Wheel/Suspension/Steering, Rear Wheel/Suspension
Brakes:
Brake System
Electrical:
Lights/Meters/Switches, Battery/Charging System, Wiring Diagrams
Steering:
Electric Power Steering (Unlikely for this model, likely misstatement or referring to steering damper if equipped. Standard VZ800 has manual steering.)
Bodywork:
Included (implied by 'from front to back' coverage)
General Information:
Included (covers basic information, specifications, and general procedures)
Procedures Included
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, lubrication
Repair And Rebuild:
Engine, transmission, clutch, brakes, suspension, electrical components
Troubleshooting:
Diagnostic procedures, common issues and solutions
Diagnostics:
System checks, fault finding
Electric Shift Program:
Covered (Note: This is highly unusual for a VZ800/C50 and likely a misstatement in the product description, as these models do not have electric shift programs. The manual might be a generic template or incorrectly listing features.)
Selectable 4Wd System:
Covered (Note: This is highly unusual for a VZ800/C50 and likely a misstatement in the product description, as these models are 2-wheel drive. The manual might be a generic template or incorrectly listing features.)
Electric Power Steering:
Covered (Note: This is highly unusual for a VZ800/C50 and likely a misstatement in the product description, as these models do not have electric power steering. The manual might be a generic template or incorrectly listing features.)
Technical Depth
Depth:
Comprehensive (from basic maintenance to complete engine rebuilds, including detailed diagrams and specifications)
Diagnostic Tools:
Covers procedures that may require basic tools and diagnostic skills, potentially referring to specific Suzuki diagnostic tools for EFI models.
📊 Manual Specifications
File Format
Format:
Digital Download (assumed PDF, likely searchable and printable)
Print Quality
Quality:
High quality (designed by well-qualified technicians, used by industries)
Binding Type
Binding:
Not Applicable (Digital)
Paper Type
Type:
Not Applicable (Digital)
Coverage Areas
Index Availability:
Yes (as indicated in content list)
⚙️ Engine Specifications
Primary Engine
Type:
V-twin, 45-degree
Cooling:
Liquid-cooled
Displacement:
783 cc (47.8 cubic inches)
Bore X Stroke:
Approx. 83 mm x 74.4 mm (typical for this engine)
Valvetrain:
SOHC, 4 valves per cylinder
Performance
Horsepower:
Approx. 50-55 HP (at crank, specific rating varies by year and market)
Torque:
Approx. 65-70 Nm (at crank, specific rating varies by year and market)
Fuel System
Induction:
Digital Fuel Injection (DFI) or Carbureted (early models)
Fuel Type:
Unleaded gasoline (91 octane or higher recommended)
Ignition System
Type:
Electronic Ignition (CDI/Transistorized)
🔧 Transmission
Standard
Type:
5-speed manual
Clutch:
Wet multi-plate
Features
Final Drive:
Shaft drive
📐 Dimensions
Exterior
Length:
Approx. 2360 mm (92.9 in)
Width:
Approx. 830 mm (32.7 in)
Height:
Approx. 1130 mm (44.5 in)
Weights
Dry Weight:
Approx. 215 kg (474 lbs)
Wet Weight:
Approx. 232 kg (511 lbs)
Fuel Capacity:
Approx. 15.5 L (4.1 US gal)
🛡️ Safety Features
Ratings
Classification:
Cruiser Motorcycle (No formal safety ratings like cars)
Active Features
Braking Front:
Single disc (typically 330mm) with 2-piston caliper
Braking Rear:
Disc (typically 270mm) with 1-piston caliper
Passive Features
Lighting:
Halogen headlight, LED taillight
💡 Technology Features
Infotainment
Features:
Basic instrumentation (speedometer, tachometer, fuel gauge, warning lights). No advanced infotainment systems.
Driver Assistance
Features:
None (traditional cruiser design)
🔧 Maintenance
Service Intervals
Oil Change:
Every 6,000 km (3,700 miles) or 6 months
Air Filter Check:
Every 6,000 km (3,700 miles)
Spark Plug Replacement:
Every 12,000 km (7,500 miles)
Fluid Specifications
Engine Oil:
SAE 10W-40 API SG or higher (check manual for exact spec and capacity, typically ~3.2L with filter change)
Brake Fluid:
DOT 4
Coolant:
Suzuki Super Long Life Coolant or equivalent (50/50 mix with distilled water)
Known Issues
Common Problems:
Stator failure (common on many Suzuki models), charging system issues, carburetor cleaning/synchronization (for pre-FI models), driveshaft boot cracking, starter clutch wear.
Preventative Maintenance:
Regular oil changes, checking and maintaining battery health, inspecting for leaks, proper clutch adjustment.
📚 Vehicle History
Brand Heritage
Manufacturer:
Suzuki Motor Corporation, Japan
Model Evolution
Intruder 800:
Launched as the Intruder 800 in the early 1990s, evolving through the VZ 800 designation. Known for its classic cruiser styling and reliable V-twin engine.
Boulevard C50:
Rebranded and subtly updated as the Boulevard C50 starting in 2005, continuing the legacy with fuel injection (on most models) and refined styling.
Production
Production Period:
Continuously produced with updates from early 1990s to present (as Boulevard C50).
